- Page 1 Solid State SSR Biphasic 60, 80 and 100 A Model with 2 SSR INSTRUCTION MANUAL V1.0x A Product marketed by NOVUS Automation. NOVUS AUTOMATION...
- Page 2 Power cords are connected directly to the SSRs, and, to avoid damage, do not over-strain the device. • Proper grounding is essential to avoid electrical shock and interference. • Under rated current, the ambient temperature must not exceed 40 °C. NOVUS AUTOMATION...
- Page 3 The SSR static switch has a NF (normally closed) thermal relay that is in series with the control terminals. This thermal relay interrupts the command signal by turning off the switch when the heatsink temperature exceeds 80 °C. This prevents damage to the electronic relays of the switch. NOVUS AUTOMATION...
- Page 4 The user must identify the cause of the defect and arrange the correction, always with the key turned off. 10. TECHNICAL SPECIFICATIONS Model Operation Conditions Unit Static Switch 4860 Static Switch 4880 Static Switch 48100 Load Current (I A rms...
- Page 5 Zero cross Isolation V rms 2000 Housing Temperature °C -40 to 80 Ambient Temperature °C -20 to 40 Protection Actuation °C Temperature Technical Specifications Table 01 – 11. WARRANTY The warranty conditions are set forth on our website www.novusautomation.com/warranty. NOVUS AUTOMATION...
