Service Manual
Household Sewing
Registered Trademark "THE SINGER COMPANY LTD."
Machine
Series
2700
2700
THE SINGER COMPANY
2003 SINGER (SHANGHAI)
SEWING MACHINE CO., LTD.
ALL RIGHTS RESERVED
Printed In China
359109-000 AGO/03

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2700 Series and is the answer not in the manual?

Questions and answers

Tracy
April 5, 2025

I need the Singer 2700 series service manual Section 2 pages 67-141. It appears you only have section 1 Pages 1-66

1 comments:
Mr. Anderson
April 5, 2025

The provided context does not include Section 2 pages 67–141 of the Singer 2700 Series service manual. Therefore, their location cannot be determined.

This answer is automatically generated

Summary of Contents for Singer 2700 Series

  • Page 1 Service Manual Household Sewing Machine Series 2700 2700 THE SINGER COMPANY 2003 SINGER (SHANGHAI) SEWING MACHINE CO., LTD. ALL RIGHTS RESERVED Registered Trademark “THE SINGER COMPANY LTD.” Printed In China 359109-000 AGO/03...
  • Page 2 Service Manual 2700 - Revisions Records Approval Description Revision and date Rev. n . 359109-000 AGO/03 AGO/03...
  • Page 3 This manual is designed for use by trained and qualified service persons. The SINGER COMPANY will not be responsible for any parts requiring replacement due to natural wear or to the abuse or negligence of its use or in the event the machine is serviced by other than a trained and qualified service person or even if replaced parts do not meet applicable specifications.
  • Page 4 This service manual describes all of the servicing procedures,including all adjustments and parts removal and replacement for the 2700 class machine. Additional information covering any production changes, improvements or changes to parts will be made by issuing Singer service/parts bulletins.
  • Page 5: Table Of Contents

    Service Manual Table of Contents Section I PAGE Parts removals and replacements............Face plate..................07-08 Light bulb replacement..............07-08 Arm top cover................09-10 Bed bottomcover................11-12 Rear cover..................13-14 Front cover..................15-16 Needle bar..................17-18 Face plate and lamp mounting bracket..........19-20 Needle threader assembly (for model 2730/2732) ........
  • Page 6 Service Manual Table of Contents Section 2 PAGE Sequential order of adjustment procedures ..........Vertical shaft end play ................. 68-69 Bevel gear mesh and arm shaft end play ..........70-71 Disc follower height adjustment ............72-73 Disc and disc follower clearance (For models 2718/24/30) ......74-75 Disc stack radial play (For models 2718/24/30) ........
  • Page 7: Parts Removals And Replacements

    Service Manual Section 1 Parts Removal and Replacement Rev. n . 359109-000 AGO/03 AGO/03...
  • Page 8: Face Plate

    Service Manual Face Plate Cover Light Bulb Replacement Rev. n . 359109-000 AGO/03 AGO/03...
  • Page 9 Service Manual Face Plate Cover Removal: 1. Raise presser foot. 2. Remove face plate cover screw (A). 3. Remove face plate cover (B) by pulling it down and laterally and then out of the machine. Replacement: 1. Replacement of the face plate cover is the same as described above, but in a reverse order.
  • Page 10: Arm Top Cover

    Service Manual Arm Top Cover Rev. n . 359109-000 AGO/03 AGO/03...
  • Page 11 Service Manual Arm Top Cover Removal: 1. Place bobbin winder in the “OFF” position. 2. Remove tree arm top cover srews (A), (B) and (C). 3. Remove the arm top cover by pulling it straight upwards. Replacement: 1. Replacement is the same as removal in reverse order. Rev.
  • Page 12: Bed Bottomcover

    Service Manual Bed bottom Cover Rev. n . 359109-000 AGO/03 AGO/03...
  • Page 13 Service Manual Bed bottom Cover Removal: Remove the free-arm extension table. 2. Remove the three screws (A). 3. Remove 8 mm hex nut (B). 3. Remove bed bottom cover (C). Replacement: Replacement of this bed bottom cover is the same as described above, but in a reverse order.
  • Page 14: Rear Cover

    Service Manual Rear Cover Rev. n . 359109-000 AGO/03 AGO/03...
  • Page 15 Service Manual Rear Cover Removal: Remove the free-arm extension table, the face plate cover and arm top cover. 2. Turn the machine down and remove bottom bed cover. 3. Loose screws (A) and screw (C) by turning them 3 times. 4.
  • Page 16: Front Cover

    Service Manual Front Cover For 2712 / 2722 / 2732 For 2718 / 2724 / 2730 Rev. n . 359109-000 AGO/03 AGO/03...
  • Page 17 Service Manual Front Cover Removal: Remove the free-arm extension table, face plate and arm top cover, the bottom bed cover and rear cover. 2. Move all the levers to it’s center positions and remove the knobs (B) by pulling it straight frontward (2 knobs for models 2718, 2724 and 2730, and 3 knobs for models 2712, 2722 and 2732).
  • Page 18: Needle Bar

    Service Manual Needle Bar Rev. n . 359109-000 AGO/03 AGO/03...
  • Page 19 Service Manual Needle Bar Removal: 1. Remove the face plate and arm top cover. 2. Remove needle by loosing the screw (B). Turn handwheel to bring the needle bar to its position. Loose screw (A) together with the thread guide and then, remove the entire needle clamp body.
  • Page 20: Face Plate And Lamp Mounting Bracket

    Service Manual Face Plate and Lamp Mounting Bracket Rev. n . 359109-000 AGO/03 AGO/03...
  • Page 21 Service Manual Face Plate and Lamp Mounting Bracket Removal: Remove the face plate and the arm top cover. 2. Remove the screw (A),the washer and the needle threader lever guide (for models 2730/2732). 3. Loose the screw (B) and remove the socket with the lamp. 4.
  • Page 22: Needle Threader Assembly (For Model 2730/2732)

    Service Manual Needle Threader Assembly (For Models 2730/2732) Rev. n . 359109-000 AGO/03 AGO/03...
  • Page 23 Service Manual Needle Threader Assembly (For Models 2730/2732) Removal: 1. Remove the face plate and the arm top cover. 2. Force the needle threader (F) down to remove it. 3. Remove the screw (H), the washer and the support guide. 4.
  • Page 24: Needle Bar Vibrating Bracket Assembly

    Service Manual Needle Bar Vibrating Bracket Assembly Rev. n . 359109-000 AGO/03 AGO/03...
  • Page 25 Service Manual Needle Bar Vibrating Bracket Assembly Removal: 1. Remove the face plate, arm top cover and the needle bar. 2. Loose the screw (A). 3. Remove the screw (B) and the collar (C). 4. Loose the screw (D) and remove the stud (E). 5.
  • Page 26: Presser Bar Assembly

    Service Manual Presser Bar Assembly Rev. n . 359109-000 AGO/03 AGO/03...
  • Page 27 Service Manual Presser Bar Assembly Removal: 1. Remove the face plate, arm top cover, needle bar, face plate and lamp mounting bracket, needle threader and needle bar vibrating bracket. 2. Raise press bar, remove the screw (A) and the presser foot shank with presser foot (B). 3.
  • Page 28: Take-Up Lever Assembly And Needle Bar Connecting Link

    Service Manual Take-up Lever Assembly and Needle Bar Connecting Link Rev. n . 359109-000 AGO/03 AGO/03...
  • Page 29 Service Manual Take-up Lever Assembly and Needle Bar Connecting Link Removal: 1. Remove the face plate, arm top cover, face plate and lamp mounting bracket, needle bar, needle threader assembly and vibrating bracket assembly. 2. Turn handwheel making screws (A) and (B) to come to sight and then, loose these screws just enough to allow stud (D) to be removed.
  • Page 30: Handwheel

    Service Manual Handwheel Rev. n . 359109-000 AGO/03 AGO/03...
  • Page 31 Service Manual Handwheel Removal: 1. Remove the face plate, the free-arm extension table, the arm top cover, and the covers. 2. Turn handwheel (D) making screw (B) to come to sight. 3. Loose screw (B) just enough to clear it out from the hole in armshaft (A). 4.
  • Page 32: Cam Controlled Feed Follower

    Service Manual Cam Controlled Feed Follower For 2712 / 2722 / 2732 For 2718 / 2724 / 2730 Needle Position Lever For 2712 / 2722 / 2732 For 2718 / 2724 / 2730 Rev. n . 359109-000 AGO/03 AGO/03...
  • Page 33 Service Manual Cam Controlled Feed Follower Removal: 1. Remove the free-arm extension plate and all the covers. 2. Remove the retaining ring (A). 3. Remove the cam controlled feed follower assembly (B). Replacement: 1. Replace these parts the same way as described above, but in a reverse order. Needle Position Lever (for Models 2718 / 2724 / 2730) Removal:...
  • Page 34: Cam Controlled Feed Mechanism

    Service Manual Cam Controlled Feed Mechanism Rev. n . 359109-000 AGO/03 AGO/03...
  • Page 35 Service Manual Cam Controlled Feed Mechanism Removal: 1. Remove the free-arm extension table, all the covers and the cam controlled feed follower. 2. Remove spring (B) and the two Philips screws (A). 3. Remove mechanism. Replacement: 1. Replace this set the same way as described above, but in a reverse order. Rev.
  • Page 36: Disk Stack Shaft Gear And Bracket Assembly

    Service Manual Disc Stack Shaft Gear and Bracket Assembly For 2712/22/32 For 2718/24/30 Rev. n . 359109-000 AGO/03 AGO/03...
  • Page 37 Service Manual Disc Stack Shaft Gear and Bracket Assembly for Models 2712 / 2722 / 2732 Removal: 1. Remove the free-arm extension table and all the covers. 2. Loose the screw (A). 3. Remove bracket (B) and the gear by pulling them up. Replacement: 1.
  • Page 38: Zigzag Stitch Width Bracket Assembly

    Service Manual Zigzag Stitch Width Bracket Assembly Rev. n . 359109-000 AGO/03 AGO/03...
  • Page 39 Service Manual Zigzag Stitch Width Bracket Assembly Removal: 1. Remove the free-arm extension table and all the covers. 2. Remove screw (B) and disengage the lever (C). 3. Remove screw (A). 4. Remove the stitch width bracket by pulling it up. Replacement: 1.
  • Page 40: Disc Follower Quick Out Lever(For Models 2718/2724/2730)

    Service Manual Disc Follower Quick Out Lever For 2718/24/30 Disc Follower Rev. n . 359109-000 AGO/03 AGO/03...
  • Page 41 Service Manual Disc Follower Quick Out Lever for Models 2718 / 2724 / 2730 Removal: 1. Remove the free-arm extension table, all the covers and the stitch width bracket assembly. 2. Remove screw (A) and eccentric bushing (B). 3. Remove lever (D) and spring (C). Replacement: 1.
  • Page 42: Arm Shaft And Horizontal Bevel Gear

    Service Manual Arm Shaft and Horizontal Bevel Gear Rev. n . 359109-000 AGO/03 AGO/03...
  • Page 43 Service Manual Arm Shaft and Horizontal Bevel Gear Removal: 1. Remove the free-arm extension table, all the covers, needle bar, face plate lamp mounting bracket, needle bar vibrating bracket, needle threader (for 2730/2732), take-up lever assembly, the cam controlled follower, the cam controlled feed mechanism, the stitch width bracket assembly, the disc follower quick out lever, the disc follower, the disc stack shaft gear and bracket, and the handwheel.
  • Page 44: Pattern Selector Assembly

    Service Manual Pattern Selector Assembly For 2718/24/30 Rev. n . 359109-000 AGO/03 AGO/03...
  • Page 45 Service Manual Pattern Selector Assembly for Models 2718 / 2724 / 2730 Removal: 1. Remove the free-arm extension table, all the covers, disc stack shaft gear bracket, stitch width bracket, disc follower quick out lever and disc follower. 2. Turn the pattern selector dial bringing to sight the screw (A) an then remove this screw. 3.
  • Page 46 Service Manual Pattern Selector Assembly For 2712/22/32 Rev. n . 359109-000 AGO/03 AGO/03...
  • Page 47 Service Manual Pattern Selector Assembly for Models 2712 / 2722 / 2732 Removal: 1. Remove the free-arm extension table, all the covers, the cam controlled feed follower, the cam controlled feed mechanism and the stitch width bracket assembly. 2. Remove driving arm slide screw (H), driving arm slide (G), retaining ring (F), retaining ring ( I ), washer (J) and connecting link screw (N).
  • Page 48: Thread Tension Assembly

    Service Manual Thread Tension Assembly Rev. n . 359109-000 AGO/03 AGO/03...
  • Page 49 Service Manual Thread Tension Assembly Removal: 1. Remove the face plate and arm top cover. 2. Remove the tension mechanism shrouder (A), pulling it forward. Loose de screw (B) and pull out the tension mechanism assembly. 3. Remove the tension dial (N). 4.
  • Page 50: Motor And Motor Belt

    Service Manual Motor and Motor Belt Rev. n . 359109-000 AGO/03 AGO/03...
  • Page 51 Service Manual Motor and Motor Belt Warning: Make sure to remove the plug from wall outlet before any attempt to remove the motor. Removal: 1. Remove the free-arm extension table and all the covers. 2. Loose the motor belt tension adjustment screw (A). 3.
  • Page 52: Hook

    Service Manual Hook Rev. n . 359109-000 AGO/03 AGO/03...
  • Page 53 Service Manual Hook Removal: 1. Remove the free-arm extension table, all the covers, the needle plate and the bobbin case. 2. Remove feed dog screws (F) and feed dog (E). 3. Remove position plate screws ( I ) and (K). 4.
  • Page 54: Feed Lifting Lever Assembly

    Service Manual Feed Lifting Lever Assembly For models 2722/32/24/30 Rev. n . 359109-000 AGO/03 AGO/03...
  • Page 55 Service Manual Feed Lifting Lever Assembly (For models 2722 / 2732 / 2724 / 2730) Removal: 1. Set feed regulator dial at number “5” (maximum stitch lenght). 2. Turn handwheel toward the front of the machine to bring the feed dog to its furthest rear position.
  • Page 56 Service Manual Feed Lifting Lever Assembly For models 2712/18 Rev. n . 359109-000 AGO/03 AGO/03...
  • Page 57 Service Manual Feed Lifting Lever Assembly (For models 2712 / 2718) Removal: 1. Set feed regulator dial at number “5” (maximum stitch lenght). 2. Turn handwheel toward the front of the machine to bring the feed dog to its furthest rear position.
  • Page 58: Feed Rock Shaft Assembly

    Service Manual Feed Rock Shaft Assembly Rev. n . 359109-000 AGO/03 AGO/03...
  • Page 59 Service Manual Feed Rock Shaft Assembly Removal: 1. Remove the free-arm extension table, all the covers, the needle plate, the feed dog, the feed lifting lever assembly (N), the hook pulley (K) and the belt (M). 2. Remove the 10 mm nut (H) and eccentric hinge screw ( I ). 3.
  • Page 60: Feed Forked Connection

    Service Manual Feed Forked Connection Rev. n . 359109-000 AGO/03 AGO/03...
  • Page 61 Service Manual Feed Forked Connection Removal: 1. Remove the free-arm extension table, all the covers, the stitch length and buttonhole control assembly (see pages 66-67) and the handweel. 2. Remove screw nut ( I ) and the eccentric screw (H). 3.
  • Page 62: Vertical Shaft Bevel Gear

    Service Manual Vertical Shaft Bevel Gear ILLUSTRATION "M" Rev. n . 359109-000 AGO/03 AGO/03...
  • Page 63 Service Manual Vertical Shaft Bevel Gear Removal: 1. Remove the free-arm extension table, al the covers, needle bar, face plate mounting bracket, needle threadr, needle bar vibrating bracket, the stitch lenght and buttonhole control assembly, the thread take-up assembly, the disc stack shaft gear and bracket assembly, and the handwheel.
  • Page 64 Service Manual Vertical Shaft Rev. n . 359109-000 AGO/03 AGO/03...
  • Page 65 Service Manual Vertical Shaft Removal: 1. Remove the free-arm extension table, all the covers, needle bar, needle threader, needle bar vibrating bracket, face plate and lam mounting plate, the stitch length and buttonhole control assembly, the thread take-up lever assembly, the disc stack shaft gear and bracket assembly, the handwheel and the vertical shaft bevel gear.
  • Page 66: Stitch Lenght And Buttonhole Control Assembly

    Service Manual Stitch Length and Buttonhole Control Assembly Rev. n . 359109-000 AGO/03 AGO/03...
  • Page 67 Service Manual Stitch Length and Buttonhole Control Assembly Removal: 1. Remove the fre-arm extension table, all the covers and the cam controlled feed mechanism. 2. Set the stitch length and buttonholer control assembly dial at buttonhole position. 3. Remove retaining ring (A). 4.
