EC REGULATIONS AND SECURITY ATTENTION: Do not disassemble or modify the device in any way. This symbol warns of the presence of dangerous un-insulated voltages inside some of the components, of sufficient magnitude to expose people to risk of electronic shock. This symbol draws attention to important use and maintenance instructions in the manual that accompanies the unit.
Page 7
SAFETY INSTRUCTIONS Wiring connected to hazardous voltage requires installation by qualified personnel or the use of ready-made flexible cables. For your security, your equipment must be connected to an electrical outlet with grounding connection protection. Since the plug is used to disconnect the device, the operating electrical outlet must be in an easily accessible place.
Page 8
SAFETY INSTRUCTIONS Environment This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harm- ful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to ra- dio communications.
SYSTEM DESCRIPTION The DynamicCableRetract is a patented motorised cable retraction system. Simply touch a button and a 600 mm cable will appear in a smooth and silent move. Push to deploy and push to retract: extremely easy and neat. The DynamicCableRetract is compact, elegant and robust. It provides a harmonic and silent motorised movement for a seamless integration in furniture.
Not complying with these direction will result in a loss of the Arthur Holm warranty. Albiral Display Solution S.L. shall not be held liable for any loss or injury...
Page 11
MOUNTING INSTRUCTIONS Information Cut a hole in the table surface where the DynamicCableRetract top surface will be installed Ensure that there is enough space under the table to install the DynamicCableRetract. The output of the cable and connections of the device are in the back side (As shown in the picture).
Page 12
MOUNTING INSTRUCTIONS Preparing the table: Cut-out If the cut-out in the table can not be made with precision, a cover plate is supplied in order to hide the cut imperfections. DynamicCableRetract can be installed in tables with a thickness from 10mm [0.39] to 50mm [1.97].
Page 13
MOUNTING INSTRUCTIONS Preparing the table 1- Make the cut-out according to 2- Place mounting jig in the table the provided pattern hole in the bracket as indicated below. Mounting Jig table surface. 3- From below the table, place 4- Align the bracket with your the mounting jig with the raised table axis and mark the screws square into the already made...
Page 14
MOUNTING INSTRUCTIONS Mounting table brackets Place the brackets as shown in the drawing and tighten them down using the nuts (M4). Place the vertical adjustment screws (2+2) into the bracket so that the tip of the screw is flushed with the upper side of the bracket.
Page 15
MOUNTING INSTRUCTIONS Preparing the DynamicCableRetract 1- Place the DynamicCableRetract housing with the brackets into the installed table brackets as shown on the drawing below. Insert the two M6 nuts. Tighten each gradually until DynamicCableRetract top plate surface is flush with of the table surface or cover plate: - For the standard installation, flush the top plate surface with the top surface of the table.
Page 16
MOUNTING INSTRUCTIONS Mounting the DynamicCableRetract 3- To level the device top surface of the device with the table, screw the (x4) M6x60 screws gradually. There is a M6 screw in every corner, tighten one more than others you can level the DynamicCableRetract top surface of the table or cover plate.
Page 17
MOUNTING INSTRUCTIONS Mounting the DynamicCableRetract With the DynamicCableRetract is supplied a cover plate. This cover plate can help to hide the cut out of the table if it cannot be made properly. Follow next steps to stick the cover plate to top surface. 1- Clean the table Surface where the cover plate is goning to be taped.
INPUT CONNECTORS AHnet: RJ45 CAT5 connector for addressable RS422 control. There is a loop through connector to use as signal RS422 output. Up to 30 devices can be connected on the same RS422 bus. Termination: Activate (ON) the termination, ONLY on the last unit of the RS422 bus.
AHLINK AHlink is used to control and set-up the unit. By default, the AHlink signal on the unit is deactivated. To activate the AHlink signal, press for 5 seconds the external Up and Down retractable cable button located on the cover plate. The unit automatically deactivate the AHlink signal if there is no device (mobile or tablet) connected for more than 2 minutes.
Page 20
AHLINK If the device does not appear on the window, the AHlink signal is not active. The AHlink name always begins with AH characters and the fourth last MAC AHlink address. Select the device to control and set-up the unit. When selecting the device, the first page will upload on the mobile phone.
Page 21
AHLINK SERIAL Serial number of the unit Firmware version CONTROL Move the HDMI cable up and down COMMAND Information of the last AHnet command received from RS422 port INFORMATION OF THE SENSOR STATUS S1: Activate when the HDMI cable is inside S2: Active when the cable cover trap is open S3: Deactivated when the cable is at the...
AHNET PROTOCOL Communications protocol COMMUNICATION RS422 CONNECTION RJ45 WIRING CAT-5 Speed and configuration BAUD RATE 38400 DATA BITS PARITY NONE STOP BITS Wiring Diagram 1. Data TX + 2. Data TX – 3. Data RX + 4. NC 5. NC 6 .Data RX RJ-45 7.
Page 23
AHNET PROTOCOL AHnet protocol Using 5 bytes communication: BYTE 0 START BYTE BYTE 1 ADDRESS BYTE BYTE 2 COMMAND BYTE BYTE 3 VALUE 1 BYTE 4 VALUE 2 Commands COMMAND DESCRIPTION RESPONSE FA XX 08 01 00 GO UP FB XX 08 01 00 FA XX 08 00 00 GO DOWN FB XX 08 00 00...
Page 24
AHNET PROTOCOL TOP POSITION DOWN POSITION BUTTON LOCKED (1) FAILURE IN THE SYSTEM (1) To send an order to all the devices, you must use the address: F6 Hex. (Byte1) In this case, the units do not send a reply. Use shielded (FTP) RJ45 cables for RS422 BUS.
INFORMATION ON DISPOSAL FOR USERS OF WASTE ELECTRICAL & ELECTRONIC EQUIPMENT This symbol on the products and/or accompanying documents means that used electrical and electronic products should not be mixed with general household waste. For proper treatment, recovery and recycling, please take these products to the designated collection points, where they will be accepted on a free of charge basis.
WARRANTY TERMS AND CONDITIONS Albiral Display Solutions warrants this product against manufacturing defects and workmanship for a period of two (2) years from the date of purchase, subject to the conditions below. Electrical, electronic boards, engine, mechanical parts, accessories and power supply are warranted against manufacturing defects and workmanship for a period of two (2) years from the date ot purchase.
