- Page 1 Instruction Manual Island Hood Model: LKCH-9802BGS Before operating this unit, please read these instructions completely.
-
Page 2: Table Of Contents
CONTENT INTRODUCTION..............SAFETY PRECAUTION............ISLAND MODEL INSTALLATION........... FITTING CARBON FILTER............ OPERATION................MAINTENANCE..............TROUBLESHOOTING............ENVIRONMENTAL PROTECTION......... -
Page 3: Introduction
INTRODUCTION Thank you for choosing Lebensstil Kollektion Island Hood. This instruction manual is designed to provide you with all required instructions related to the installation, use and maintenance of the appliance. In order to operate the unit correctly and safely, please read this instruction manual carefully before installation and usage. - Page 4 This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
-
Page 5: Island Model Installation
ISLAND MODEL INSTALLATION... - Page 6 1) Position the hanging plate on the ceiling and mark the position of the screw holes. The hanging plate should be securely fixed to the ceiling. 11 x ST6 (40mm) screws for wooden ceiling 8 x expansion bolts for cement ceiling 2) Fix the angle bars to the hanging plate, using the 8 x M5 screws.
- Page 7 5) If the glass canopy has not been pre-assembled by the factory, it should be fixed to the top of the main body of the cooker hood at this stage. 6) Lift the main body of the cooker hood towards the angle bar and fix it into position using the 16 x M5 screws.
-
Page 8: Fitting Carbon Filter
FITTING CARBON FILTER If you do not have an outlet to the outside, exhaust pipe is not required Activated carbon filter can be used to trap odors. In order to install the activated carbon filter, the grease filter should be detached first. -
Page 9: Operation
OPERATION Invisible Touch Control STANDBY MODE will flash slowly to indicate system is in After plugging in, STANDBY MODE On/Off button Used for turning off the fan. When plugged into power supply, press this button for 3 seconds and all buttons will illuminate with all functions ready. Low Speed button Used for ventilation in the kitchen. -
Page 10: Maintenance
MAINTENANCE Before cleaning switch the unit off and pull out the plug. I. Regular Cleaning Use a soft cloth moistened with warm and mildly soapy water or household cleaning detergent. Never use metal pads, chemical, abrasive material or stiff brush to clean the unit. II. -
Page 11: Troubleshooting
TROUBLESHOOTING Fault Cause Solution Light The fan blade is jammed. Switch off the unit and repair by does qualified service personnel only. work The motor is damaged. Light bulb burned. Replace the bulb with correct rating. Both light and fan do not work Power cord is loose. - Page 12 Tel: +603-7954 5200 Fax: +603-7954 5705 Careline...
