E a s y L o a d e r
AV-2004, AV-2048
Integrated Alarm Control/Communicator
Year 2000 ready
Express
Installation and Operation Manual
Version 3.06
(with very slow zone)
Edition II
This product is subject to continual enhancement and therefore
specifications may be changed or altered without prior notice
Item: 4718_2004
www.av-gad.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EasyLoader AV-2004 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AV-GAD EasyLoader AV-2004

Summary of Contents for AV-GAD EasyLoader AV-2004

  • Page 1 Integrated Alarm Control/Communicator Year 2000 ready Express Installation and Operation Manual Version 3.06 (with very slow zone) Edition II This product is subject to continual enhancement and therefore specifications may be changed or altered without prior notice Item: 4718_2004 www.av-gad.com...
  • Page 2 1. INTRODUCTION System planning When the panel reaches you it will be factory programmed. This is done for testing purposes but also can be used for installation if required without first entering to programming. This present program is referred to as ‘Factory Defaults’. This is a short format manual.

  • Page 3: Mounting The Control Panel

    2. MOUNTING THE CONTROL PANEL Refer to detailed wiring diagram. Note: ‘h’ is displayed after power-up to remind installer to set the time; ‘h’ will be removed after time setting (by using keys 0 and 1 refer to page 10). Select a mounting location as following: 1.

  • Page 4: Keypad Wiring

    When using few keypads connect them in parallel. Each keypad has four terminal wires: (+) Power, connect to + Aux. Power System Data, connect to OR (–) Power, connect to – Aux. Power System Strobe, connect to YE Panel Panel AV-GAD AV-GAD AV-GAD AV-GAD EASYLOADER AV-701 EASYLOADER AV-701 EASYLOADER AV-701...
  • Page 5 When a non-blinking ‘8’ is displayed and keys do not respond, it is an indication that the keypad is not communicating with the panel. Check wiring and polarity Wire length for each AV-701 Keypad should not exceed 100 meters (when using 0.5 mm 2 wires).

  • Page 6: Backup Battery

    Add a power supply for installation with over three LCD keypad and/or if over ten high current sensors included. Refer to Av-Gad AV-21, AV-40 power supply and charger. The 4AH–12V battery fits in the ABS box, but the door is too tight, why? Note the following: 1.

  • Page 7: Before Powering Up

    8. TELEPHONE LINE WIRING and PROGRAMMING It’s recommended to connect the control panel to an independent telephone line, if a device is in parallel with the alarm panel, this may grab the call first (like a message answer/fax) during remote up and download. Don’t connect fax or answering machine in parallel on the same telephone line.
  • Page 8 Short press access standard Keypad functions. The numbered keys (1 to 0) are used for Arming/Disarming (ON/OFF), Zone Shunt (Bypass), and other operation and programming functions. Short beep confirms each key press. A short press on the AV-701 keypad key accesses the following special functions: Chime Instant Arming.

  • Page 9: Status Display

    11. AV-2004/48 HOLD-DOWN FUNCTIONS (AV-701, AV-702 SERIES) To access the hold-down functions hold down the key for approximately 2 seconds. Holds down functions are confirmed by a prolonged beep. Hold-Down Functions: Siren SIREN TEST Key 1 Shunt Display Key 2 SHUNT DISPLAY Displays shunted zone(s).
  • Page 10 Telephone Siren then Address 092 enables ‘Answer Now‘ feature (answers remote computer after 1 ring). The user attending the control panel can reduce the number of rings before answer to one ring. To cancel the Answer Now feature hold-down 6 and hold-down 0. This feature is useful if the control panel was programmed not to answer incoming calls (programming of 21 rings or greater at address 091).
  • Page 11 XX - Event number (from 01 to 36), then HH_MM (Hour and Minutes) Event Time, Event (alarm or opening/closing). More events are reported in the PC up and download log events. Translate the display as following: ‘u’ (user number 1 to 8) ‘o’...

  • Page 12: Panic Button

    The local clock time is not stored in system memory; clock must be adjusted after power-up. System time is reset to 00:00 after power-up, ‘h’ will be displayed to remind user to set time, ‘h’ will be removed after setting new time. Shunt Shunt Display...
  • Page 13 This code is valid 30 seconds from Arming. After 30 seconds, the code is not valid. Entering code No. 8 will delete zone bypasses including auto-bypass. 3. Code number 9, Programming Code (Installer Code). This code enables entering the programming mode (system features programming) at the Installer level. The factory default programming code is ‘1 9 9 4’.
  • Page 14 To enable the DTMF control program address 074/6 “Enable remote access by telephone”, and 074 - 2 “Enable A1 activation by telephone”. Keypad online conformation and DTMF functions history When the control panel detects the first DTMF key, five short beeps sound at the keypads. The keypad activation shows the user at the remote site that a DTMF connection takes place (in case of mistaken connection or similar).

  • Page 15: User Code Programming

    [2 #] - Disarm control panel. The control panel will be disarmed. A confirmation tune followed by a "disarmed" tune will be sounded ("Disarmed" tune: Five short beeps). [31 #] - Activates A1 output for 3 seconds (enabled by programming 074-2) [6 #] - Stop dialer.
  • Page 16 4. The two left-most LEDs blink to indicate that the system is waiting for a new user code-index (user 1 to 8) to be entered. 5. Enter the code index you want to be delete (1 for code No. 1; 2 for code No. 2, etc.) 6.
  • Page 17 17. AV-2004/48 Programming Sheet Version 3.06 Factory Default Program is as shown in table; Blank Square means no default program TELEPHONES SIGNAL & AUTO ARMING TEST TIME Tel. 1 Tel. 2 Tel. 3 Tel. 4 Time Auto Arm Time (00:01) 00:00 Tel.
  • Page 18 SYSTEM FEATURES – Values marked with ( ) are the factory default programming Feature Feature Enable-Siren/Bell Test upon Arming Enable-Erase F. Me number on Disarm Enable-Keypad 3 Beeps upon Disarming Enable-Instant Arming via Key 5 Enable-Buzzer upon Entry Delay Enable-Buzzer during exit delay Enable-Keypad Tactile Beep Enable-Display Alarmed Zone during alarm Disable-4 LEDs display during Armed...
  • Page 19 COMMUNICATOR PARAMETERS TELE Receiver Reserved Handshake Data Protocol Transmit Inter MSG Wait for PHONE Format Check Format Frequency Type (Parity) Rounds Time Handshake No. 2 TELE Receiver Handshake Data Protocol Transmit Inter MSG Wait for PHONE Format Check Format Reserved Frequency Type (Parity)
  • Page 20 Restore Codes - Single Codes Restore Codes - Single Codes Z O N E S AC LB PA 142 144 146 148 158 160 162 CODES 143 145 147 149 159 161 163 CODES Restore Codes - Extended or 2 Digits Restore Codes - Extended or 2 Digits Bypassed Zones Codes - Single Codes Reserved...
  • Page 21 TEL. 3 - SUBSCRIBER ID NUMBER Group 1 Group 2 Alarm / Restore ID Alarm / Restore ID Open. / Closing ID 264 265 266 267 272 273 274 275 280 281 282 283 EASY Program EASY Program EASY Program Alarm / Restore ID Alarm / Restore ID Open.
  • Page 22 EXAMPLE 2: 1. To program zone 4 as 24H zone (in default program, this is an Instant Zone). 2. Address 024 represents the 24H zones Delay Shunt 3. Press ; current value of the address is ‘-’ (‘-’ means blank - no 24H zone is Shunt Display Delete...

  • Page 23: Answering Machine Bypass

    20. ANSWERING MACHINE BYPASS In case the alarm panel connected with fax or answering machine on the same telephone line (not recommended) enable the Answering Machine Bypass or Answer Now features (otherwise connection is impossible). To enable the feature: 1. Program 7 at address 074 2.
  • Page 24 23. CONTCAT ID FORMAT For Central Station (CS) reporting two telephone numbers are available, Tel. 2 (address 011) is main central station Tel. Number and Tel. 3 (address 012) is backup, in case Tel. 2 fails. Do not program different formats for each telephone. Contact ID Format (known also as Ademco Express) is the fastest to program and easiest to use communicator format for central station, with communication speed achieved by the DTMF signaling.
  • Page 25 COM PORT, on which your modem is installed, making sure your mouse is not on the same COM PORT. Do not use COM1 and COM3 or COM2 and COM4 simultaneously. If you cannot initialize modem, use the Auto Detect option. Av-Gad supply the proper mode, and inverter for USB computers.

  • Page 26: Wiring Diagram

    WARNING: Auxiliary Power Output Regulated 13.8V. Observe To prevent electrical maximum current-0.8A, combined shock, disengage the Battery keypad and Aux. System and disconnect the AV-GAD SIREN FUSE AV-2004 telephone line before 1.25A +BATT- servicing this unit. RS-232 adapter -SIR +SIR...
  • Page 27 Addendum: Technical Specifications AV-2004 and AV-2048 Operating Temperature -10 C to 60 C Relative Humidity 80% maximum Input AC Power 16V AC Step-Down Transformer 1.2A Dynamic Inner Memory EEprom Auxiliary Power Output 13.8 Volts +/- 5%, Regulated Short & Overload circuit protection Siren Output Siren or Bell Selectable Bell Mode: 13.6V DC - 0.5A...

  • Page 28: Av-Gad Limited Warranty

    Av-Gad is not an insurer of either the property or safety of the user’s employees, family, or 3rd part and limits its liability for any loss or damage including incidental or consequential damages to Av-Gad original selling price of the product regardless of the cause of such a loss or damage.
