- Page 1 Development Board EPC9060/61 Quick Start Guide Half-bridge with Gate Drive for EPC2030/31 Revision 2.0...
- Page 2 Symbol Parameter Conditions Units Gate Drive Input Supply Range When using 40 V devices, EPC9060 Bus Input Voltage Range When using 60 V devices, EPC9061 When using 40 V devices, EPC9060 Switch Node Output Voltage When using 60 V devices, EPC9061...
- Page 3 Measurement) low: Figure 2: Proper Connection and Measurement Setup a. EPC9060, 40 V b. EPC9061, 60 V 7. Turn on the controller / PWM input source and probe switching node to see switching operation.
-
Page 4: Thermal Considerations
Silicon devices, their relatively smaller size does magnify of 150°C. the thermal management requirements. These development boards NOTE. The EPC9060/61 development boards do not have any current or thermal are intended for bench evaluation with low ambient temperature and protection on board. - Page 5 QUICK START GUIDE EPC9060/61 Table 2 : Bill of Material Item Reference Part Description Manufacturer Part Number C4, C10, C11 Capacitor, 1 µF, 10%, 25 V, X5R Murata GRM188R61E105KA12D C16, C17 Capacitor, 100 pF, 5%, 50 V, NP0 Kemet C0402C101K5GACTU Capacitor, 0.1 µF, 10%, 25 V, X5R...
- Page 6 QUICK START GUIDE EPC9060/61 EPC – THE LEADER IN GaN TECHNOLOGY | WWW.EPC-CO.COM | COPYRIGHT 2019 |...
- Page 7 Demonstration Board Notification The EPC9060/61 board is intended for product evaluation purposes only. It is not intended for commercial use nor is it FCC approved for resale. Replace components on the Evaluation Board only with those parts shown on the parts list (or Bill of Materials) in the Quick Start Guide. Contact an authorized EPC representative with any questions. This board is intended to be used by certified professionals, in a lab environment, following proper safety procedures.
