Remote
SC-TMAX50
Control
This service information is designed for experienced repair technicians only and is not designed for use by the general
public. It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting
to service a product. Products powered by electricity should be serviced or repaired only by experienced professional
technicians. Any attempt to service or repair the product or products dealt with in this service information by anyone else
could result in serious injury or death.
There are special components used in this equipment which are important for safety. These parts are marked by
in the Schematic Diagrams, Circuit Board Diagrams, Exploded View and Replacement Parts List, It is essential that
these critical parts should be replaced with manufacturer's specified, parts to prevent shock, fire or other hazards, Do
not modify the original design without permission of manufacturer.
Model No.
Colour:(K)...........Black Type
WARNING
IMPORTANT SAFETY NOTICE
Wireless Speaker System
SC-TMAX50PU
SC-TMAX50PR
SC-TMAX50E
© Panasonic Corporation 2019
Unauthorized copying and distribution is a violation of law.
PSG1909002CE
