Undercounter & Food Prep Tables
Installation & Operation Manual
Please read this manual completely before attempting to install or operate this equipment!
KUCR-27-1
KUCR-36-2
KUCR-48-2
KUCR-60-2
KUCR-72-3
IMPORTANT SAFETY INSTRUCTIONS (SAVE THESE INSTRUCTIONS)
KUCF-27-1
KUCF-36-2
KUCF-48-2
KUCF-60-2
Visit us on the web at www.mvpgroupcorp.com
KST-27-1
KSTM-27-1
KST-36-2
KSTM-36-2
KST-48-2
KSTM-48-2
KST-60-2
KSTM-60-2
KST-72-3
KSTM-72-3
Issued : May 2020
R512B-060
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Kool-It KUCR-27-1
Summary of Contents for Kool-It KUCR-27-1
- Page 1 Undercounter & Food Prep Tables Installation & Operation Manual Please read this manual completely before attempting to install or operate this equipment! KUCR-27-1 KUCF-27-1 KST-27-1 KSTM-27-1 KUCR-36-2 KUCF-36-2 KST-36-2 KSTM-36-2 KUCR-48-2 KUCF-48-2 KST-48-2 KSTM-48-2 KUCR-60-2 KUCF-60-2 KST-60-2 KSTM-60-2 KST-72-3 KUCR-72-3...
-
Page 2: Table Of Contents
CONTENTS RECEIVING AND INSPECTING THE EQUIPMENT Even though most equipment is shipped crated, care should be taken during unloading so the equipment is not damaged while being moved into the building. 1. Visually inspect the exterior of the package and skid or container. Any damage should be noted on the delivery slip and reported to MVP Group immediately at 1-888-275-4538;... -
Page 3: Specifications
SPECIFICATIONS Product Undercounter Refrigerator Model KUCR-27-1 KUCR-36-2 KUCR-48-2 KUCR-60-2 KUCR-72-3 Capacity(cu.ft) 13.1 16.7 20.2 Exterior Dimensions (Including 4" Casters) [in] Net Weight (lbs) Type of refrigeration system Indirect cooling (Fan blowing) ELECTRONIC PCB Control Number of Shelves Number of Doors... - Page 4 SPECIFICATIONS Product Undercounter Freezer Model KUCF-27-1 KUCF-36-2 KUCF-48-2 KUCF-60-2 Capacity(cu.ft) 13.1 16.7 Exterior Dimensions (Including 4" Casters) [in] Net Weight (lbs) Type of refrigeration system Indirect cooling (Fan blowing) ELECTRONIC PCB Control Number of Shelves Number of Doors Rated Voltage 115V/60Hz Type of Power Cord NEMA 5-15...
- Page 5 SPECIFICATIONS Product Salad Table unit Model KST-27-1 KST-36-2 KST-48-2 KST-60-2 KST-72-3 Capacity(cu.ft) 13.1 16.7 20.2 Exterior Dimensions (Including 4" Casters) [in] Net Weight (lbs) Type of refrigeration system Indirect cooling (Fan blowing) ELECTRONIC PCB Control Number of Shelves Number of Doors 4"...
- Page 6 SPECIFICATIONS Product Mega Top Table unit Model KSTM-27-1 KSTM-36-2 KSTM-48-2 KSTM-60-2 KSTM-72-3 Capacity(cu.ft) 13.1 16.7 20.2 Exterior Dimensions (Including 4" Casters) (Including cutting board 35 [in] Net Weight (lbs) Type of refrigeration system Indirect cooling (Fan blowing) ELECTRONIC PCB Control Number of Shelves Number of Doors 4"...
-
Page 7: Serial Number
Serial number The serial number is located on the rating label which is on the left interior wall. Please retain the unit's serial number for service purposes. INSTALLATION 1. GOOD AIR CIRCULATION - Inside and Outside the Unit - Make sure to avoid any object which will interrupt or block the air flow inside the unit. - Make sure to leave enough space toward the interior rear wall to ensure good air circulation - Make sure to keep 7 inches space at the rear and sides of the unit. -
Page 8: Cleaning
CLEANING WARNING - To reduce the risk of electric shock, unplug before cleaning or servicing. 1. CLEANING THE INTERIOR AND EXTERIOR - The interior and exterior of the unit can be cleaned using warm water with soap. - Do not use an abrasive cleaner because it will scratch the surface. 2. - Page 9 UNDERCOUNTER / Guide to set parameters for R290 UNIT Parameter Setting Follow the steps to set the value of parameter. Gently touch the button and Do Not press hard because the operation of the button is done by the electrostatic m ethod.
-
Page 10: Operation
UNDERCOUNTER / Guide to set parameters for R290 UNIT <Blue air> Default Value of Parameter Table Units Para Control or Range of Function Remarks -meters control KUCR-72-3 KUCR KST/KSTM KST-72-3 KUCF KSTM-72-3 Model Code Not recommended Factory use Only See the table below to change. - Page 11 UNDERCOUNTER / Guide to set parameters for R290 UNIT Details of Parameter Select a program by model. Defrost termination temperature control. • It is not recommended to change. Keep the default. • 10~20°C (Controlled by °C base only) Changes may invalidate the warranty. Cord Heater ON/OFF time control : Factory use Only.
- Page 12 UNDERCOUNTER / Guide to set parameters for R290 UNIT Error Code Table Error Display before accessing Cause Error Conditions Status of Unit Code Error Check mode Defective Sensor is disconnected, opened or Cabinet Te "S1 " Temperature mperature is below -58°F (Cabin)senor Show "ESL"...
-
Page 13: Trouble-Shooting
Trouble-Shooting Problem Possible Cause Action Check Power Cord and Power connection failure plug it in Compressor not working Power switch is in off position Change it on position Temperature set point is Correct temperature set too high point The door is opened too frequently Loading of too much warm or moist product... -
Page 14: Installing Castors
Installing Castors 1. Remove the outer packing. 2. Install the castors as illustrated. 3. Maker sure that the castors with brakes are installed at the front of the unit. - Page 15 THREE YEAR PARTS & LABOR WARRANTY MVP GROUP CORP. (KOOL-IT) warrants to the original purchaser of every new KOOL-IT refrigerated unit to be free from defects in material or workmanship, under normal and proper use and maintenance service as specified by MVP Group Corp.
