Micro B-58 Assembly
and Setup Manual


Specifications
Recommended Power System
Wingspan
12"
RX/ESC/Servo
Spektrum AR6400 (or similar)
Overall Length
17.28"
Parkzone P-51 Motor & Gearbox (PKZ3624)
2
Wing Area
70.7 in
Motor
or
Flying Weight
1.3oz
Hobbyzone Champ Motor & Gearbox (HBZ4930)
Intended Use
Indoor/Calm Winds
Battery
160mAh 1S 3.7V 25C LiPo (or similar)
Revised 2014-09-27


Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Micro B-58 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sawn Craft Micro B-58

  • Page 1   Micro B-58 Assembly and Setup Manual     Specifications Recommended Power System Wingspan 12” RX/ESC/Servo Spektrum AR6400 (or similar) Overall Length 17.28” Parkzone P-51 Motor & Gearbox (PKZ3624) Wing Area 70.7 in Motor Flying Weight 1.3oz Hobbyzone Champ Motor & Gearbox (HBZ4930)
  • Page 2     Thank you from Sawn Craft.  Thank you for purchasing the Sawn Craft Micro B‐58 aircraft. Like the full‐scale USAF B‐58, in your hands  is a remarkably versatile airplane designed to deliver a pleasure cruiser with an incredible look. The  lightweight and rigid EPS and carbon construction makes it possible for you to experience a wide  performance envelope. This means that no matter how you like to fly, you’ll enjoy both stability and  maneuverability without any sacrifice in precision or control feel.  Your Sawn Craft Micro B‐58 aircraft represents the benchmark of ultra‐micro performance and aerobatic  versatility.  All you have to do next is read and apply the information presented in this instruction  manual.  I sincerely hope that you enjoy your model as much as we do!  If you have any troubles with these  instructions or in the setup of your model feel free to contact us and we will provide you with the    service you expect from a hobbyist‐owned and operated business.   Jonathan Sawn  Owner, Sawn Craft  Jonathan@Sawn‐Craft.com ...
  • Page 3: Table Of Contents

    Table of Contents   1 Introduction  1  1.1 Style Conventions  1  1.2 Required Tools & Supplies  1  1.3 Required Parts for Completion   2  1.4 Included Parts Description   3    2 Assembly Instructions  4    2.1 Fuselage Lamination  4    2.2 Wing Reinforcement Lamination  5    2.3 Elevator/Elevon & Rudder Hinging  6    2.4 Skid Installation  9    2.5 Fuselage Installation  10    2.6 Vertical Stabilizer Installation  11    2.7 Electronics Installation  12  3 Setup and Tuning  14   ...
  • Page 4: 1 Introduction

    Sawn Craft Micro B‐58 Manual  1 Introduction The contents of this manual assume the operator will have the following prerequisites:  • Understanding of all appropriate safety procedures and requirements  • The ability to follow written procedures and possess basic hobby building skills  1.1 Style Conventions Below are the important style conventions that will be used throughout the guide.   Note: Key points or hints for success will be formatted in this manner.  Warning: Any area that poses either a physical hazard or the danger will be formatted in this manner.    Arrows inform where to click or to perform the specified operation.    Circled items inform of items of interest for the specified operation.  Circled items will typically be  accompanied by text further identifying the region of interest.    1.2 Required Tools & Supplies The list below contains all of the required tools and supplies that are required for the assembly and  tuning of this model.  • Clean, flat work surface  • #11 hobby knife   • Straight‐edge ruler  • Soldering iron & solder  • Heat gun  • Wire cutters  • Needle nose pliers ...
  • Page 5: Required Parts For Completion

    Sawn Craft Micro B‐58 Manual  Sawn Craft recommends the use of Beacon Foam‐Tac adhesive and 3M Blenderm Hinge Tape for the  construction of this model due to its strength, light weight, and easy use.  Both Blenderm and Foam‐ Tac can be purchased by visiting the Building Supplies tab on Sawn‐Craft.com  1.3 Required Parts for Completion This model was designed with the intention of putting to use the electronics that are used in today’s  popular 1S LiPo‐powered Ultra‐Micro aircraft.  Once you have worn out the airframe on your  Hobbyzone© Champ or Parkzone© UM P‐51 Mustang, simply remove the electronics and use them to  power this model.  If you choose to purchase your power system components separately, Sawn Craft  does offer the Micro Electronics Kit that includes every part of the power system that you need. The list  below contains all of the required and recommended parts for the successful operation of this model.  • 1S LiPo “Brick”  • Ultra‐Micro Motor and Gearbox  • 5x3 Propeller (or similar)  • 1S LiPo Battery  Please note that other power systems and components may be compatible and may work without  issue, but the listed components have been used successfully by Sawn Craft.  Optional Parts for Completion To make your build easier and ensure the nicest looking finished product, the following products are  offered on Sawn Craft.com.  See the Building Supplies tab for these products.  • Colored Packing Tape  • Micro Electronics Kit    Page 2    140927 Micro B‐58 Manual.docx ...
  • Page 6: Included Parts Description

    Sawn Craft Micro B‐58 Manual  1.4 Included Parts Description Please inspect your kit and ensure that all listed parts are present and undamaged. If you find missing  parts or signs of damage please contact Support@Sawn‐Craft.com for assistance.  Main Wing  KFm Step  Fuselage Half (2 each)  Vertical Stabilizer (Elevon)  Vertical Stabilizer (Rudder/Elevator)  Left Elevator Half/Elevon  Right Elevon  Right Elevator Half  Skid/Engines (4 each)  Component Bag:  Micro Control Horn (4 each)  1” 0.024” Control Wire with Z‐Bend (4 each)  5” 0.024” Elevator Joiner Wire  3" 0.051" Carbon Rod  4” 0.051” Carbon Rod (2 each)  5” 0.051” Carbon Rod   6” 0.083” Carbon Rod   3” 2mm Heat Shrink Tube (3 each)  12” Micro Wire  i  d  e    b  a  h  c  f  g  Page 3    140927 Micro B‐58 Manual.docx ...
  • Page 7: 2 Assembly Instructions

    Sawn Craft Micro B‐58 Manual  2 Assembly Instructions The order of assembly presented in this instruction has been tested and it is recommended that you  do not differ from them to provide the most accurate and easiest assembly possible.  2.1 Fuselage Lamination • Parts Required:  o Fuselage Half (2 each)  o 6” 0.083” Carbon Rod    Lay both fuselage halves flat on the table with the recessed slot facing up.  Press the carbon rod  into the foam on the recessed slots to enlarge the slot.   Apply a bead of glue around the entire perimeter of one of the fuselage halves.  Press the unglued fuse half onto the glued fuse half, recessed slots facing each other, and gently  slide the parts around to spread the glue evenly.    Separate the two fuse halves and insert the carbon rod into one of the recessed slots.  Rejoin the two fuse halves, glue side toward each other, ensuring that the carbon rod already in  the slot aligns with the recessed slot on the other fuse half.  Set the assembled fuse lamination  aside to allow the glue to cure.  If desired you can place a flat weight (book, etc.) on top of the  lamination while curing to ensure a flat assembly.   Once cured, sand leading edges to round them to your liking.       Page 4    140927 Micro B‐58 Manual.docx ...
  • Page 8: Wing Reinforcement Lamination

    Sawn Craft Micro B‐58 Manual  2.2 Wing Reinforcement Lamination • Parts Required:  o Main Wing  o KFm Step  o 4” 0.051” Carbon Rod (2 each)    Lay the main wing on the table with the diagonal carbon rod location markings slot facing up.   Press the carbon rod into the recessed slots to enlarge them slightly if necessary.  Apply a bead of  glue around the entire perimeter of the KFm Step.  Press the glued side of the KFm onto the Main Wing with the carbon rods in place, aligning the  leading edges of both parts, and gently slide the parts around to spread the glue evenly.    Set the assembled wing lamination aside to allow the glue to cure.  If desired you can place a flat  weight (book, etc.) on top of the lamination while curing to ensure a flat assembly.  Once cured, sand the leading edges to your liking.    Page 5    140927 Micro B‐58 Manual.docx ...
  • Page 9: Elevator/Elevon & Rudder Hinging

    Sawn Craft Micro B‐58 Manual  2.3 Elevator/Elevon & Rudder Hinging • Parts Required:  o Right Elevator Half   o Left Elevator Half  o Elevator Joiner Wire  o Vertical Stabilizer   o Micro Control Horn (2 each)  o Main Wing  or  o Elevon (2 each)  o Micro Control horn (2 each)  o Main Wing    Elevator/Rudder Setup  Warning: This process involves using extremely sharp cutting blades. Care must be taken to avoid injury.  Lay the elevator halves on the table with the leading edge facing yourself and the widest parts  nearest each other.  Use a straight edge ruler and a hobby knife or a sanding block to cut an  approximate 45° bevel into the leading edge of the control surface.   Bend two 90‐degree bends into the Elevator Joiner wire 1” from each end, making a U‐shape with  the middle 3” long.  Ensure the short sides are parallel to each other; if not, bend the wire so they  are.  Press the short ends of the joiner wire into the beveled end of the elevator halves at the small  notches cut into the elevator halves. Glue the wire to the elevator halves and use small pieces of  tape over the slot to secure.       ...
  • Page 10 Sawn Craft Micro B‐58 Manual  Lay the vertical stabilizer on the table with the bottom facing you.  Carefully crack the rudder along  the rudder line or use a straight edge ruler and a hobby knife to cut down the rudder cut line in  order to separate the rudder.                Lay the rudder on the table with the leading edge facing you.  Use a straight edge ruler and a  hobby knife to cut an approximate 45° bevel into the leading edge of the control surface, ensuring  that the bevel is on the correct side.    If you choose to use a glue hinge for your surfaces ensure you bevel the mating surface as well.   Place the vertical stabilizer and rudder back together with trailing and leading edges touching,  oriented the proper direction for the bevel to face to the left when installed.  Cut approx. ¼” x 1”  pieces of hinge tape.  Use two of these small pieces of tape to attach the smooth sides of the  rudder and vertical stab together.  Dry fit a micro control horn into the slot, ensuring that the hinge  bevel is facing down.  Set assembly aside.        Tape hinge          Place the elevator and main wing together with trailing and leading edges touching, oriented such  that the hinge bevel faces down when the KFm Step is facing up.  Use two small pieces of tape on  each elevator half to attach the smooth sides of the elevator halves and main wing together.    Page 7    140927 Micro B‐58 Manual.docx ...
  • Page 11 Sawn Craft Micro B‐58 Manual                Elevon Setup  Lay the elevons on the table with the leading edge facing yourself and the wide part of the elevons  on the outside.  Use a straight edge ruler and a hobby knife or a sanding block to cut an  approximate 45° bevel into the leading edge of the control surface, ensuring that you have both a  left and right elevon.  Dry fit a micro control horn into the slots, ensuring that the hinge bevel is  facing down.  Note: Ensure you use the elevons with a slot in each for the control horn.                Place the elevon and main wing together with trailing and leading edges touching, oriented such  that the hinge bevel faces down when the KFm Step is facing up.  Use two small pieces of tape on  each elevon to attach the smooth sides of the elevon and main wing together.    This is an ideal time to paint or decorate the parts as they are still flat and will be easier to handle.      Page 8    140927 Micro B‐58 Manual.docx ...
  • Page 12: Skid Installation

    Sawn Craft Micro B‐58 Manual  2.4 Skid Installation • Parts Required:  o Main Wing Assembly  o Skid (4 each)    Lay the main wing assembly on the table with the KFm step facing down.  Apply a bead of glue  down the entire length of the top of the skid.              Press the glued side of the skid onto the Main Wing, aligning the slots on the wing with the tabs on  the skids, and gently press the parts together to spread the glue evenly.  Allow glue to cure before  proceeding.      Slot                    Page 9    140927 Micro B‐58 Manual.docx ...
  • Page 13: Fuselage Installation

    Sawn Craft Micro B‐58 Manual  2.5 Fuselage Installation • Parts Required:  o Main Wing Assembly  o Fuselage Assembly    Apply a bead of glue down the entire length of the flat spot on the top rear of the fuselage  assembly.  Also apply glue on the inside edges of the main wing assembly fuselage slot.  Press the glued side of the fuselage assembly onto the main wing assembly, sliding the fuse all the  way back, and gently slide the parts back and forth to spread the glue evenly.  Check that the front  of the wing that is glued to the side of the fuse is straight and even on both sides of the fuse.  Allow  glue to cure before proceeding.        Glue              Page 10    140927 Micro B‐58 Manual.docx ...
  • Page 14: Vertical Stabilizer Installation

    Sawn Craft Micro B‐58 Manual  2.6 Vertical Stabilizer Installation • Parts Required:  o Main Wing Assembly  o Vertical Stabilizer Assembly  o 5" 0.051" Carbon Rod    Apply a bead of glue down the entire length of the bottom of the vertical stabilizer assembly.  Press  the glued vertical stab assembly onto the top of the main wing assembly onto the proper slots,  ensuring that the stab sits evenly on the wing.  Allow the glue to cure fully prior to proceeding.    If building your model with a rudder: Secure the push rod z‐bends to the 5" carbon rod by using  glue and heat shrink tube.  Glue one rudder joiner control horn and dry fit the other.  Adjust the  control rod length and then shrink the heat shrink tube to “lock” the z‐bend wire in place to ensure  that the rudder is straight with the vertical stabilizer.  Once the rod length is set, attach the  unglued control horn to the z‐bend and then glue the assembly in place.                                Page 11    140927 Micro B‐58 Manual.docx ...
  • Page 15: Electronics Installation

    Sawn Craft Micro B‐58 Manual  2.7 Electronics Installation • Parts Required:  o Complete Model Assembly  o RX/ESC/Servo “Brick”  o Motor & Gearbox w/Prop  o 12” Micro Wire  o 1/16” Heat Shrink Tube  o Hook and loop material  The steps for this part of the assembly are the same for multiple models so even though the photos  may not be for your model, the instruction is correct.  Use the photos for reference.  Glue the RX/ESC/Servo “Brick” on the top of the main wing at the location marked by a square, just  behind the prop slot.  Ensure that the servo gears are facing forward and the brick and all wires are  completely clear of the prop.                Cut the motor and battery wires approximately in the center.  Strip the insulation off the wire  about 1/8” and tin the wires.  Strip and tin one end of the micro wire as well.  Cut pieces of shrink  tube to cover the exposed wires.  Slide the shrink tube onto the wires leading to the motor.  Solder  the micro wire to the motor wire ends, matching polarity.  Once soldered, slide the shrink tube  over the completed solder joint and use a heat gun to shrink the tubes.  Warning: This process involves using soldering equipment that is extremely hot. Extreme caution must  be taken      Page 12   ...
  • Page 16 Sawn Craft Micro B‐58 Manual  Dry fit the motor onto the top of the main wing by inserting the motor mounting pins into the pre‐ cut alignment holes/dots in the wing with the prop located inside the open slot.  Route the motor  wires around the slot and to the brick and cut the micro wire to the proper length.  Solder the  motor plug onto the micro wire and cover with heat shrink tube.  Use small pieces of clear packing  tape or glue to secure the motor wires around the slot.  Plug the completed, longer motor wire  into the brick.          Alignment Holes      Use glue to secure the motor to the airframe.  Let glue cure fully before proceeding. Secure all  loose wires with tape or glue around the prop slot to ensure it is not damaged by the prop.                Attach a piece of hook and loop material to the side of the fuse, under the canopy for battery  mounting and adjustment.  Secure the push rod z‐bends to the remaining carbon rods by using glue and heat shrink tube.  If  you choose to use elevons you will need to cut the 5" carbon rod down to 3" to match the other.   Adjust the control rod length and then shrink the heat shrink tube to “lock” the z‐bend wire in  place to ensure that the elevator and rudder are straight with the main wing and vertical stabilizer.   Once the rod length is set, install the control rods to the brick and control horns then attach the  unglued control horn to the z‐bend and then glue the assembly in place.      Page 13    140927 Micro B‐58 Manual.docx ...
  • Page 17: 3 Setup And Tuning

    Sawn Craft Micro B‐58 Manual  3 Setup and Tuning 3.1 Center of Gravity The CG of this plane is located approximately ½” in front of the prop slot and is marked by a slot cut in  the foam on the main wing.  Moving the CG fore and aft will dramatically change the handling of the  plane so adjust to your liking.  An aft CG will allow for slow, high‐alpha flight while a more fore CG will  provide a faster flight experience.  Use the included hook and loop fastener to adjust the fore/aft  location of the battery to adjust the CG without adding additional weight.  3.2 Control Throws & Expo By altering the amount of control throw the surfaces have you can fine‐tune the handling and  performance.  Below are the recommended settings as tested that will provide a successful flying  experience.  Throws are measured at the point farthest from the hinge.  Control Surface Low Rate Throw Low Rate Expo High Rate Throw High Rate Expo Elevator  1/2in  20%  3/4in  35%  Rudder  5/16in  20%  3/8in  35%  Elevon  1/4in  30%  3/4in ...
  • Page 18: Flying Tips

    Sawn Craft Micro B‐58 Manual  3.4 Flying Tips This aircraft is designed to fly in the space as small as a single basketball court.  Being such light weight,  it is recommended that this aircraft be flown indoors or outdoors in calm wind conditions.  Always  ensure that you are comfortable with the aircraft and its flight characteristics prior to flying in a small  venue.  If you want to fly slower, choose the rudder/elevator version.  If you'd like to fly more  aerobatically, pick the elevons.  Never fly over people or animals.  This aircraft flies much “bigger” than it really is and the techniques of flying larger aircraft apply.  Rudder  turns will bank the aircraft so elevator will need to be added to maintain altitude.  The delta‐wing design  is inherently stable and makes this model a pure joy to fly!  This model can fly slowly in high alpha flight,  but when you drop the nose it is remarkably quick and nimble.  Landing the aircraft is simple; keep some  throttle applied and as the plane nears the ground, pull back on the elevator to flare.  3.5 Decorating/Finishing The beauty of this aircraft is that you have the opportunity to finish it with the look that you desire.  We  recommend using colored packaging tape (available on the Building Supplies tab) for decorating as it is  easy to use, lightweight, and provides a nice, glossy finish.  Water‐based paints have been used with  success in the past as have permanent markers.  Prior to using any paints or markers, test on a scrap  piece of foam to ensure that it doesn’t melt the foam.    Remember that any weight you add to the airframe will affect its performance so keep heavy  applications of paint and decals to a minimum.  3.6 Repairs & Spare Parts Due to this models extremely light weight, it is surprisingly durable!  If a part of the model is damaged it  can typically be repaired using small pieces of packaging tape or by gluing using Beacon Foam Tac.    If a part is damaged beyond repair, simply send us an email at Support@Sawn‐Craft.com as we have  replacement parts for purchase.  Page 15    140927 Micro B‐58 Manual.docx ...
