I - INTRODUCTION

Thank you for choosing a SIC MARKING machine for your marking applications.
SIC marking systems contribute to improve industrial marking standards and we welcome
you as a user of our systems.
This guide contains the installation and use instructions for the "Integrated" type machines.
We recommend that you read it carefully before installing the system.
We invite you to contact our local distributor first.
II - PRESENTATION
1/ Functioning principle
SIC Scratching machines enable to mark parts by material displacement.
Characters are made by a succession of lines resulting from a pin displacement.
This principle enables to identify parts of any shape, made of either hard or soft
materials with a permanent mark.

2/ Description

The system is made of the following parts:
a) the marking head
It is the mechanism part. It carries and drives the marking tool : the pin.
b) The controller
It contains the electronics. A push button box will command the start or stop of the
marking cycle..
III - Installation

1/ UNPACKING

Except if we deliver the system, it is generally delivered on a pallet, which needs to be kept
for any return of the material.
Remove the sub-systems carefully from the pallet (controller, button box, options...).
Remove both safety bolts and remove the machine.
