2/ INSTALLATION

a) Fixing
The marking system must be installed on a perfectly rigid and stable appropriate support
frame.
b) Connections
Rear of E10 controller
N° TITLE
1 MARKER
2 I/O
3 START/STOP
4 SERIAL
5 HOST
6 USB DEVICE
7 ACCESSORY 1
8 ACCESSORY 2
9 PROFIBUS
10 ETHERNET
11 USB KEYBOARD
12 WIFI
TRAPPE A.U /
13
BATTERIE
NOTI124SUS-R01.docx
Figure 1 : Rear of e10
CONNECT TO :
MARKING MACHINE
INPUT/OUTPUT/MARKING
FILE
CONTROL HANDBOX
PC / PLC
PC / PLC
PC
D-AXE
Z-AXE / 4th AXE
PC/PLC
PC/PLC
USB KEYBOARD
ANTENNA
Translation of the original instructions
CODE ARTICLE
OPTION 3 300 050
OPTION
OPTION 3 300 051
OPTION
