No. Signal
8 ETH_SPD
9 GND
10 CAN_TX
11 CAN_RX
12 Reserved
13 GND
14 SPEED
15 FWR
16 GND
2
This will be supported in the future release
Function
light
LOW Level: connection building;
High Level: ununited;
Ethernet interface network speed
indicator
LOW Level: 100Mbps
High Level: 10Mbps
Ground
CAN bus transmit data
CAN bus receive data
Reserved
Ground
Odometer velocity Input
Odometer direction message Input
Ground
20
UB4B0 User
Description
GND
Reserved
GND
2
GND
