SDHQ 53-1601-G3 Install Instructions Manual

SDHQ-53-1601/1602-G3
Product:
2007-2020 Tundra Prerunner Bumper
Description:
(1) SDHQ Prerunner Bumper
o Without Winch Mount, Without Baja Bar
o Without Winch Mount, With Baja Bar
(1) Driver Side Lower Connector
(1) Passenger Side Lower Connector
(1) Driver Side Tube Frame Mount
(1) Passenger Side Tube Frame Mount
(1) Main Skid
o Main Skid Without Winch
(1) 2 nd Skid
(1) Hardware Package
(4) 3/8" – 16 x 1" Grade 8 Hex Head Bolts
(4) 3/8" – 16 x 1 ¼" Grade 8 Hex Head Bolts
(8) 3/8" – 16 Grade 8 Steel Locknuts
(16) 3/8" Grade 8 Flat Washers
(4) 5/16" – 18 x 1" S.S. Countersunk Allen Bolts
(4) 5/16" Delrin Fender Washers
(3) 3/8" – 16 x 1" S.S. Button Head Allen Bolts
(3) 3/8" – 16 S.S. Locknuts
(3) 3/8" S.S. Flat Washers
Inspected and Packaged By:
For questions or help with the installation, please call SDHQ Offroad @ 480-633-2929
Mon.–Fri. 8:00am–5:30pm and Sat. 8:00am–3:30pm Arizona Time. www.sdhqoffroad.com
Latest Revision: 11/5/2019
Product Packing List
Page 1 of 10
SDHQ-53-1601-G3
SDHQ-53-1602-G3
SDHQ-53-1601-G3-A
SDHQ-53-1601-G3-B
SDHQ-53-1601-G13-C
SDHQ-53-1601-G3-D
SDHQ-53-1511-G3
SDHQ-53-1501-G3
SDHQ-53-1601-E
Date:
