E a s y L o a d e r
AV-4000 GSM
AV-4000 DVR
(for LED keypads)
Integrated Alarm Control panel &
Communicator Series 4000
Appendix for GSM Alarm Panels
Version 1.06
Edition II
This product is subject to continuous
enhancements and therefore specifications may
be changed or altered without prior notice
Item:
4785E_GSM (A4BKE)
Rev01: 03-Nov-2018

Advertisement

loading
Need help?

Need help?

Do you have a question about the EasyLoader 4000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for AV-GAD EasyLoader 4000 Series

  • Page 1 E a s y L o a d e r AV-4000 GSM AV-4000 DVR (for LED keypads) Integrated Alarm Control panel & Communicator Series 4000 Appendix for GSM Alarm Panels Version 1.06 Edition II This product is subject to continuous enhancements and therefore specifications may be changed or altered without prior notice Item:...
  • Page 2 The series 4000 GSM and AV-4044DVR, AV-4008DVR GSM are compatible with Av-Gad LED keypads models AV-701 and AV-702. The AV-4044, 4008 GSM are supplied with the Gismo board that is plugged into the serial RS-232 plug and connected to the integrated GSM modem.
  • Page 3 2. Hardware The AV-4044, 4008, 4009, 4016 GSM suffix are based on the AV-4044, 4008, 4009 & 4016 LED panels and supplied with the additional hardware to provide full GSM alarm panel. To identify the GSM; The Gismo PCB board (refer to fig. 1) with antenna plug located at the let-upper side in the main control panel case.
  • Page 4 GisMo wired to Alarm panel diagram Fuse -SIR +SIR AC-16-ACKEY/Z9 GisMo board is Sensitive to anti static. Prevent touching Figure 2: Gismo 95 GSM module wired to alarm panel...
  • Page 5 3. Programming GSM and Dial features To setup the panel wire the keypad model AV-701 or AV-702 (refer your panel main manual). Insert the SIM card and connect the GSM antenna Power up with AC (not with battery at first power up) Hold down key 8, enter 1 9 9 4 (programming code), P is displayed indicating you are in PROGRAM mode.
  • Page 6 Programming the Dialing and SMS phone numbers: - To enable sending SMS program address 003, enter 01 to enable - In GSM mode address 008 is not in use - Supports six Dial telephone numbers, each 16 digits, address 013 to 018 - Supports four SMS telephone numbers, each 16 digits.
  • Page 7 5. Commands 200 in programming mode Location Function 200 and 00 Display control panel type & software version 200 and 04 Erase (reset) the events history 200 and 05 Restore all codes to factory default 200 and 10 (SMS) Displays current setting LInE or Cell (SMS Mode) 200 and 11 (SMS) Sets to PSTN line (displays LInE) (PSTN SMS) 200 and 12 (SMS)
  • Page 8 6. GisMo LEDs indications Green LED Status - Indicates the GSM processor is operating. Must light Red LED Net - Indicated the GSM network status, see modes in the below table, wait while until unit registered to network. Red LED status Description Note Slow blinking every 2...
  • Page 9 Figure 4: SIM card that fits In Australia GisMo works and tested with Vodafone SIM card. 9. AV-4044, AV-4008, AV-4009, 4008DVR GSM texts The AV-4044DVR, 4008DVR models are dedicated to be used with CCTV system that includes DVR or NVR recording device, the DVR may fail form certain faults, the AV-4000 system supervised the recording device and reports ant fail by sending SMS.
