- Page 1 PRISM MPX2-DUALDSP Dual Display Installation and Safety Instructions www.telestream.net 071-3729-00A...
- Page 2 Copyright © 2020 Telestream, LLC and its Affiliates. All rights reserved. TELESTREAM is a registered trademark of Telestream, LLC. All other trade names referenced are the service marks, trademarks, or registered trademarks of their respective companies. Telestream products are covered by U.S. and foreign patents, issued and pending. Information in this publication supersedes that in all previously published material.
- Page 3 Telestream supplies; or d) to service a product that has been modified or integrated with other products when the effect of such modification or integration increases the time or difficulty of servicing the product.
- Page 4 Program may be used. Title to the Program and all copies thereof, but not the media on which the Program or copies may reside, shall be and remain with Telestream or others for whom Telestream has obtained a respective licensing right.
- Page 5 Telestream or any third party from whom Telestream may have obtained a respective licensing right if Customer fails to comply with any term or condition and such failure is not remedied within thirty (30) days after notice hereof from Telestream or such third party.
-
Page 7: Table Of Contents
Initial product inspection ..........................1 Accessories ..............................2 Operating requirements ..........................3 Rear-panel connectors ..........................5 Dual Display installation ..........................6 Power-on and power-off procedures ......................12 Operation ................................. 14 Configure the MPX2-DUALDSP Dual Display ..................14 PRISM MPX2-DUALDSP Installation and Safety Instructions... -
Page 8: Important Compliance And Safety Information
Cet appareil numerique respecte les limites de bruits radioelectriques visant les appareils numeriques de classe A prescrites dans le Reglement sur le brouillage radioelectrique du Quadstere des Communications du Canada. Cet appareil numerique de la Classe A est conforme a la norme NMB-003 du Canada. PRISM MPX2-DUALDSP Installation and Safety Instructions... - Page 9 EN 61000-4-5: 2006, EN 61000-4-6: 2009, EN 61000-4-11: 2004 Environments: E2 Warnings Warning! This is a Class A product. In a domestic environment, this product may cause radio interference, in which case, the user may be required to take appropriate measures. PRISM MPX2-DUALDSP Installation and Safety Instructions...
- Page 10 Section II of the relevant Packing Instructions from the IATA Dangerous Goods Regulations. Consult your air carrier for applicability and determination of any special lithium battery transportation requirements. PRISM MPX2-DUALDSP Installation and Safety Instructions...
- Page 11 Taiwan Compliance Statement Japan Compliance Statement Important Compliance and Safety Information This manual contains information and warnings that must be followed by the user for safe operation and to keep the product in a safe condition. PRISM MPX2-DUALDSP Installation and Safety Instructions...
- Page 12 Avoid exposed circuitry: Do not touch exposed connections and components when power is present. Do not operate with suspected failures: If you suspect that there is damage to this product, have it inspected by qualified service personnel. PRISM MPX2-DUALDSP Installation and Safety Instructions...
- Page 13 Be sure your work area meets applicable ergonomic standards. Consult with an ergonomics professional to avoid stress injuries. Use only the Telestream rackmount hardware specified for this product. Service Safety Summary The Service safety summary section contains additional information required to safely perform service on the product.
- Page 14 Use personal protective equipment to prevent shock and arc blast injury where hazardous live conductors are exposed. When incorporating this equipment into a system, the safety of that system is the responsibility of the assembler of the system. viii PRISM MPX2-DUALDSP Installation and Safety Instructions...
- Page 15 Damage to the module can occur if this module is powered on at temperatures outside the specified temperature range. CAUTION. To prevent risk of fire, adequate airflow to instrument(s) and rack adapter must be maintained. Failure to provide adequate airflow to instrument(s) could cause an instrument to shut down. PRISM MPX2-DUALDSP Installation and Safety Instructions...
-
Page 16: Preface
Product description The PRISM MPX2-DUALDSP provides a 3RU dual touch display unit for the PRISM family of waveform monitors to create fully integrated audio, video, and data monitoring suite. The PRISM Dual Display module is 19 inches wide with a shallow installation depth and comes with two sets of USB/Headphone connectors that can be mounted on each rack ear. -
Page 17: Documentation
MPX2 instrument in a 19” equipment Rackmount Slides and rack Rails Installation Instructions Conventions used in this manual These icons may be used throughout this manual. Sequence Step Front panel Connect power Network SVGA power PRISM MPX2-DUALDSP Installation and Safety Instructions... -
Page 19: Installation
Avoid the use of chemical cleaning agents that might damage the plastics used in the module. Use a 75% isopropyl alcohol solution as a cleaner and rinse with deionized water. Before using any other type of cleaner, consult your Telestream Service Center or representative. PRISM MPX2-DUALDSP Installation and Safety Instructions... -
Page 20: Accessories
When ordering the A99 option, it is the responsibility of the end user to ensure that a certified power cord, for the country or region it is installed, is used with this module. CAUTION. To reduce risk of fire and shock, use the certified power cord provided with the product. PRISM MPX2-DUALDSP Installation and Safety Instructions... -
Page 21: Operating Requirements
To ensure proper airflow, there must be at least 2 inches of clearance on both sides of Instrument the instrument, at least 2 inches of clearance from the rear of the instrument, and at least a 1/2 inch of clearance from the top of the instrument. PRISM MPX2-DUALDSP Installation and Safety Instructions... - Page 22 Table 3 lists the physical characteristics of the Dual Display. Table 3: Physical characteristics Parameter Description Dimensions Height 13.28 cm (5.23 in.) Width 48.26 cm (19 in.) Depth 7.62 cm (3 in.) Weight 2.73 kg (6.02 lbs.) Shipping Typically 4.54 kg (10 lbs.) PRISM MPX2-DUALDSP Installation and Safety Instructions...
-
Page 23: Rear-Panel Connectors
Rear-panel connectors Figure 1 shows the external connections to the rear panel of the Dual Display module. A description of each connector is provided in the table. Figure 1 : PRISM MPX2-DUALDSP rear panel connectors Item number (See Figure 1.) Description AC power input. -
Page 24: Dual Display Installation
WASHER, FLAT; 0.203 ID X 0.625 OD X 0.062, ZINC PLATED STEEL 210-1298-XX WASHER; SHOULDER & RETAINER, 0.195 ID X 0.195 THK, PLASTIC, TV GRAY, 6.575 OD 212-0591-XX SCREW, MACHINE; 10-32 X 0.750 OVAL HEAD, POZI PRISM MPX2-DUALDSP Installation and Safety Instructions... - Page 25 4. Use the four screws from step 1 to secure the USB/headphone connector from the back of each rack ear. Figure 3 : Guide the connections through the rack ears and secure with screws PRISM MPX2-DUALDSP Installation and Safety Instructions...
- Page 26 1. Locate four 10-32 X 0.750 oval head screws from the hardware kit (016-1133-XX). 2. Use a screwdriver with a PoziDriv tip to secure the Dual Display in the rack with two screws on each rack ear. Figure 4 : Secure the Dual Display to the rack PRISM MPX2-DUALDSP Installation and Safety Instructions...
- Page 27 3. Connect the cables from the USB port and headphone jack on each rack ear to the rear of the Dual Display. Figure 5 : Connect USB and headphone connections (optional) 4. Connect the power cable to the Dual Display. (See Power cord installation.) PRISM MPX2-DUALDSP Installation and Safety Instructions...
- Page 28 1. Connect DisplayPort1 on the MPX2 to the DisplayPort connector on Display 1. 2. Connect any USB port on the MPX2 to the USB B port on Display 1. Figure 6 : Connect the MPX2 to Display 1 (primary) PRISM MPX2-DUALDSP Installation and Safety Instructions...
- Page 29 3. Connect DisplayPort2 on the MPX2 to the DisplayPort connector on Display 2. 4. Connect any USB port on the MPX2 to the USB B port on Display 2. Figure 7 : Connect the MPX2 to Display 2 (extended) PRISM MPX2-DUALDSP Installation and Safety Instructions...
-
Page 30: Power-On And Power-Off Procedures
To minimize the risk of damage to the Dual Display, it is strongly recommended that the power cord be connected to the Dual Display before the power cord is connected to the AC power source. Figure 8: Connect the power cord to the display PRISM MPX2-DUALDSP Installation and Safety Instructions... - Page 31 2. To completely remove power from the display, disconnect the power cord from the Dual Display. The power cord has a locking mechanism to keep it attached to the Dual Display. Push the button on the cord housing to release the locking mechanism. PRISM MPX2-DUALDSP Installation and Safety Instructions...
-
Page 32: Operation
: Extended display mode configuration NOTE. When you connect an MPX2-DUALDSP to an MPX2-10 or -25 the first time, the second display might be blank until an application is selected from the press-and-hold menu. PRISM MPX2-DUALDSP Installation and Safety Instructions...
