Phonak ComPilot II How To Connect

How to Connect
with ComPilot II
12
5
Device Description
1.
Main
2.
Volume up/down
3.
Home
4.
Connect
5.
On/Off switch
General Operation
To switch on, slide the On/Off switch on the side of the ComPilot II down.
•
The power indicator light will continue to fade in and out green during use.
To switch off, slide the On/Off switch on the side of the ComPilot
•
II up. The power indicator light will flash red and then turn off.
• When charging with the mini-USB power cord, the power indicator
light will be solid red and when fully charged will be solid green.
10
11
1
2
6
6.
Microphones
7.
Audio input 3.5 mm jack
8.
Roger/FM (Europlug)
9.
Charging input (mini-USB)
10.
Audio
13
7 8 9
11.
12.
13.
4
3
Power
Neckloop sockets
Neckloop
