EP1502 Intelligent Controller
with Two Reader Interface
Installation and Specifications:
1. General:
The EP1502 intelligent controller provides decision making, event reporting, and database storage for the
Mercury hardware platform. Two reader interfaces provide control for two physical barriers.
The EP1502 communicates with the host via on-board 10-BaseT/100Base-TX Ethernet port. Alternatively,
port 1 (RS-232) can be used for host communication.
Each reader port can accommodate a reader that utilizes TTL (D1/D0, Clock/Data), F/2F, or 2-wire
RS-485 device signaling, and also provides tri-state LED control, and buzzer control (one wire LED mode
only). Four Form-C relay outputs may be used for strike control or alarm signaling. The relay contacts are
rated at 5 A @ 30 Vdc, dry contact configuration. Eight inputs are provided that may be used for monitoring
the door contacts, exit push buttons and alarm contacts. Input circuits may be configured as unsupervised
or supervised. The EP1502 requires 12 to 24 Vdc for power.
2. EP1502 Hardware:
8.00 [203.20]
Mercury Security © 2015
2355 MIRA MAR AVE. LONG BEACH, CA 90815-1755, (562)986-9105 FAX (562) 986-9205
BATTERY: BR/CR2330
REPLACE ANNUALLY
STATUS LED's
.50 [12.70]
1
2
J4
3
TMP
FLT
R1
R2
2.00 [50.80]
+
-
1
2
3
J3
4
J8
1
2
3
4
S1
TB8
VBAT
GND
DAT
D0
CLK
D1
BZR
3.00 [76.20]
LED
VO
TB9
GND
DAT
D0
CLK
D1
BZR
LED
VO
PASS
12V
NO
J7
OUT 1 C
NC
NO
2.00 [50.80]
OUT 2 C
NC
NO
OUT 3 C
NC
NO
OUT 4 C
.50 [12.70]
NC
.25 [6.35]
RELAY
STATUS
LED's
EP1502
This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must
accept any interference received, including interference that
may cause undesired operation.
RESET SWITCH
3V
BR/CR2330
S2
BT1
J1
5V
3.3V
8V
K2
K1
IN1
IN2
IN3
K
IN4
1
K
IN5
2
IN6
K
3
IN7
K
4
IN8
K4
K3
5.50 [139.70]
6.00 [152.40]
INPUT
STATUS
LED's
DOC 10107-0031
www.mercury-security.com
Ø.156 [3.96]
8 PLACES
TB1
VIN
TMP
GND
FLT
GND
CHASSIS
GROUND
J6
TB2
TXD
RXD
RTS
CTS
GND
TR+
TR-
GND
TB4
IN1
IN2
IN3
IN4
TB5
TB6
IN5
IN6
TB7
IN7
IN8
.25 [6.35]
REV 1.06
Page 1
