Elite Linnea Series Assembly Instructions

www.elite-furniture.co.uk
...Helpline 01405 746 000
Range
Linnea
Desk Style
Double Bench with Shared Inset Leg
2 Person Assembly
Please Read This Leaflet
Assembly Instructions
Before Assembly
Tools Required
Pozi Screwdriver
Q
B
A A
Components
A A Desktop Panels x 2
B
Leg Frames x 2
C
Shared Inset Leg Frame x 1
D D Top Rails x 4
E E
Arms x 3/4
F F Double Bench Cable Tray x 1
Leg Frame Bolts (M8x16)
G
x 16
Shared Leg Frame Bolts (M8x16)
H x 16
Top Rail Bolts (M6x20)
J J
x 12
Slider Screws (30mm Confirmat)
K K
x 12
L L Sliders x 12
M
Screen Brackets x 2
N Screen Bracket Screws x 2
P
Screen x 1
5mm Allen Key
or Hex' Screwdriver
C
F F
E E
D D
G H J J K K
L L N
Orange: Double Bench
Yellow: Double Bench with Shared Inset Leg
Green: Double Bench Screen
P
