- Page 1 BPR|zero INSTRUMENT GUIDE rbr-global.com...
-
Page 2: Table Of Contents
6.4.2 Servicing the RBRquartz BPR|zero waste oil reservoir....................14 Overview..................................14 6.4.3 Repairs ..................................... 15 6.4.4 Support kits ..................................16 Appendix........................17 7.1 Appendix A - RBRquartzBPR|zero Product Drawing..............17 7.2 Appendix B - RBRquartzBPR|zero Service Drawing............... 19 7.3 Appendix C - RBRquartzBPR|zero Connector Details ..............20 RBR#0008819revA ... -
Page 3: Introduction
2 Introduction You can access the RBR instrument guide on the USB data stick provided when you purchase a logger, from the Help menu in Ruskin, and on the RBR web site, at www.rbr-global.com. RBR#0008819revA – 3... -
Page 4: Revision History
3 Revision history Revision No. Release Date Notes 04-May-2020 Original RBR#0008819revA – 4... -
Page 5: Warranty Statement
Units suffering from such defects will be repaired or replaced at the discretion of RBR Ltd., provided that the problem has appeared during normal use of the instrument for the purpose intended by us. The liability of RBR Ltd. extends only to the replacement cost of the instrument. -
Page 6: Rbrquartz Bpr|Zero
5.2 Specifications - RBRquartz BPR|zero Physical Weight: ~30kg in air (one Paros) ~18kg in water (one Paros) Size: ~750mm x Ø140mm Housing: Titanium Depth rating: 7000 m Operational temperature: -20°C to 50°C* Storage temperature: -20°C to 50°C RBR#0008819revA – 6... - Page 7 While the Paros will continue to run and be measured, the valve will not operate. ***Connector diagram and pinout available in Appendix C - RBRquartzBPR|zero Connector Details Marine temperature (standard) Range: -5 to 35°C Accuracy: ±0.002°C Time constant: ~3 minutes Typical stability: ±0.002°C/year RBR#0008819revA – 7...
- Page 8 1350 / 2000 / 4000 / 7000 dbar Initial accuracy: ±0.01% FS (full scale) Resolution: 10ppb (at 16Hz sampling rate) Accelerometer (optional) Range: ±3g Resolution: <100ng The full mechanical drawing is available in Appendix A - RBRquartzBPR|zero Product Drawing RBR#0008819revA – 8...
-
Page 9: Instrument Hardware
M6 screws will need to be removed using a 6mm Allan key (supplied). To do this the instrument can be stood on the sensor end cap and held vertically, or laid on its side. Once the screws are removed, the battery end cap can be removed and rested on the side of the housing when standing vertical. RBR#0008819revA – 9... - Page 10 O-rings clean and avoid scratching the O-ring mating surfaces. Carefully inspect the O-rings, as described in the Inspecting the O-rings section, before deploying the logger. Reinstall the 2 X M6 screws and tighten to max of 10Nm. RBR#0008819revA – 10...
-
Page 11: Changing The Batteries - Rbrquartz Bpr|Zero
Remove the old cells from the battery end cap. Install new cells with the negative terminal installed on the side with the spring. The terminals are also labelled on the boards. 4. Reinstall the battery end cap. RBR#0008819revA – 11... -
Page 12: Installing Desiccant - Rbrquartz Bpr|Zero
6.4.1 O-rings - RBRquartz BPR|zero The single most important item of maintenance on any RBR submersible data logger is the care of the O-rings. Any kind of water leak can damage the circuitry beyond repair and cause complete data loss. Every logger's seal depends upon its O-rings, not the end cap tightness. -
Page 13: Inspecting O-Rings
If the O-ring is scratched, cut, distorted, perished or defective in any other way it must be replaced. If any of the surfaces of the O-ring groove are scratched, pitted or otherwise damaged, the logger may need to be returned to RBR for refurbishment: please contact us for advice. -
Page 14: Servicing The Rbrquartz Bpr|Zero Waste Oil Reservoir
The cost of an O-ring is negligible compared with the cost of the instrument and its deployment. Therefore, routine replacement of O-rings is cheap insurance. O-rings: #2-225 N70 O-ring (RBR#0002408), #8-225 N90 backup ring (RBR#0009115) 6.4.2 Servicing the RBRquartz BPR|zero waste oil reservoir... -
Page 15: Repairs
6.4.3 Repairs We support all instruments and software that we manufacture. First line support is always available by phone or e-mail. Please contact us immediately if you are experiencing problems with your RBR product. It is very important to contact RBR#0008819revA... -
Page 16: Support Kits
There are no user-repairable parts of the logger. Any attempt at repair, whether successful or not, without prior authorization from RBR Ltd., will void the warranty. If it is necessary to return the product to RBR for an upgrade, repair, or calibration; please review the detailed shipping information on our website www.rbr-global.com before returning the unit. -
Page 17: Appendix
7 Appendix 7.1 Appendix A - RBRquartzBPR|zero Product Drawing RBR#0008819revA – 17... - Page 18 RBR#0008819revA – 18...
-
Page 19: Appendix B - Rbrquartzbpr|Zero Service Drawing
7.2 Appendix B - RBRquartzBPR|zero Service Drawing RBR#0008819revA – 19... -
Page 20: Appendix C - Rbrquartzbpr|Zero Connector Details
7.3 Appendix C - RBRquartzBPR|zero Connector Details RBR#0008819revA – 20...
