PTZ Cameras
79068 User Manual
HD PTZ Cameras
HDMI & HDBaseT IP/PTZ Cameras
5x, 12x, or 20x Optical Zoom, Up to 1080p Resolution
All Rights Reserved
Version: 79068_2020V2.0
www.tekvox.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 79068 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tekvox 79068

Summary of Contents for Tekvox 79068

  • Page 1 PTZ Cameras 79068 User Manual HD PTZ Cameras HDMI & HDBaseT IP/PTZ Cameras 5x, 12x, or 20x Optical Zoom, Up to 1080p Resolution All Rights Reserved Version: 79068_2020V2.0 www.tekvox.com...
  • Page 2 PTZ Cameras 79068 User Manual Attentions Electric Safety Installation and operation must accord with electrical safety standards Caution in transportation Avoid stress, vibration, and soakage in transportation, storage, and installation. Polarity of power supply The power supply of the product is ±12V and the max electrical current is 2A. Polarity of the power supply drawing.
  • Page 3 PTZ Cameras 79068 User Manual Safety Precautions To ensure the best performance from the product, please read all instructions carefully before using the device. Save this manual for further reference.  Unpack the equipment carefully, and save the original box and packing material for possible future shipment ...

  • Page 4: Table Of Contents

    PTZ Cameras 79068 User Manual Table of Contents 1. Fast Installation ........................... 7 1.1 Camera Interface Explanation ......................7 1.2 Powering On & Initial Configuration ....................8 1.3 Video Output ............................8 1.3.1 Video Output from LAN ......................8 1.3.2 HDMI Video Output ........................8 1.3.3 3G-SDI Video Output ........................
  • Page 5 PTZ Cameras 79068 User Manual 3.2.1 Keys Instruction ........................20 3.2.2 Applications ..........................21 3.3 Menu Settings ........................... 23 3.3.1 Main Menu ..........................23 3.3.2 System Settings ........................24 3.3.3 Camera Settings ........................24 3.3.4 P/T/Z Settings .......................... 27 3.3.5 Video Format ..........................27 3.3.6 Version ............................
  • Page 6 PTZ Cameras 79068 User Manual 6.1 Camera Maintenance ........................47 6.2 Troubleshooting ..........................48 www.tekvox.com...

  • Page 7: Fast Installation

    8. RJ-45 HDBaseT Interface 11. Bottom Dial Switch 9. DC12V Input Power Supply Socket 12. Tripod Screw Hole Note: 79068-HDMI models are HDMI interface, 79068-HDBT models have RJ-45 HDBaseT interface. Users should read the manual according to the special model. www.tekvox.com...

  • Page 8: Powering On & Initial Configuration

    PTZ Cameras 79068 User Manual 1.2 Powering On & Initial Configuration 13. Power on: Connect DC12V power supply adapter with power supply socket. 14. Initial Configuration: Power on with power indicator light on and remote control receiver light blinking, camera head moves from bottom left to the bottom, and then goes to the HOME position (intermediate position of both horizontal and vertical), while the camera module stretches.

  • Page 9: Wall Mount Step

    PTZ Cameras 79068 User Manual 1.4.1 Wall Mount Step www.tekvox.com...

  • Page 10: Upside-Down Mount Step

    PTZ Cameras 79068 User Manual 1.4.2 Upside-Down Mount Step www.tekvox.com...

  • Page 11: Product Overview

    PTZ Cameras 79068 User Manual 2. Product Overview 2.1 Product Introduction 2.1.1 Product Model Model Number: 79068—XXXX—XX 5—5x Optical Zoom 12—12x Optical Zoom 20—20x Optical Zoom HDBT—RJ-45 HDBaseT Interface HDMI—HDMI Interface Please refer to corresponding features in this manual Note: 5G Wi-fi is optional for HDMI series only 2.1.2 Dimensions...

  • Page 12: Main Features

    PTZ Cameras 79068 User Manual 2.2 Main Features 2.2.1 Camera Performance This series of cameras offers improved functions and performance. Features include advanced ISP processing algorithms to provide vivid images with a strong sense of depth, high resolution, and fantastic color rendition. It supports H.265/H.264 encoding which makes motion video fluent and clear even with less than ideal bandwidth conditions.

  • Page 13: Specifications

    PTZ Cameras 79068 User Manual 29. Multiple Network Protocols: Supports ONVIF, RTSP, RTMP protocols, and RTMP push mode. Also includes easy-to-link streaming media server. 30. 5G Wi-Fi function: If the product contains a 5G Wi-Fi module, you can set up a wireless Wi-Fi connection.
  • Page 14 PTZ Cameras 79068 User Manual Input/Output Interfaces ‘-HDMI models: HDMI, 3G-SDI, LAN Video Interfaces ‘-HDBT models: HDBaseT, LAN Image Code Stream Double streams outputs simultaneously Video Compression H.264, H.265 Format Control Signal RS-232 Ring through RS232 output, RS-485 Interface Control Protocol VISCA/Pelco-D/Pelco-P;...

  • Page 15: Interface Instruction

    PTZ Cameras 79068 User Manual Dimensions 5.9” (150mm) x 5.9” (150mm) x 6.6” (167.5mm) Weight 3.1 lbs. (1.4kg) Working Environment Indoor Remote Operation (IP) Remote Upgrade, Reboot and Reset 2.4 Interface Instruction 2.4.1 External Interface External Interface of HDMI models: RS232 Input/Output, RS485 Input, Audio Input, 3G-SDI Output,...

  • Page 16: Bottom Dial Switch

    PTZ Cameras 79068 User Manual External Interface of HDBT models: Audio Input, HDBaseT Output, LAN, and DC12V Power Interface External Interface of HDBT (HDBaseT) Series 2.4.2 Bottom Dial Switch HDMI models: Two DIP switches are set to ON or OFF to select different modes of operation...

  • Page 17: Rs-232 Interface

    PTZ Cameras 79068 User Manual 2.4.3 RS-232 Interface Computer/keyboard & camera connection HDMI models’ RS-232C interface specification: Camera Windows (DB-9) 1. DTR 1. DCD 2. DSR 2. RXD 3. TXD 3. TXD 4. GND 4. DTR 5. RXD 5. GND 6.
  • Page 18 PTZ Cameras 79068 User Manual RS232 (DB-9) Port Definition Port Definition Data Carrier Detect Receive Data Transmit Data Data Terminal Ready System Ground Data Set Ready Request to Send Clear to Send Ring Indicator VISCA Networking Camera Cascade Connection Method...

  • Page 19: Application Instructions

    PTZ Cameras 79068 User Manual 3. Application Instructions 3.1 Video Output 3.1.1 Power-On Initial Configuration When powered on, the IR indicator light will flash and configure the camera to its default configuration. When the camera returns to the HOME position (middle position for P/T), the lens finish will zoom in/out and finish auto-testing.

  • Page 20: Remote Controller

    PTZ Cameras 79068 User Manual 3.2 Remote Controller 3.2.1 Keys Instruction 1. Power Button: After pressing the key for 3 seconds, the camera will enter standby mode. If pressed again for three seconds, the camera will self-test again and then return to the HOME position (If Preset 0 is set, the camera will move to that preset instead of HOME).

  • Page 21: Applications

    PTZ Cameras 79068 User Manual 3.2.2 Applications After finalizing installation, the camera can receive and execute IR commands. When the remote controller button is pressed, the indicator light will flash. When the button is released, the indicator light will stop flashing. Users can control the pan/tilt/zoom setting and run preset positions via the IR remote controller.
  • Page 22 PTZ Cameras 79068 User Manual 5. BLC Setting To toggle Back-Light Compensation (BLC), press [BLC ON/OFF] 6. Setting, Running, and Clearing Presets 1. Setting Presets To set a preset position, manually move the camera into the desired position, then press [SET PRESET], followed by the number...

  • Page 23: Menu Settings

    PTZ Cameras 79068 User Manual 3.3 Menu Settings 3.3.1 Main Menu Language: Language setting (Chinese/English) MENU Setup: System settings ＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝ Camera: Camera settings Language English (Setup) P/T/Z: Pan, tilt, and zoom settings (Camera) Video Format: Output resolution settings (P/T/Z) Version: MCU, Camera, and AF version information...

  • Page 24: System Settings

    PTZ Cameras 79068 User Manual 3.3.2 System Settings Navigate to “Setup” in the Main Menu, and then press [HOME] to enter the System Settings menu Protocol: Network protocol setting (VISCA/Pelco-P/Pelco- SETUP D/Auto) ＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝ VISCA Address: 1 ~ 7 Protocol Auto...
  • Page 25 PTZ Cameras 79068 User Manual 3.3.3.1 Exposure Settings Navigate to “Exposure” in the Camera Settings menu, and then press [HOME] to enter the Exposure Settings sub-menu Mode: Auto / Manual / Shutter Priority / Iris Priority / Brightness Priority EV (Exposure Value): ON / OFF (Auto mode only)
  • Page 26 PTZ Cameras 79068 User Manual 3.3.3.3 Image Settings Navigate to “Image” in the Camera Settings menu, and press [HOME] to enter the Image Settings sub-menu Brightness: 0 ~ 14 Contrast: 0 ~ 14 Sharpness: 0 ~ 15 Flip Horizontal (Flip-H): ON / OFF Flip Vertical (Flip-V): ON / OFF Black &...

  • Page 27: P/T/Z Settings

    PTZ Cameras 79068 User Manual 3.3.4 P/T/Z Settings Navigate to “P/T/Z” in the Main Menu, and then press [HOME] to enter the PTZ Settings menu Depth of Field: ON / OFF (Remote Control only) Reduces zoom speed when zooming in using the remote...

  • Page 28: Version

    PTZ Cameras 79068 User Manual 3.3.6 Version Navigate to “Version” in the Main Menu, then press [HOME] to enter the Version Information menu MCU Version: Version information for the camera microcontroller unit (MCU) Camera Version: Version information for the camera hardware &...
  • Page 29 PTZ Cameras 79068 User Manual First open the “Local Area Connection Properties” on your computer, and then select “Internet protocol version 4(TCP/IPv4)”. Next, click the “Properties” button. From there, select “Advanced” to enter into the Advanced TCP/IP Setting and add IP and subnet mask in the IP browser as pictured below.
  • Page 30 PTZ Cameras 79068 User Manual After the camera has finished self-checking, users can verify the network connection by clicking the Windows Search icon in the Taskbar and typing “cmd”. Press “Enter” to open the Windows Command Prompt window. If the IP address is set to its default, type “ping 192.168.5.26” and press Enter, and it will show message as below: which means network segment adding is succeed.

  • Page 31: Browser Log-In

    PTZ Cameras 79068 User Manual 4.2 Browser Log-In 4.2.1 Web Client Web Client Log-In: Input the IP address 192.168.5.163 in your web browser and click the Enter key to enter the Web Client login page as below picture. Users can log in as an administrator or normal user.

  • Page 32: Configuration

    PTZ Cameras 79068 User Manual 4.2.4 Configuration Click “Configuration” to enter into the device parameters setting page. It contains the following options: Local configuration, audio configuration, video configuration, network configuration, PTZ configuration, internet access configuration, and system configuration. Menu Explanation...
  • Page 33 PTZ Cameras 79068 User Manual 4.2.5.1 Video Encoding Code Stream: Stream: Different video output mode settings use different streams. (Main stream, secondary stream) Compression Format: Set the video compression format, save and reboot to take effect (primary / secondary stream default: H.264, H.265 optional) Video Size: Set video image resolution, save and reboot to take it effect (main stream default 1920 * 1080 or 1280 * 720 optional;...
  • Page 34 PTZ Cameras 79068 User Manual Exposure compensation value: Set the exposure compensation value - valid when it is set for auto (default 0,-7 to 7 optional). BLC: Set back light compensation - valid when it is auto status (default is off).

  • Page 35: Network Configuration

    PTZ Cameras 79068 User Manual 4.2.5.4 Character Overlapping Display date and time: Set whether to display the time and date (default display). Display Title: Set whether to display the title (default display). Font Color of Time: Set font color of time and date (default white, black, yellow, red, blue optional).
  • Page 36 PTZ Cameras 79068 User Manual Onvif Port: Set Onvif port, the device will restart automatically after it has been changed (default 2000,0-65535 optional). Soap Port: Set Soap port (default 1936, 0-65535 optional). RTMP Port: Set RTMP port (default 1935, 0-65535 optional).

  • Page 37: System Configuration

    PTZ Cameras 79068 User Manual Server ID: 34020000002000000001 Click on the "Save" button, it will be valid when it displays "Save successful". 4.2.7 System Configuration 4.2.7.1 Device Properties Device Name: Set the device name (the default Camera1, user can add their own).

  • Page 38: Logout

    PTZ Cameras 79068 User Manual 4.2.7.4 Version Upgrade MCU version: V2.0.0.16 2015-12-18 Camera version: V2.0.0.16 2015-12-18 Focus version: V2.0.0.6 2015-12-11 Users only read the version information above which is consistent with the menu version but cannot modify. Different types of the machine have different information.

  • Page 39: Serial Communication Control

    PTZ Cameras 79068 User Manual Subnet Mask: Set the wireless IP subnet mask (default255.255.255.0) Default Gateway: Set the wireless IP default gateway (default 192.168.1.1) SSID: The user can modify their own (the default test) Encryption: can check, the password can be set after checked.

  • Page 40: Camera Control Commands

    PTZ Cameras 79068 User Manual Error Messages Command Packet Note Returned when the command format is different or Syntax Error z0 60 02 FF when a command with illegal command parameters is accepted Returned when a command cannot be executed due Command Not to current conditions.
  • Page 41 PTZ Cameras 79068 User Manual Command Function Command Packet Note Reset 8x 01 04 03 00 FF 8x 01 04 03 02 FF Manual Control of R Gain CAM _RGain Down 8x 01 04 03 03 FF Direct 8x 01 04 43 00 00 0p 0q FF...
  • Page 42 PTZ Cameras 79068 User Manual Command Function Command Packet Note CAM_NR（2D） 8x 01 04 53 0p FF p = 0 – 7; 0: OFF CAM_NR（3D） 8x 01 04 54 0p FF p = 0 – 8; 0: OFF p = 0 – 4...
  • Page 43 PTZ Cameras 79068 User Manual Command Function Command Packet Note 8x 01 04 A4 00 FF Flip-H 8x 01 04 A4 01 FF Single Command for CAM_Flip Video Flip Flip-V 8x 01 04 A4 02 FF Flip-HV 8x 01 04 A4 03 FF p = 0 ~ E Video format 0: 1080P60;...

  • Page 44: Inquiry Commands

    PTZ Cameras 79068 User Manual 5.1.3 Inquiry Commands Command Function Command Packet Note y0 50 02 FF CAM_PowerInq 8x 09 04 00 FF y0 50 03 FF Off (Standby) CAM_ZoomPosInq 8x 09 04 47 FF y0 50 0p 0q 0r 0s FF...
  • Page 45 PTZ Cameras 79068 User Manual Command Function Command Packet Note p: Memory number last CAM_MemoryInq 8x 09 04 3F FF y0 50 0p FF operated. y0 50 02 FF SYS_MenuModeInq 8x 09 06 06 FF y0 50 03 FF y0 50 02 FF...

  • Page 46: Pelco-D Protocol Command List

    PTZ Cameras 79068 User Manual Command Function Command Packet Note ww: Pan Max Speed Pan-tiltMaxSpeedInq 8x 09 06 11 FF y0 50 ww zz FF zz: Tilt Max Speed y0 50 0w 0w 0w 0w wwww: Pan Position Pan-tiltPosInq 8x 09 06 12 FF...

  • Page 47: Pelco-P Protocol Command List

    PTZ Cameras 79068 User Manual 5.3 Pelco-P Protocol Command List Function Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7 Byte 8 0xA0 Address 0x00 0x08 Pan Speed Tilt Speed 0xAF Down 0xA0 Address 0x00...
  • Page 48 PTZ Cameras 79068 User Manual 6.2 Troubleshooting No video output: 1. Check whether the camera power supply is connected, that the voltage is normal, and that the power indicator is lit. 2. Check whether the machine can perform self-inspection after it has been restarted.
