mangOH Yellow Hardware Architecture Manual page 3

Patents
Document
details
Copyright
Disclaimer
Trademarks
Revision
History
Revision Release date
number
1 September 2019
1.01 September 2019
2 October 2019
Rev 2 Oct.19
This document contains information which is proprietary to Sierra Wireless Inc. and is
licensed pursuant to Creative Commons Attribution 4.0 International License.
Title: mangOH Yellow Hardware Architecture Guide
Author: Sierra Wireless
Source: https://mangoh.io
© 2019 Sierra Wireless. Licensed under the Creative Commons Attribution 4.0
license, http://creativecommons.org/licenses/by/4.0/
Indicate any modifications made to the original document.
®
mangOH and the mangOH logo are trademarks of Sierra Wireless.
Other trademarks are the property of their respective owners.
Changes
Document created
Document formatting adjustments
Minor formatting corrections
Corrected schematic component numbers where needed
Added notes to not connect at same time IoT card and Expansion connector device
Corrected SW403 Notes (Table 2-1)
Added IoT Edge Connector pin drawing and schematic excerpt
Updated GPIO Configuration Figure 2-9
Updated 2.4.16 Expansion connector description and table details
Updated 2.4.20 UART1
Updated Expansion Connector Configuration Figure 2-26
Removed Regulatory Compliance chapter
