Sawn Craft Micro F-22 Assembly And Setup Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Micro F-22 Assembly
and Setup Manual
Specifications
Recommended Power System
Wingspan
12"
RX/ESC/Servo
Spektrum AR6400 (or similar)
Overall Length
17.28"
Parkzone P-51 Motor & Gearbox (PKZ3624)
2
Wing Area
66.86 in
Motor
or
Flying Weight
1.2oz
Hobbyzone Champ Motor & Gearbox (HBZ4930)
Intended Use
Indoor/Calm Winds
Battery
160mAh 1S 3.7V 25C LiPo (or similar)
Revised 2013-11-05

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Micro F-22 and is the answer not in the manual?

Questions and answers

Related Manuals for Sawn Craft Micro F-22

Summary of Contents for Sawn Craft Micro F-22

  • Page 1 Micro F-22 Assembly and Setup Manual Specifications Recommended Power System Wingspan 12” RX/ESC/Servo Spektrum AR6400 (or similar) Overall Length 17.28” Parkzone P-51 Motor & Gearbox (PKZ3624) Wing Area 66.86 in Motor Flying Weight 1.2oz Hobbyzone Champ Motor & Gearbox (HBZ4930)
  • Page 2 Thank you from Sawn Craft. Thank you for purchasing the Sawn Craft Micro F-22 aircraft. Like the full-scale USAF F-22, in your hands is a remarkably versatile airplane designed to deliver a pleasure cruiser with an incredible look. The lightweight and rigid EPS and carbon construction makes it possible for you to experience a wide performance envelope.

  • Page 3: Table Of Contents

    Table of Contents 1 Introduction 1.1 Style Conventions 1.2 Required Tools & Supplies 1.3 Required Parts for Completion 1.4 Included Parts Description 2 Assembly Instructions 2.1 Fuselage Lamination 2.2 Wing Reinforcement Lamination 2.3 Elevator/Elevon & Rudder Hinging 2.4 Skid Installation 2.5 Fuselage Installation ARF &...

  • Page 4: Introduction

    Sawn Craft Micro F-22 Manual 1 Introduction The contents of this manual assume the operator will have the following prerequisites:  Understanding of all appropriate safety procedures and requirements  The ability to follow written procedures and possess basic hobby building skills 1.1 Style Conventions...

  • Page 5: Required Parts For Completion

    Sawn Craft Micro F-22 Manual Sawn Craft recommends the use of Beacon Foam-Tac adhesive and 3M Blenderm Hinge Tape for the construction of this model due to its strength, light weight, and easy use. Both Blenderm and Foam- Tac can be purchased by visiting the...

  • Page 6: Included Parts Description

    Sawn Craft Micro F-22 Manual 1.4 Included Parts Description Please inspect your kit and ensure that all listed parts are present and undamaged. If you find missing parts or signs of damage please contact Support@Sawn-Craft.com for assistance. Main Wing KFm Step...

  • Page 7: Assembly Instructions

    Sawn Craft Micro F-22 Manual 2 Assembly Instructions The order of assembly presented in this instruction has been tested and it is recommended that you do not differ from them to provide the most accurate and easiest assembly possible. 2.1 Fuselage Lamination ...

  • Page 8: Wing Reinforcement Lamination

    Sawn Craft Micro F-22 Manual 2.2 Wing Reinforcement Lamination  Parts Required: o Main Wing o KFm Step Lay the main wing on the table with the front-to-back vertical stabilizer location markings slot facing up. Apply a bead of glue around the entire perimeter of the KFm Step.

  • Page 9: Elevator/Elevon & Rudder Hinging

    Sawn Craft Micro F-22 Manual 2.3 Elevator/Elevon & Rudder Hinging  Parts Required: o Elevator o Vertical Stabilizer (2 each) o Micro Control Horn (4 each) o Main Wing o Elevon (2 each) o Micro Control horn (2 each) o Main Wing Elevator/Rudder Setup Warning: This process involves using extremely sharp cutting blades.
  • Page 10 Sawn Craft Micro F-22 Manual Lay the vertical stabilizers on the table with the bottoms facing you with the rudder cut lines nearest each other. Carefully crack the rudder along the rudder line or use a straight edge ruler and a hobby knife to cut down the rudder cut lines in order to separate the rudders. Remove the lower rudder extension below the control horn slots using the same technique.
  • Page 11 Sawn Craft Micro F-22 Manual Place the vertical stabilizers and rudders back together with trailing and leading edges touching, oriented the proper direction for the bevels to face away from each other when installed. Cut approx. ¼” x 1” pieces of hinge tape. Use two of these small pieces of tape to attach the smooth sides of the rudder and vertical stab together.

  • Page 12: Skid Installation

    Sawn Craft Micro F-22 Manual Elevon Setup Lay the elevons on the table with the leading edge facing yourself and the wide part of the elevons on the outside. Use a straight edge ruler and a hobby knife or a sanding block to cut an approximate 45°...

  • Page 13: Vertical Stabilizer Installation

    Sawn Craft Micro F-22 Manual 2.5 Fuselage Installation  Parts Required: o Main Wing Assembly o Fuselage Assembly Apply a bead of glue down the entire length of the flat spot on the top rear of the fuselage assembly. Also apply glue on the inside edges of the main wing assembly fuselage slot.
  • Page 14 Sawn Craft Micro F-22 Manual Apply a bead of glue down the entire length of the beveled bottom of the vertical stabilizer assembly. Press the glued vertical stab assemblies onto the top of the main wing assembly onto the proper location lines, ensuring that the hinge bevel faces away from the center of the model.
  • Page 15 Sawn Craft Micro F-22 Manual 2.7 Electronics Installation  Parts Required: o Complete Model Assembly o RX/ESC/Servo “Brick” o Motor & Gearbox w/Prop o 12” Micro Wire o 1mm Heat Shrink Tube o Hook and loop material Glue the RX/ESC/Servo “Brick” on the top of the main wing at the location marked by a square, just behind the prop slot.
  • Page 16 Sawn Craft Micro F-22 Manual glue to secure the motor wires around the slot. Plug the completed, longer motor wire into the brick. Install the prop with the numbers facing forward. Use glue to secure the motor to the airframe. Let glue cure fully before proceeding. Secure all loose wires with tape or glue around the prop slot to ensure it is not damaged by the prop.

  • Page 17: Setup And Tuning

    Sawn Craft Micro F-22 Manual 3 Setup and Tuning 3.1 Center of Gravity The CG of this plane is located approximately ½” in front of the prop slot and is marked by a slot cut in the foam on the main wing. Moving the CG fore and aft will dramatically change the handling of the plane so adjust to your liking.

  • Page 18: Flying Tips

    Sawn Craft Micro F-22 Manual 3.4 Flying Tips This aircraft is designed to fly in the space as small as a single basketball court. Being such light weight, it is recommended that this aircraft be flown indoors or outdoors in calm wind conditions. Always ensure that you are comfortable with the aircraft and its flight characteristics prior to flying in a small venue.
