QUICK START PROCEDURE The half bridge development board EPC9034 is easy to set up as buck or boost converter. Refer to figure 2 for buck converter configuration and measurement setup, and figure 3 for boost converter setup, and follow the...
Connect the output voltage (labeled as V , J5, J6) Figure 1: Block diagram of EPC9034 development board to your circuit as required, e.g., resistive load. 3. With power off, connect the gate drive supply to V...
Switch-node temperature of 150° C. output NOTE. The EPC9034 development board does not have any current or thermal protection on board. For more information regarding the thermal performance of EPC eGaN FETs, please Switch-node oscilloscope probe consult: D.
Page 5
QUICK START GUIDE EPC9034 Table 2: Bill of Materials Item Reference Part Description Manufacturer Part Number C4, C10, C11 Capacitor, 1 µF, ±10%, 25 V X7R C1608X7R1E105K C5, C6 Capacitor, 0.1 µF, ±10%, 25 V X7R C1608X7R1E104K Capacitor, 0.1 µF, ±10%, 25 V X7R...
Page 6
100 pF, 50 V 100 pF, 50 V PWM2 EMPTY Direct Drive .1" Male Vert. .1" Male Vert. EMPTY vSW probe adapter PWM1 PWM2 MMCX EMPTY MMCX vGS2 probe EMPTY EMPTY adapter vSW probe holes Figure 6: EPC9034 - Schematic...
Demonstration Board Notification The EPC9034 board is intended for product evaluation purposes only. It is not intended for commercial use nor is it FCC approved for resale. Replace components on the Evaluation Board only with those parts shown on the parts list (or Bill of Materials) in the Quick Start Guide. Contact an authorized EPC representative with any questions. This board is intended to be used by certified professionals, in a lab environment, following proper safety procedures.
