GRAIN AUGERS
MK 130 PLUS X 61' - 81'
ASSEMBLY & OPERATION
Read this manual before using product. Failure
Part Number: 30259
to follow instructions and safety precautions can
Revised: 10/2/10
result in serious injury, death, or property
damage. Keep manual for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MK 130 PLUS 61 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Westfield MK 130 PLUS 61

Summary of Contents for Westfield MK 130 PLUS 61

  • Page 1 GRAIN AUGERS MK 130 PLUS X 61’ - 81’ ASSEMBLY & OPERATION Read this manual before using product. Failure Part Number: 30259 to follow instructions and safety precautions can Revised: 10/2/10 result in serious injury, death, or property damage. Keep manual for future reference.
  • Page 2 This product has been designed and constructed according to general engineering standards . Other local regulations may apply and must be followed by the operator. We strongly recommend that all personnel associated with this equipment be trained in the correct operational and safety procedures required for this product. Periodic reviews of this manual with all employees should be standard practice.

  • Page 3: Table Of Contents

    ESTFIELD RAIN UGERS MK 130 P 61’ - 81’ LUS X TABLE OF CONTENTS 1. Introduction .......................... 5 2. Safety First..........................7 2.1. General Safety ......................8 2.2. Assembly Safety....................... 9 2.3. Operation Safety ...................... 9 2.4. PTO Safety......................10 2.5.
  • Page 4 ESTFIELD RAIN UGERS MK 130 P 61’ - 81’ LUS X TABLE OF CONTENTS 5. Operation ..........................57 5.1. Pre-Operation Checklist ..................57 5.2. Auger Drive & Lockout Procedure ................58 5.3. Hydraulics....................... 58 5.4. Operating Procedure ....................59 5.4.1. Initial Start-Up ................... 59 5.4.2.

  • Page 5: Introduction

    1. I ESTFIELD RAIN UGERS NTRODUCTION MK 130 P 61’ - 81’ LUS X 1. Introduction Congratulations. As the new owner of a grain auger, you will be working with equipment designed to complement and improve your farming operation. Before using this auger, please read this manual and all safety labels and familiarize yourself with the various features of the machine and the necessary precautions for efficient and safe operation.
  • Page 6 1. I NTRODUCTION ESTFIELD RAIN UGERS MK 130 P 61’ - 81’ LUS X 30259...

  • Page 7: Safety First

    2. S ESTFIELD RAIN UGERS AFETY IRST MK 130 P 61’ - 81’ LUS X 2. Safety First The Safety Alert symbol to the left identifies important safety messages on the product and in the manual. When you see this symbol, be alert to the possibil- ity of personal injury or death.

  • Page 8: General Safety

    2. S AFETY IRST ESTFIELD RAIN UGERS MK 130 P 61’ - 81’ LUS X 2.1. GENERAL SAFETY Important: The general safety section includes instructions that apply to all safety practices. Any instructions specific to a certain safety practice (e.g., assembly safety), can be found in the appropriate section.

  • Page 9: Assembly Safety

    2. S ESTFIELD RAIN UGERS AFETY IRST MK 130 P 61’ - 81’ LUS X • Follow good shop practices: • keep service area clean and dry • be sure electrical outlets and tools are properly grounded • use adequate light for the job at hand •...

  • Page 10: Pto Safety

    2. S AFETY IRST ESTFIELD RAIN UGERS MK 130 P 61’ - 81’ LUS X Figure 2.1 2.4. PTO SAFETY • Never use a PTO driveline without a rotating shield in good working order. • Ensure PTO driveline is securely attached at both ends before operating. •...

  • Page 11: Hydraulic Safety

    2. S ESTFIELD RAIN UGERS AFETY IRST MK 130 P 61’ - 81’ LUS X • Do not exceed operating speed of 540 rpm. • Keep u-joint angles small and equal. Do not exceed recommended operating length for PTO driveline. 2.5.

  • Page 12: Transport & Placement Safety

    2. S AFETY IRST ESTFIELD RAIN UGERS MK 130 P 61’ - 81’ LUS X 2.6. TRANSPORT & PLACEMENT SAFETY • Transport auger in full down position with slight ten- sion on cable. • Properly place hitch pin and securely attach safety chain.

  • Page 13: Safety Decal Locations

    PTO driveline shields, winches, and lift cables must meet ASABE standards or serious injury may result. Use of unauthorized parts will void warranty. If in doubt, contact Westfield or your Westfield dealer. • Do not modify any auger components without authorization from Westfield.
  • Page 14 2. S AFETY IRST ESTFIELD RAIN UGERS MK 130 P 61’ - 81’ LUS X DECAL #17698 DECAL #28615 Figure 2.2 30259...
  • Page 15 2. S ESTFIELD RAIN UGERS AFETY IRST MK 130 P 61’ - 81’ LUS X DECAL #27709 PLACED ON MACHINE BEHIND GUARD DECAL #17093 (ON LOW PROFILE ONLY) DECAL #17101 DECAL #17098 DECAL #17113 DECAL #17097 DECAL #17398 NOTE: INCLINED HOPPER SHOWN DECAL #17096 Figure 2.3...
  • Page 16 2. S AFETY IRST ESTFIELD RAIN UGERS MK 130 P 61’ - 81’ LUS X DECAL #17099 DECAL #17107 DECAL #18859 DECAL #17094 DECAL #19960 PLACED ON MACHINE BEHIND DECAL #27709 DECAL #17101 DECAL #17531 DECAL #17098 Figure 2.4 30259...
  • Page 17 2. S ESTFIELD RAIN UGERS AFETY IRST MK 130 P 61’ - 81’ LUS X DECAL # 27516 NOTE: THIS WARNING DECAL IS ONLY INCLUDED ON AUGERS 81’ AND LONGER. Figure 2.5 30259...
  • Page 18 2. S AFETY IRST ESTFIELD RAIN UGERS MK 130 P 61’ - 81’ LUS X 30259...

  • Page 19: Assembly

    3. A ESTFIELD RAIN UGERS SSEMBLY MK 130 P 61’ - 81’ LUS X 3. Assembly Warning: Before continuing, please reread the safety information relevant to this section at the beginning of this manual. Failure to follow the safety instructions can result in serious injury, death, or property damage.

  • Page 20: Track Shoe, Trackstop, & Lift-Assist Arm

    3. A SSEMBLY ESTFIELD RAIN UGERS MK 130 P 61’ - 81’ LUS X 3. Slide tube sections together and secure. Make sure to align upper and lower track ends and then tighten bolts. Secure with hardware in table below. Figure 3.1 Details for fastenings: Auger...
  • Page 21 3. A ESTFIELD RAIN UGERS SSEMBLY MK 130 P 61’ - 81’ LUS X Figure 3.3 Figure 3.2  2. MK130 Plus 81’: the track shoe has 4 rollers (Figure 3.4) and the track stop is attached using 8 bolts and locknuts (Figure 3.5). Figure 3.5 Figure 3.4 ...

  • Page 22: Tow Bar

    3. A SSEMBLY ESTFIELD RAIN UGERS MK 130 P 61’ - 81’ LUS X Figure 3.7 Figure 3.6  5. MK130 Plus 81’: attach the lift-assist arm to the center hole on the track shoe with an 11/16” short spacer and flat washer on each side and a 1" x 10" bolt and locknut.

  • Page 23: Boot

    3. A ESTFIELD RAIN UGERS SSEMBLY MK 130 P 61’ - 81’ LUS X 3.4. BOOT Note: The gearbox is sent from the factory filled halfway with EP90 oil. Before further assembly, check oil level to make certain the gearbox is half full. Add oil if necessary.

  • Page 24: Discharge Spout

    3. A SSEMBLY ESTFIELD RAIN UGERS MK 130 P 61’ - 81’ LUS X Part Hardward • 7/16” x 1-1/4” bolts To attach boot to flange and locknuts Wide rim flat • 1-3/4” washer • 3/8” x 3-1/2” Square key Figure 3.10 3.5.

  • Page 25: Truss

    3. A ESTFIELD RAIN UGERS SSEMBLY MK 130 P 61’ - 81’ LUS X 4. Secure the lock collar and tighten the set screw. 5. Install the cover over the two longer 5/8” bolts. Secure with two 5/8” whiznuts. 3.7. TRUSS See Figure 3.12, 3.13, and 3.14.
  • Page 26 3. A SSEMBLY ESTFIELD RAIN UGERS MK 130 P 61’ - 81’ LUS X Figure 3.12 MK130 Plus 61’ & 71’  9. MK130 Plus 81’ (Figure 3.13): a. Fasten short truss anchor (A) to lower auger tube with 7/16” x 1" bolts and locknuts.
  • Page 27 3. A ESTFIELD RAIN UGERS SSEMBLY MK 130 P 61’ - 81’ LUS X Important: Once auger is fully assembled, adjust truss cables on all units (because of initial stretching). Cables may also require adjustment for side alignment. Figure 3.13 MK130 Plus 81’ Figure 3.14 All Augers 30259...

  • Page 28: Transport Undercarriage

    3. A SSEMBLY ESTFIELD RAIN UGERS MK 130 P 61’ - 81’ LUS X 3.8. TRANSPORT UNDERCARRIAGE Figure 3.15 MK130 Plus 61’/71’ Figure 3.16 MK130 81’ 1. Fasten the lower reach arms to the axle with three 5/8” x 2" bolts and locknuts on each side.
  • Page 29 3. A ESTFIELD RAIN UGERS SSEMBLY MK 130 P 61’ - 81’ LUS X 4. Secure the tubing crossbraces to the welded lugs on the lower reach arms with four 1/2” x 1-1/4” bolts and locknuts, and a fifth one where the braces cross.
  • Page 30 3. A SSEMBLY ESTFIELD RAIN UGERS MK 130 P 61’ - 81’ LUS X Figure 3.18 7. Raise the discharge end of auger with a front end loader and a strong sling/chain or block and tackle. The height should be sufficient to clear undercarriage assembly.
  • Page 31 3. A ESTFIELD RAIN UGERS SSEMBLY MK 130 P 61’ - 81’ LUS X  13. MK130 Plus 81’: attach upper lift arms to the center hole on the lift-assist arms as shown in Figure 3.25 using two 5/16” medium spacers, flat washers, and two 1”...
  • Page 32 3. A SSEMBLY ESTFIELD RAIN UGERS MK 130 P 61’ - 81’ LUS X Figure 3.19 30259...

  • Page 33: Lift Cylinder / Cable

    3. A ESTFIELD RAIN UGERS SSEMBLY MK 130 P 61’ - 81’ LUS X 3.9. LIFT CYLINDER / CABLE 3.9.1. MK130 P 61’/71’ Note: Determine right or left side of auger by standing at intake end facing top discharge end. 1.
  • Page 34 3. A SSEMBLY ESTFIELD RAIN UGERS MK 130 P 61’ - 81’ LUS X 4. Attach other lift cylinder to left side of welded bracket with four 7/16” x 1-1/4” bolts and locknuts. Tighten securely (see Figure 3.12 for correct position). CAUTION Track shoe must rest against track stop when adjusting cable.

  • Page 35: Mk130 Plus 81

    3. A ESTFIELD RAIN UGERS SSEMBLY MK 130 P 61’ - 81’ LUS X Figure 3.22  • MK130 Plus 61': attach the cable-roller to bracket located between lower end of track and lift cylinder (Figure 3.12).  • MK130 Plus 71': attach the cable-roller to lower end of track (Figure 3.13). 3.9.2.
  • Page 36 3. A SSEMBLY ESTFIELD RAIN UGERS MK 130 P 61’ - 81’ LUS X 4. Insert the ram ends into brackets on ram guide (Figure 3.24). Secure with two roll pins. Figure 3.24 MK130 Plus 81’ 5. Seat lift-assist arm against the track and place both lift cylinders in full down position (fully retracted).

  • Page 37: Hydraulic Hoses

    3. A ESTFIELD RAIN UGERS SSEMBLY MK 130 P 61’ - 81’ LUS X Note: Although the lift cables are factory installed on the lift cylinders, make sure the cable clamps on the cylinders are secure and the cables are properly seated in the cable sheaves before attaching the cables to the lift-assist arm.

  • Page 38: Mk130 81

    3. A SSEMBLY ESTFIELD RAIN UGERS MK 130 P 61’ - 81’ LUS X 3. Securely attach the long hydraulic hose to tee fitting (Figure 3.26). Place this hose into brackets welded to side of auger tube and boot. Bend tops of these brackets over slightly to hold hose in place.

  • Page 39: Pto (Cv) Driveline

    3. A ESTFIELD RAIN UGERS SSEMBLY MK 130 P 61’ - 81’ LUS X 4. Position the elbow fittings on the left lift cylinder. The lower one should face forward and downward at approximately 45°. The upper one should face rearward and upward at approximately 10°.

  • Page 40: Standard Intake Hopper

    3. A SSEMBLY ESTFIELD RAIN UGERS MK 130 P 61’ - 81’ LUS X Figure 3.27 3.12. STANDARD INTAKE HOPPER See Figure 3.28 and 3.29. 1. Remove access covers, then clean paint and dirt from flight shaft end. Insert Woodruff key into flight shaft end. 2.
  • Page 41 3. A ESTFIELD RAIN UGERS SSEMBLY MK 130 P 61’ - 81’ LUS X NOTICE To prevent damage, you must maintain the correct angle when inserting flight shaft end into angle drive until tube is secured to the hopper section. Allowing tube or hopper to drop will bend the flight shaft end causing it to bind in the angle drive.
  • Page 42 3. A SSEMBLY ESTFIELD RAIN UGERS MK 130 P 61’ - 81’ LUS X 7. Install the 2 pieces of rubber extension on inside hopper lip with twenty  5/16” x 3/4” bolts and washer locknuts, 10 long and 2 short flat iron straps, plus the 2- piece extension connector plates (Figure 3.29).

  • Page 43: Hopper Lift Extension

    3. A ESTFIELD RAIN UGERS SSEMBLY MK 130 P 61’ - 81’ LUS X 3.12.1. H OPPER LIFT XTENSION Æ MK100 81’ only: 1. Place the hopper lift extension onto the bracket on the lower tube as shown. 2. Secure by using the 2 lift extension brackets and four 7/16” x 1-1/4” bolts and locknuts.

  • Page 44: Optional Low Profile Hopper

    3. A SSEMBLY ESTFIELD RAIN UGERS MK 130 P 61’ - 81’ LUS X Note: Winch shown is positioned to use hopper on right side of auger (as determined when standing at intake end facing discharge end). To position winch or left side hopper use, the winch with bracket must be attached with drum up, using the saddle pin with a hairpin.
  • Page 45 3. A ESTFIELD RAIN UGERS SSEMBLY MK 130 P 61’ - 81’ LUS X Figure 3.36 7. Tighten set screws on u-joints, then close and secure the service door. 8. Remove the two 5/16” washer locknuts that secure the chain drive guard. Attach the 2-piece rubber extension to inside of hopper lip with 5/16”...

  • Page 46: Hitch Jack

    3. A SSEMBLY ESTFIELD RAIN UGERS MK 130 P 61’ - 81’ LUS X 11. Place wide rim 1-1/4” washer guard over splined shaft on lower gearbox. a. Clean u-joint spline and splined shaft on lower gearbox, then apply a light film of grease on this splined shaft.

  • Page 47: Auger-To-Tractor Hookup

    3. A ESTFIELD RAIN UGERS SSEMBLY MK 130 P 61’ - 81’ LUS X 3.15. AUGER-TO-TRACTOR HOOKUP Important: Auger must be hooked up to tractor for all operations including transport, raising, placement, and augering grain. 3.15.1. PTO D RIVELINE RAWBAR The final stage of the MK assembly is attaching the auger to the tractor.
  • Page 48 3. A SSEMBLY ESTFIELD RAIN UGERS MK 130 P 61’ - 81’ LUS X Figure 3.39 Figure 3.1 MEASUREMENT PROBLEM SOLUTION • The PTO driveline will bottom out • Pull out or lengthen the trac- If (A) is less than 14” when auger is in raised position.

  • Page 49: Hydraulic Hose Couplers

    3. A ESTFIELD RAIN UGERS SSEMBLY MK 130 P 61’ - 81’ LUS X Figure 3.40 3.15.2. H YDRAULIC OUPLERS Check in your tractor manual or with your dealer regarding the correct type of coupler to use on your auger. Make sure hose ends are free of dirt before securing to coupler.
  • Page 50 3. A SSEMBLY ESTFIELD RAIN UGERS MK 130 P 61’ - 81’ LUS X 30259...

  • Page 51: Transport & Placement

    4. T & P ESTFIELD RAIN UGERS RANSPORT LACEMENT MK 130 P 61’ - 81’ LUS X 4. Transport & Placement Warning: Before continuing, please reread the safety information relevant to this section at the beginning of this manual. Failure to follow the safety instructions can result in serious injury, death, or property damage.
  • Page 52 4. T & P RANSPORT LACEMENT ESTFIELD RAIN UGERS MK 130 P 61’ - 81’ LUS X Figure 4.2 CAUTION If auger wheels are partially or fully buried in snow or grain, failure to clear the area around the wheels before moving may cause damage to the auger or result in serious injury.

  • Page 53: Placement Procedure

    4. T & P ESTFIELD RAIN UGERS RANSPORT LACEMENT MK 130 P 61’ - 81’ LUS X 4.2. PLACEMENT PROCEDURE WARNING Auger must be hooked up to tractor for all operations, including transport, raising, placement, and augering grain. 1. Disconnect PTO driveline from tractor and secure in transport saddle. NOTICE When positioning the MK auger, the PTO driveline must be disconnected from the tractor and placed in the transport...
  • Page 54 4. T & P RANSPORT LACEMENT ESTFIELD RAIN UGERS MK 130 P 61’ - 81’ LUS X NOTICE The hydraulic cylinders are shipped without oil and must be charged with oil before auger is put into operation. See the appendix for charging instructions. WARNING Fluid leaks in the hydraulic cylinder or hose will allow auger to lower inadvertently.
  • Page 55 4. T & P ESTFIELD RAIN UGERS RANSPORT LACEMENT MK 130 P 61’ - 81’ LUS X WARNING Do not raise the MK130 Plus 81’ auger unless the axles are in the extended position. Do not transport the auger unless the axles are in the retracted position.
  • Page 56 4. T & P RANSPORT LACEMENT ESTFIELD RAIN UGERS MK 130 P 61’ - 81’ LUS X Important: Once valves are opened, auger lowers by gravity. As the auger nears the full down position, the rate of descent will increase. Do not operate with tractor valve fully open.

  • Page 57: Operation

    5. O ESTFIELD RAIN UGERS PERATION MK 130 P 61’ - 81’ LUS X 5. Operation Warning: Before continuing, please reread the safety information relevant to this section at the beginning of this manual. Failure to follow the safety instructions can result in serious injury, death, or property damage.

  • Page 58: Auger Drive & Lockout Procedure

    5. O PERATION ESTFIELD RAIN UGERS MK 130 P 61’ - 81’ LUS X 5.2. AUGER DRIVE & LOCKOUT PROCEDURE Note: If shearbolt in the PTO driveline fails, shut down and lock out tractor to replace bolt. The MK130 Plus uses one 3/8” x 1" grade 8 bolt through the shank shear.

  • Page 59: Operating Procedure

    5. O ESTFIELD RAIN UGERS PERATION MK 130 P 61’ - 81’ LUS X 5.4. OPERATING PROCEDURE 5.4.1. I NITIAL TART REAK CAUTION Auger must be hooked up to tractor for all operations, including transport, raising, placement, and augering of grain. Note: The angle drive on the standard intake hopper requires a break-in period of at least 2 or 3 loads of grain.

  • Page 60: Shutdown

    5. O PERATION ESTFIELD RAIN UGERS MK 130 P 61’ - 81’ LUS X DANGER Rotating Flighting Hazard! To prevent death or serious injury: • Keep away from rotating auger flighting. • Do not remove or modify auger flighting guards, doors, or covers. Keep in good working order.

  • Page 61: Lowering & Completion

    5. O ESTFIELD RAIN UGERS PERATION MK 130 P 61’ - 81’ LUS X 2. When auger is clear of grain, disengage PTO drive. 3. Shut down and lock out tractor. MERGENCY ESTART 1. If cleanout covers or safety doors have been opened or removed, close or replace them before restarting the unit.
  • Page 62 5. O PERATION ESTFIELD RAIN UGERS MK 130 P 61’ - 81’ LUS X OWERING 1. Raise the intake feed hopper. Do not attempt to lift by hand. 2. Reconnect hose coupler to tractor, if disconnected. 3. Disconnect PTO driveline from tractor before lowering. 4.

  • Page 63: Maintenance & Storage

    6. M & S ESTFIELD RAIN UGERS AINTENANCE TORAGE MK 130 P 61’ - 81’ LUS X 6. Maintenance & Storage Warning: Before continuing, please reread the safety information relevant to this section at the beginning of this manual. Failure to follow the safety instructions can result in serious injury, death, or property damage.
  • Page 64 6. M & S AINTENANCE TORAGE ESTFIELD RAIN UGERS MK 130 P 61’ - 81’ LUS X Area Maintenance Procedures Frequency Keep a film of grease on gears. Regularly Oil the bushings, drum shaft, and ratchet. • Take care not to get oil or grease on brake discs. Occasionally Service winch with auger in fully lowered position Winch...
  • Page 65 6. M & S ESTFIELD RAIN UGERS AINTENANCE TORAGE MK 130 P 61’ - 81’ LUS X ECOMMENDATIONS LUBE RECOMMENDATIONS Interval Location Amount Cross & Bearing 1 pump 8 hours 8 hours Telescoping Members 4-8 pumps CV Ball & Socket 1-2 Pumps 8 hours a.
  • Page 66 6. M & S AINTENANCE TORAGE ESTFIELD RAIN UGERS MK 130 P 61’ - 81’ LUS X Area Maintenance to Perform Frequency Check oil levels in both gearboxes. They should be half full of EP90 lube oil. • Fill as needed; you may need a flexible funnel. If you notice excessive loss of oil, check more fre- quently and repair problem.

  • Page 67: General Storage Procedure

    6. M & S ESTFIELD RAIN UGERS AINTENANCE TORAGE MK 130 P 61’ - 81’ LUS X Figure 6.2 6.2. GENERAL STORAGE PROCEDURE O PROTECT AUGER IN STORAGE DURING THE OFF SEASON 1. Lower the auger to full down position with slight tension on the cable. 2.
  • Page 68 6. M & S AINTENANCE TORAGE ESTFIELD RAIN UGERS MK 130 P 61’ - 81’ LUS X 4. Check oil level in gearbox and refill if necessary (half full only). 5. Replace any damaged parts and decals. 6. Check and perform general maintenance before using auger. 7.

  • Page 69: Troubleshooting

    7. T ESTFIELD RAIN UGERS ROUBLESHOOTING MK 130 P 61’ - 81’ LUS X 7. Troubleshooting Problem Possible Cause Remedy Determine if noise originates in main or swing away section of auger. Disconnecting the chain from the sprocket drive can assist in narrowing down the source of the problem.
  • Page 70 Early series cross-link or non- Ensure new “E” series cross links and genuine Westfield part used. Westfield replacement parts are used. Telescoping part of PTO shaft Pull out or lengthen tractor drawbar to maintain bottoming out.
  • Page 71 61’ - 81’ LUS X Problem Possible Cause Remedy Replace with correct part number. Westfield Incorrect shear bolt type. shear bolts are specifically designed to provide correct driveline protection. Frequent use of an incorrect shear bolt size can Shear bolt hole worn out-of- wear the mounting hole creating a “scissor...
  • Page 72 7. T ROUBLESHOOTING ESTFIELD RAIN UGERS MK 130 P 61’ - 81’ LUS X 30259...

  • Page 73: Appendix

    These tests used a hydraulic pressure gauge (4000 psi maximum rating) and are solely intended to be used as a guide. The psi requirements for specific augers may vary slightly. Should your auger require a significantly higher psi to raise, contact either your dealer or Westfield Industries. AUGER SIZE MK130 Plus 13"...
  • Page 74 8. A PPENDIX ESTFIELD RAIN UGERS MK 130 P 61’ - 81’ LUS X 30259...

  • Page 75: Warranty

    Company, or to our factory, with transportation charges prepaid. This warranty does not obligate Westfield Industries Ltd. to bear the cost of labor in replacing defective parts. Any defects must be reported to the Company before the end of the one year period.
  • Page 76 Westfield is a Division of Ag Growth Industries LP Part of the Ag Growth International Inc. Group P.O. Box 39 Rosenort, Manitoba, Canada R0G 1W0 Phone: (866) 467-7207 (Canada & USA) Fax: (866) 768-4852 website: www.grainaugers.com email: sales@grainaugers.com © Ag Growth Industries Limited Partnership 2009...

This manual is also suitable for:

Mk 130 plus 71Mk 130 plus 81
