N80/N90/N100/N109/N110/N112/N145 REFRIGERATOR FIGURES FOR INSTALLATION Installatiehandleiding Installation manual Instructions pour l’installation Instrusioni per l’installazione Einbau anleitung Monteringsanvisningar Instrucciones de montaje Prirocnik z navodili za uporabo Ref. 0305...
Page 2
Operation incl. incl. (kWh/24h) (gr./24h) (kg) Depth incl. door freezer freezer Manual N80 Px x 821 x 486 x 543 (piëzo) N80 Ex x 821 x 486 x 543 Electric Manual N90 Px x 821 x 525 x 543 (piëzo)
CONTENTS INTRODUCTION SAFETY INSTRUCTIONS DETERMINING WHERE TO IN STALL THE REFRIGERATOR OUTSIDE VENTS COMBUSTION GASES OUTLET REFRIGERATION INSTALLATION ELECTRICAL COMPONENTS GAS CONNECTION INSTALLATION WIRING DIAGRAMS...
This installation manual concerns the Thetford absorption refrigeration models N80, N90, N100, N109, N110, N112 and N145 and serves as a guide for the correct and safe installation of the refrigerator. Thetford refrigerators are a category C11 (EN 1749) product: “appliances with gas as energy source and which need to be installed isolated from the living area”.
Warnings Install the refrigerator in accordance with the manufacturer’s instructions and local/national laws. Incorrect installation or maintenance of the refrigerator may cause physical injury and/or damage to the refrigerator. Never use naked flames whilst performing maintenance or repairs on gas lines or when checking fittings for leaks.
Page 15
Make sure the lower ventilation grating is always placed right behind the combustion chamber. This grating is also used for maintenance access. In case of models with a wheel arch recess (N80 / 90 / 112), the bottom of the lower ventilation grating must be level with the top of the wheel arch.
- Make sure the floor is solid and even. The floor must be able to take the weight of the refrigerator with its contents. Fitting margins FIGURE 11 / 12: If you use Thetford combustion seals, the dimensions as mentioned in table 11/12 are required.
Securing the refrigerator FIGURE 13: If you use Thetford combustion seals, these need to be fixed in the way shown in the drawing to ensure optimum insulation. Fix the upper and lower flap of the combustion seal. Fix the strips to the sides of the refrigerator in a vertical di rection at the rear of the refrigerator. Fix the upper and lower flap of the combustion seal in the way shown in the drawing.
Page 18
Connecting to a DC power supply (12 V) for all S ES model s (see figu re 1) The description below applies to the installation in motor homes. Please contact Thetford if you wish to install in any other vehicle.
CONNECTING THE GAS SYSTEM - The gas connection has to comply with EN 1949 and EN 732 - Gas components may be installed only by a qualified installer. Be sure to use high -quality approved parts. - The gas components must be installed in accordance with the latest technical regulations. - Gas pipes or hoses must be fitted so that they cannot come into contact with hot or sharp parts.
