AV-GAD EasyLoader AV-4044 Installation And Operation Large Manual

Integrated alarm control panel & communicator 8 zones for lcd keypads, pstn sms enabled
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
E a s y L o a d e r
AV-4044, 4008 Pro
AV-4009 Dublo
AV-4016 Dublo
(for LCD keypads)
Integrated Alarm Control panel &
Communicator 8 zones
PSTN SMS Enabled
Installation and Operation Large Manual
Version 1.05 Preliminary
Edition I
This product is subject to continuous enhancements and therefore
specifications may be changed or altered without prior notice
Item:
4764E (A3BKE)
Rev 03: 04-May-2018
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EasyLoader AV-4044 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AV-GAD EasyLoader AV-4044

Summary of Contents for AV-GAD EasyLoader AV-4044

  • Page 1 E a s y L o a d e r AV-4044, 4008 Pro AV-4009 Dublo AV-4016 Dublo (for LCD keypads) Integrated Alarm Control panel & Communicator 8 zones PSTN SMS Enabled Installation and Operation Large Manual Version 1.05 Preliminary Edition I This product is subject to continuous enhancements and therefore specifications may be changed or altered without prior notice Item:...

  • Page 2: Table Of Contents

    Table of contents Introduction series AV-4000 LCD keypads ............4 Tips to first time installer..................4 Revision changes ....................5 Keypad AV-707 short description ..............5 2. Wiring devices to the panel .................7 2.1 Zone Wiring....................7 2.2 AV-4016 AV-4009 EOL Zone Wiring ............8 2.3 Zone Wiring AV-4008 ..................
  • Page 3 7. New address Series 4000 ...................32 7.1 Systems parameters address ..............32 7.2 Telephone and SMS address ..............32 7.3 Events reported by the SMS module ............33 7.4 Dialer reporting Programming locations............35 8. Programming Sheet AV-4000 Dublo Version 1.05..........36 9.

  • Page 4: Introduction Series Av-4000 Lcd Keypads

    The alarm model suffix indicates the keypads compatibility: PRO is for LCD keypad; Dublo is for LCD keypad and are expandable alarm panels. AV-4044 PRO, AV-4008 PRO, AV-4009 & AV-4016 Dublo are compatible with Av-Gad LCD keypads (AV-705, AV-706, AV-707).

  • Page 5: Revision Changes

    Revision changes Date Version Contains 05-Apr-2014 1.00 First published 02-Jan-2015 1.10 Added features 14-Oct-2015 1.10 Updated programming table 10-May-2018 Added software version check procedure Keypad AV-707 short description F i g u r e 1 : A V - 7 0 7 L C D k e y p a d d e s c r i p t i o n Common Terms in this Manual ...
  • Page 6 Standard Keypad functions are accessed by pressing keys (short press). The 1 to 0  keys used for Arming/Disarming (ON/OFF), Zone Shunt (Bypass) and other programming functions. A short beep confirms each key press.  A short press on keypad key accesses the following special functions: Chime Instant Arming, by pressing key ‘5’...

  • Page 7: Wiring Devices To The Panel

    An EOL zone will report Tamper alarm in case of zone shorting (if it has been EOL programmed). For connecting N.O. zones, programming is required, refer to address 304. Do not connect few sensors to one zone in EOL mode. Colors Colors Av-Gad Panel 4.7K 2.2K Yellow Purple 2.2K Resistor...

  • Page 8: Av-4016 Av-4009 Eol Zone Wiring

    –V. Connect two wires to the same terminal, one wire in series with the 2.2.K resistor and the sensor contacts (relay), the other wire in series with 4.7K resistor and other contacts. Av-Gad 3000 Series panel Colors Colors 4.7K...

  • Page 9: Zone Wiring Av-4008

    2.3 Zone Wiring AV-4008 Your system provides two ways of zone wiring: None EOL resistor loop (factory default), EOL resistor loop only for zone 4 and 8. The EOL loop protects the zone lines against tampering. In AV-4008 zone 4 and/or zone 8 are capable being an EOL zone by setting the PCB jumpers as the table below show.

  • Page 10: Av-816 Expander Av-4016, Av-208 For Av-4009

    BAT. FUSE R102 R101 +12V -12V AV-GAD AV816 Figure 2.5: Sixteen Zone AV-816 Expander W iring Mounting Place the AV-816 board on the left side of the AV-4016 board as the drawing shows. Use two screws to tighten the AV-816.
  • Page 11 When using few keypads connect them in parallel. Each keypad has four terminal wires:  (+) Power, connect to + Aux. Power  System Data, connect to OR  (–) Power, connect to – Aux. Power  System Strobe, connect to YE F i g u r e 2 .

  • Page 12: Siren Wiring

    The control panels (AV-4009, AV-4016) contains dual siren outputs, each protected by Electronic Fuse. It's highly recommended to use Av-Gad Bella Sirens to prevent inference and problems caused by unknown sirens. Siren should be outdoor type with a 12V DC, 0.7A or optional (requires programming) speaker siren with minimum power of 15W, 8 Ohms Impedance.

  • Page 13: Remote Indication Terminals

    Siren configuration programming address Address Feature Explanation Siren test/beep upon arming Sounds a short beep to indicate arming Bell mode Send 12V DC to drive the siren Self contained siren Send 12V at idle, drop to zero V at alarm Siren 3 beeps when disarm by Sounds short...

  • Page 14: Remote Indications Testing

    2.9 Remote Indications Testing To test the remote indication outputs without entering to alarm mode; enter to programming mode (hold down 8, enter 1994, followed by #). Testing ON output, enter 200 than 30 to enable, 200 than 31 to disable Testing A1 output, enter 200 than 32 to enable, 200 than 33 to disable To quit programming mode enter 999 than #.

  • Page 15: Telephone Line And Central Station

    Solar Panel Polarity SL2032 +Positive +Positive -Negative -Negative Wires box 5017TER At SL2032 DC source Notice polarity F i g u r e 2 . 1 0 : W i r i n g p o w e r s u p p l y a n d s o l a r p a n e l 3.

  • Page 16: Svm - Synthesized Voice Module (Svm-40 And Svm-42)

    Analog line; connect the Analog line of the ISDN to the panel TEL-LINE terminal. If the PSTN is DSL/ADSL type connect a dedicated lien filter supplied by local Telecom Company, or Av-Gad AV03 high end ADSL filter. If GSM module is required: Use high end unit like AVG-13, AVG-16. Cut the jumper at the PCB, located at the right-lower side of the PCB, see drawing at wiring diagram.

  • Page 17: Telephone Line Test

    When Answering Machine Bypass enabled, the control panel will answer at first ring if: - There was a pause of at least 10 seconds from last ring - The panel already counted at least three rings before the pause - Number of rings to answer (at address 091) is less than 20 Notice: The panel will answer (in a normal mode) if there is no pause and the rings counted exceed (or equal) the number programmed at 091.

  • Page 18: Remote Dtmf And Remote Arming

    Specify the COM PORT, on which your modem is installed, making sure your mouse is not on the same COM PORT. Do not use COM1 and COM3 or COM2 and COM4 simultaneously. If you cannot initialize modem, use the Auto Detect option. Av-Gad supplies the proper mode, and inverter for USB computers.

  • Page 19: Remote Access Via Dtmf

    For Arming/Disarming via Wireless Radio Remote, connect receiver's relay to ‘KE’ and ‘- Aux. Power’ terminals. Verify the receiver relay mode, momentary, or latch, and set system accordingly. In most cases the Key terminal is applicable for emergency Disarming – Short the key terminal to -V.

  • Page 20: Dtmf Commands

    When the call ends, the three short beeps sound at the keypads. When the user code is in process, the keypad display shows a line for each code number entry (disclose the code), then each DTMF number pressed show the received number. History log: Each call, confirmed by a valid user code, is recorded in the events history.

  • Page 21: System Codes

    Note that if the user answered a call from the panel or called the panel during a dialing period without Arming/Disarming/Stopping the dialer, the dialer will restart the cycle from the beginning. [7 #] - Check control panel status. The control panel will answer with an Armed or Disarmed tune followed by an Alarm tune if it is in an alarm condition.

  • Page 22: Sms And Dialer Number Entry By User

    In user programming mode user is able to: Set clock, set SMS and dialer number (not CS numbers), and change user codes 01 to 32. 1. Hold down key Program 2. While the four LEDs are blinking, enter code No. 1 (factory default 1 2 3 4) 3.

  • Page 23: Restore Default Codes

    To set Auto Arming Time: Hold down key 8 and enter the time in 24H format. Hold down key 8 to display the system clock. To display, hold down '8' and wait. To disable Automatic Arming program 0000. If Automatic Arming was programmed, the system time can be set only via User Programming Mode: Address 40 hhmm - Set system time, 41 hhmm - set auto arming time.

  • Page 24: Hold-Down Functions

    6.1 Hold-Down Functions Holding down the key for approximately 2 seconds accesses hold-down functions  Hold down functions are confirmed by a long beep  Hold-Down Functions: Siren Key 1  SIREN TEST Shunt Display Key 2  SHUNT DISPLAY Displays shunted zone(s).

  • Page 25: Zone Bypass & Group Bypass (Home Mode)

    Telephone Siren Address 092 enables ‘Answer now‘ feature, the system answers remote computer after one ring. This feature is important if the control panel programmed not to answer incoming calls (programming of 21 rings or greater at address 091). To enable ‘Answer Now’ feature program 01 at address 092. Hold-down key 6 and then key 1, before the computer and modem connect (dial) the control panel.
  • Page 26 To activate Group Bypass II press key ‘0’ three times. To activate both group bypass groups, press 0 then 88. When Group Bypass is selected, the buzzer and LEDs react as follows: The Shunt LED stops blinking 8 seconds after Arming, (prevents LED light from ...

  • Page 27: Lcd Dual Keys Functions

    6.4 LCD Dual Keys Functions Hold down means hold the key for about 2 seconds and as buzzer start release the key. key hold down key hold down Function Note Display alarm and events Press # for next, history hold down 2 for previous event Set system clock in 24H Like 23:10...
  • Page 28 200 and 36 Activate SLO output (until disabled) AV-4009, 4016 200 and 37 Deactivate SLO output 200 and 38 Activate SLO1 output (until disabled) AV-4009, 4016 200 and 39 Deactivate SLO1 output 200 and 44 Set panel to four (4) zones Mode (AV-4044) 200 and 48 Set panel to eight (8) zones Mode (AV-4044) 200 and 50 (Dial)

  • Page 29: Keypad Sounder

    New alarm will create a new history event instead of old one. Delay Shunt Delete Display Events Memory (history); only alarm events Reset Shunt Press (not hold-down) and press (hold-down or 99), will display ‘-’ to cancel all Bypassed Zones. Keypad Panic Keys ...

  • Page 30: Led Indicators

    When the buzzer is OFF, hold down the keys for 2-3 seconds, sounder feedback heard in this case only after releasing the keys. The buzzer set ON at "Power On" and every time the keypad is in programming mode. 6.7 LED Indicators AV-706, AV-707 Keypads: Four LEDs provide visual indication of system status, as well as confirmation of various modes.
  • Page 31  Three LEDs Flashing - In Disarmed mode, rapid blinking indicates AC power failure. AC power fail event is displayed in Events. In Armed mode, rapid blinking indicates system restored after AC Power Failure mode. During programming Follow-Me Telephone Number, three flashing LEDs indicate to enter a new telephone number.

  • Page 32: New Address Series 4000

    7. NEW ADDRESS SERIES 4000 7.1 Systems parameters address Enable PC connection/Download via modem" address113 (default not enabled) To access the panel via remote PC this parameter must be set. The panel will not accept a connection from a remote PC when it is ARMED or there was an alarm. When the panel is disarmed, a connection is always possible if the user entered the Answer Now command ("6"+"1").

  • Page 33: Events Reported By The Sms Module

    Short Message Service via land telephone line (PSTN) The panel sends Short Messages (SMS) via the land telephone line. The SMS service must be enabled on the outgoing telephone line connected to the panel. To enable the SMS reporting for the panel the installer must program: - The SMS Service Center (SMSC) telephone number for Outgoing Messages (in some countries there are two telephone numbers, one for Outgoing messages and one for Incoming messages;...
  • Page 34 PC remote Access --------------------------------------------------- Communication to Central Station Failure Each event is time/date stamped (refer to address 007 to enable) To test the SMS reporting: press/hold "6"+"5" More features * Reporting PC remote access to the central station If the panel was accessed by a remote PC (via the telephone line) then reports will be sent to the Central station (using CID format only): - Successful access/download: code 412, user 99 - Arm /Disarm by remote: code 407, user 99.

  • Page 35: Dialer Reporting Programming Locations

    - Siren, SVM1 and SVM2 telephone alert times can be programmed. - The panel can report to both Central Stations (double report) and only once to the Central Station that is available (one of the Central Station is in this case used as backup in case of failure to contact the other one).

  • Page 36: Programming Sheet Av-4000 Dublo Version 1.05

    8. PROGRAMMING SHEET AV-4000 DUBLO VERSION 1.05 Factory Default Program marked with ( ); Blank Square means no default program Part 1: TELEPHONES & SMS Subscribers (00 = No, 01 = Yes)  Feature Send SMS SMS @ Period Test SMS Max SMS Time stamp SMS SMS center Tel.
  • Page 37 3. System Features & Times (00 = No, 01 = Yes) Address Feature Default Address Feature Default     D i a l e r F e a t u r e s A r m / D i s a r m K e y Instant dialing on entry delay (0=No) Use last zone (8 /16) as key input (0=No)
  • Page 38 4. ZONE 1 to 16 FEATURES (> refers to the value setting address) Zones 1 to 8 Zones 9 to 16 Zone Number  10 11 12 13 14 15 16 Feature  Add. Group 1 Add. Group 2 Zone In Use Entry/Exit Delay 1 >062 Entry/Exit Delay 2...
  • Page 39 5. ZONE 17 to 32 FEATURES (> refers to the value setting address) Zones 17 to 24 Zones 25 to 32 Zone Number  17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 Feature ...

  • Page 40: Step - By - Step Programming

    9. STEP - BY - STEP PROGRAMMING Entering Installer (Engineer) Programming Mode Via AV-706 or AV-707 Keypad Easy Tip: You may program any address by entering the address, followed by the value in sequence. For LCD keypads press # (enter) to confirm the hold down command Power up by connecting AC power with or without battery.
  • Page 41 EXAMPLE 3: 1. Program Siren Time for a 2-minute duration (default 4 minutes). 2. Address 063 represents the Siren Time. 3. Press ; current value of the address is 04; Shunt Telephone Status Two LEDs blink and ‘04’ will be displayed (default program). Shunt 4.

  • Page 42: Reset System To Default Programming

    Note: Even if your communicator receiver requires three digits for the subscriber ID, enter four digits. The system will ignore the fourth digit. If your central station requires programming of letters as well as numbers, refer to the HEX programming description. Use the regular programming method of entering each letter or number in each address, as explained in the programming table (HEX method).
  • Page 43 Connect a momentary voltage to the siren; making sure a ‘beep’ is sounded. In case  of no beep, check for a short circuit or improperly connected wires. Power-up through transformer, if system seems to operate properly connect the battery. ...

  • Page 44: Technical Specifications Av-4009, Av-4016

    AV4016: 1.6 kg. 3 PC's per master box Fuses: Electronic Resetable Fuses Auxiliary Power: 1.25A Sirens: 2 X 1.25A (fuse for each siren) Backup Battery Fuse: 2.5A Av-Gad Systems Ltd. reserves the right to modify and upgrade products without prior notice.

  • Page 45: Troubleshooting

    12. TROUBLESHOOTING Symptom Possible Cause Remedy System not work properly Programming fail Set to default factory programming: In programming mode enter 200 than 69 Keypad failure Incorrect wiring Check color wire   Blown fuse connection  Check power at panel ...
  • Page 46 Symptom Possible Cause Remedy Cannot disarm system Code was changed Keypad wires are too long   before instant arming Disable instant arming  ‘Lock in tamper mode’ Verify address 071 value   ‘6’ ‘P’ displayed after attempt to Verify the last User- You may proceed with change end-user code...
  • Page 47 For additional assistance, please contact first your local distributor, in case problem not solved contact Av-Gad Systems Ltd, mention your vendor. Our telephone: +972-3-681 67 67, Fax: +972-3-683 5505, E-mail: avgad@inter.net.il Mail: POB 49 080, Tel-Aviv 61 490, Israel. Web site: www.av-gad.com...

  • Page 48: Wiring Diagram Av-4009

    13. Wiring Diagram AV-4009 AV-4009 Wiring Diagram WARNING: To prevent electrical shock, disengage the System and disconnect the telephone line before servicing this unit.

  • Page 49: Wiring Diagram Av-4008

    AUSTEL To -V VA10 RF remote + Power - Zones 1 to 8 receiver relay Outputs Connect AV-GAD EASYLOADER Cut jumper for Zone 4 or/and 8 EOL options ON & A1 Ground here cable CCTV Zone 4 Zone 8 Shunt...

  • Page 50: Wiring Diagram Av-4016

    15. Wiring Diagram AV-4016 AV-4016 Wiring Diagram WARNING: To prevent electrical shock, disengage the System and disconnect the telephone line before servicing this unit. Auxiliary Power Output Regulated 13.8V. Observe maximum current 1.1A for keypads and 1.1A for Aux. power...
