4 Prepare Site

Your U-Line product has been designed for either free-standing or
built-in installation. When built-in, your unit does not require
additional air space for top, sides or rear. However, the front grille
must NOT be obstructed and clearance is required for an
electrical and water connection in the rear.
IMPORTANT IMPORTANT
Units can NOT be installed behind a closed cabinet door.

Cut-Out Dimensions

ADA15IM Models

See Electrical
Specifications
for Power Supply
32"
to
33"
8"
BI-95(B)(WH) Models
Filler Panel (Not Provided by U-Line) –
May Be Added Above or Below Unit
to Enclose for a Built-In Look
Typical
Counter
Height
34-1/4"
to
35-1/8"
Cut-Out
Height
25-1/16"
8"
23-3/4"
Minimum
15-1/4"
18-1/2" Minimum
See Electrical
Specifications
for Power Supply
14-3/16"
BI-98 / SS-98 Models
Filler Panel (Not Provided by U-Line) –
Typical
Counter
Height
34-1/4"
to
35-1/8"
Cut-Out
Height
27-3/8"

BI-2115 Models

34-1/8"
to
35-1/8"
SP-18 Models
Filler Panel (Not Provided by U-Line) –
Needed to Attach Mounting Flange on Unit
Cut-Out
Height
18-7/8"
3/4"
Minimum Flange
Mounting Area
Prepare Site
May Be Added Above or Below Unit
to Enclose for a Built-In Look
21-1/2"
Minimum
See Electrical
Specifications
for Power Supply
8"
15-3/16"
See Electrical
Specifications
for Power Supply
8"
15-1/4"
3/4"
Minimum Flange
Mounting Area
26" Minimum
See Electrical
Specifications
for Power Supply
14-1/4"
Cut-Out Width
Minimum Flange
Mounting Area
23-7/8"
Minimum
8" Height
From Floor
Toe Kick
3/4"
