Operating Instructions
Wireless Speaker System
SC-TMAX5
Model No.
Thank you for purchasing this product.
For optimum performance and safety, please read these instructions carefully.
Please keep this manual for future reference.
"EB" indicates the United Kingdom model.
EB GN
TQBJ2251

Advertisement

Table of Contents
loading

Subscribe to Our Youtube Channel

Summary of Contents for Panasonic SC-TMAX5

  • Page 1 Operating Instructions Wireless Speaker System SC-TMAX5 Model No. Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully. Please keep this manual for future reference. “EB” indicates the United Kingdom model. EB GN TQBJ2251...
  • Page 2: Table Of Contents

    • The mains plug is the disconnecting device. Install this Using the “Panasonic MAX Juke” app ....8 unit so that the mains plug can be unplugged from the Wireless charging .
  • Page 3: Caution For Ac Mains Lead

    CAUTION! Caution for AC mains lead Unit (For the AC mains plug of three pins) • To reduce the risk of fire, electric shock or product damage, For your safety, please read the following text carefully. – Do not install or place this unit in a bookcase, built-in This appliance is supplied with a moulded three pin mains cabinet or in another confined space.
  • Page 4: Supplied Accessories

    • For further support on your product, please visit our website: www.panasonic.co.uk Placement Direct Sales at Panasonic UK • Order accessory and consumable items for your product You can place this system vertically or horizontally. with ease and confidence by phoning our Customer Communications Centre Monday –...
  • Page 5: Power Sources

    Using an external power bank Power sources Connect the external power bank (not supplied) to the The unit can be switched on by using AC power supply micro USB port at the rear of the unit. source. If AC power supply source is not available, you Hold the unit when connecting or disconnecting the can use an external power bank.
  • Page 6: Overview Of Controls

    Overview of controls Marking of centre charging area (~9) CHARGE Wireless charging area (~9) Select the audio source Press repeatedly to select the source: CHARGE indicator BLUETOOTH D.BASS indicator To start Bluetooth pairing, press and hold until the ® Enhance the bass sound (~8) Bluetooth indicator blinks.
  • Page 7: Preparing Media

    If prompted for a passkey, input “0000” or “1234”. The device connects with this system automatically after pairing is complete. The MAC address (example: 6C:5A:B5:B3:1D:0F) may be shown before “SC-TMAX5” is shown. Once the Bluetooth device is connected, the ®...
  • Page 8: Media Playback

    ® • Depending on the Bluetooth device, some operations may ® not work. • You can control this unit using the “Panasonic MAX Juke” app (~right). Sound effects █ Remote control The D.Bass effect is switched on by default. Press [D.BASS] to switch on or switch off the You can control the unit using the app.
  • Page 9: Wireless Charging

    Note: Wireless charging • Charging will not starts if you put the smarphone on the charging panel when the unit is in standby mode. • Charge only one smartphone each session. You can charge a Qi-compatible smartphone by placing it •...
  • Page 10: External Music Device

    ® • Components and cables are sold separately. • You can change the settings using the “Panasonic MAX • You can control this unit using the “Panasonic MAX Juke” Juke” app (~8). app (~8). Demo play The unit will play the built-in demonstration song for one minute.
  • Page 11: References

    Bluetooth SIG, Inc. and any use of area and the smartphone. Remove any foreign object. such marks by Panasonic Corporation is under license. • The smartphone is not recognised correctly. Remove the Other trademarks and trade names are those of their smartphone, wait until the CHARGE indicator goes off, and respective owners.
  • Page 12 The device is connected but audio cannot be heard through the system. • For some built-in Bluetooth devices, you have to set the ® audio output to “SC-TMAX5” manually. Read the operating instructions of the device for details.
  • Page 13: Led Indicators

    LED indicators The indicators show the condition of this system. The indicator patterns illustrated below are shown during normal operational conditions. They do not refer to the indications of a problem. Indicators Description The indicator blinks 5 times. D.BASS CHARGE •...
  • Page 14: Specifications

    Specifications █ General █ Bluetooth section ® Version Bluetooth Ver. 4.2 ® Power supply AC 220 V to 240 V, 50 Hz Class Class 1 Power consumption 50 W Supported profiles AVRCP, A2DP, SPP Power consumption in standby mode (approximate) Frequency band 2.4 GHz band FH-SS With Bluetooth...
  • Page 15 1. Subject to the conditions of this warranty Panasonic or its Authorised Service Centre will perform necessary service on the product, without charge for parts or labour, if in the opinion of Panasonic the product is found to have a manufacturing defect within one (1) year or (12 months) (the “warranty period”) from the date of purchase appearing on your purchase receipt.
  • Page 16 Disposal of Old Equipment Only for European Union and countries with Declaration of Conformity (DoC) recycling systems Hereby, “Panasonic Corporation” declares that this This symbol on the products, packaging, product is in compliance with the essential requirements and/or accompanying documents means and other relevant provisions of Directive 2014/53/EU.
