- Page 1 INSTALLATION AND OPERATION QUICK GUIDE WWW.UNICORECOMM.COM UC6226CI EVK Suite Copyright© 2009-2021, Unicore Communications, Inc. Data subject to change without notice.
- Page 2 UNICORECOMM, and UFirebird are registered trademarks of Unicore Communications, Inc. All other brands/product names are trademarks or registered trademarks of their respective companies.
- Page 3 UC6226CI_EVK Suite_Quick Guide Contents Overview................................1 EVK Introduction ............................1 Interface .................................2 Notes ................................3...
- Page 4 1 Overview UC6226CI evaluation board (hereinafter referred to as EVK board), which is mainly used to test and evaluate the function and performance of UC6226CI chip for user convenience. 2 EVK Introduction 8 9 10 11 12 13 16 17 18 Figure 1 EVK Board...
- Page 5 UC6226CI_EVK Suite_Quick Guide 3 Interface Reset, active low; GND; RTS hardware flow control (Not recommended for non-high rate data transmission); CTS hardware flow control (Not recommended for non-high rate data transmission); This interface connects MCU and TX of the chip. When the jumper cap is disconnected, the chip TX and MCU are disconnected, which can be used for external serial port debugging;...
- Page 6 4 Notes When using the USB cable for power supply communication, there may be a serial port mouse conflict. At this time, the serial enumerator needs to be removed from the serial port settings, as shown below:...
- Page 7 UC6226CI_EVK Suite_Quick Guide...
