Lebensstil Kollektion LKCHi-9120 Instruction Manual

Hide thumbs

Advertisement

Quick Links

Cooker Hood
Instruction Manual
LKCHi-9120
www.lebensstilkollektion.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the LKCHi-9120 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lebensstil Kollektion LKCHi-9120

Summary of Contents for Lebensstil Kollektion LKCHi-9120

  • Page 1 Cooker Hood Instruction Manual LKCHi-9120 www.lebensstilkollektion.com...
  • Page 2 Thank you for choosing Lebensstil Kollektion appliance. This instruction manual is designed to help you through each step of owning your new appliance, from installation to use and maintain it. Please read it carefully before you start using your product.

  • Page 3: Table Of Contents

     Content  Electrical Safety Warnings  Electrical Connection  Introduction Connection  Technical Specification  Ventilation modes  Installation 5 - 6  Touch Control Panel  Troubleshooting...

  • Page 4: Electrical Safety Warnings

     Electrical Safety Warnings  DO NOT handle the electricity connection points and plug with wet hands at all time.  The appliance must be earthed.  The power supply card shall not be in contact with any parts of the appliance that produce theat.

  • Page 5: Introduction Connection

     Introduction Connection Chimney Mounting Bracket Upper Chimney Cover Lower Chimney Cover Flexible Ducting Host Main Body Oil Filter...

  • Page 6: Technical Specification

     Technical Specification Input Power : 154 Watt Supply Voltage : 220 – 240 v 50-60 Hz LEP Lamp : 4 Watt * 1 Fan Speed : 9 speeds...

  • Page 7: Ventilation Modes

     Ventilation modes You can choose to install the hood as a ducted or recirculation mode.  Ducted Mode (Vented Mode) In the ducted mode, air is drawn into the hood, fat are trapped by oil filters. Odors, fumes and condensation are then expelled to the outside.

  • Page 8: Installation

     Installation  Wall Mounting 1. Determine height between cooker hob and base of hood. 2. Mark all to suit all bracket locations. Drill holes of 50mm depth at the selected drilling position. 3. Insert the expansion tubes to fix the bracket onto the wall. 4.
  • Page 9  Chimney assembly Upper chimney 1. Slightly widen the two sides of the upper chimney and hood them behind the mounting brackets, ensuring that they are well seated. 2. Secure the sides of the brackets using screws. Lower Chimney 1. Slightly widen the two sides of the chimney and hook them between the upper chimney and the wall, ensuring that they are well seated.

  • Page 10: Touch Control Panel

     Touch Control Panel Light Up/Down ON/OFF ON/OFF: To switch on the appliance. Touch the ON/OFF with your finger tip. Touch twice On/Off button to switch off the appliance. * All lights will go off after that. Up/Down: To adjust the fan speed by slide to the right to increase or left to reduce the level with your finger tip.

  • Page 11: Troubleshooting

     Troubleshooting Symptoms Possible Cause Solution Motor and light do Power plug is not inserted completely Check the plug and insert it not operate properly The light bulbs are blown Replace the bulbs The wire and / or cable is disconnected Contact us The light’s transformer is damaged Contact Us...
  • Page 12 Customer Careline 1800-881-770 Distributed by Kollektion Distribution Sdn. Bhd. 11b, Jalan 223, Section 51A 46100 Petaling Jaya Selangor, Malaysia...
