- Page 1 NOOK ™ POSITIONING CHAIR USER MANUAL...
- Page 2 CAUTION! Manufacturer takes responsibility for proper usage of the device only when the product was purchased from qualified Akces-Med employee or at specialized medical store! CAUTION! AKCES-MED Ltd. reserve the right to introduce technical and trading changes in the content of the instruction without warning.
-
Page 3: Table Of Contents
NOOK CONTENTS The purpose of user manual ....................5 Indications for use .........................5 3. General characteristics of chair..................6 3.1. Standard equipment....................6 3.2. Additional equipment....................6 4. Size table..........................7 5. Description how to use chair....................8 5.1 The adjustment of chest support..……..............8 5.2 The adjustment of removable abductor .............9 5.3 The adjustment of pelvic belt ................9... - Page 4 If you have any questions or remarks, do not hesitate to contact with us: Medical consultant: mobile +48 508 382 509 Akces-MED Sp. z o.o.: ph. +48 17 864 04 77 e-mail: export@akces-med.com...
-
Page 5: The Purpose Of User Manual
The present user manual contains basic information which is essential for proper usage, preparation, maintenance, cleaning and guarantee conditions NOOK™ static standing frame. User manual should be kept in easily accessible place. It is designed for people who look after the disabled, and for both doctors as well as physiotherapists who operate the device. -
Page 6: General Characteristics Of Chair
NOOK GENERAL CHARACTERISTICS OF CHAIR 3.1. Standard equipment 1. Base 2. Sit 3. Removable abductor 4. Pelvic support 5. Pelvic belt 6. Chest support 7. Chest belt 3.2 Additional equipment NKK_003 NKK_102 NKK_104 Adjustable headrest Soft cover for tray Head supporting belt... -
Page 7: Size Table
NOOK SIZE TABLE SIZE TABLE Symbol Measurement Unit Size 2*** Universal size Indicative user height* [cm] < 160 < 160 Seat width [cm] Seat depth [cm] 29 – 33,5 Backrest height [cm] 47 – 58 35 – 46 Pelvic supports width... -
Page 8: Description How To Use Chair
NOOK DESRIPTION HOW TO USE CHAIR Before the use of the device you have to adjust it to the size of the user. Therefore, you should take measurement of the patient. It is really necessary to adjust the device in a way which is described in the further part of this chapter. -
Page 9: The Adjustment Of Removable Abductor
NOOK 5.2 The adjustment of removable abductor When you adjust distance it is necessary to: Loosen knob with the aid of Allen key (fig.5), ź Adjust the desired position (fig.6), ź After obtaining the appropriate distance, screw the knob. ź... -
Page 10: The Adjustment Of Chest Belt
NOOK The adjustment of chest belt In order to adjust the belt it is necessary to: Detach Velcro from this belt, ź Adjust length of the belt to the patient ź After adjusting the appropriate length, it is important to fasten the belt ź... -
Page 11: Additional Equipment
NOOK ADDITIONAL EQUIPMENT Tray NKK_403 Tray has to be mounted after placing the child in the chair. You have to insert the tray under the removable abductor until safety pin will slam (fig.10). In order to dismantle the tray it is necessary to pull away and hold the safety pin, after which you have to take out the tray. -
Page 12: Headrest
NOOK fig.13 fig.14 Headrest NKK_104 Firstly, it is necessary to dismantle pillow of the pelvis pelotte. You should insert headrest into slot (fig.15), screw it by means of bolt (fig.16) and mount the pillow on Velcro. fig.15 fig.16 Regarding the alignment of the head... -
Page 13: Head Supporting Belt
NOOK Head supporting belt NKK_102 In order to mount the head supporting belt, you should: Fasten it to the side parts of the head ź rest with the aid of Velcro Adjust the length of the belts to the ź... -
Page 14: The Use Of Chair
NOOK THE USE OF CHAIR CAUTION! NOOK™ has to be used with compliance to guidelines included in this user manual. Remember to use the product only with someone who is trained and knowledgeable. Do not forget to prepare both product as well as patient before using NOOK™! -
Page 15: How To Use Chair
NOOK 7.2. How to use chair 1. Before use it is necessary to: Unfold the device; § Place the device on even ground; § Make sure that all parts are serviceable, correctly mounted and stable; § Block brakes (only in chair with castors);... -
Page 16: Sitting Position
NOOK 7.3. Sitting position Clinical research shows that it is really beneficial for children to adopt sitting position so as to stimulate psychomotor development. Moreover, adopting sitting as well as standing position is advantageous for disabled due to the fact that it has a positive influence on organs and systems. - Page 17 NOOK CAUTION! Incorrect adjustment of the device can lead to side effects such as: fainting, body deformities, overloading joints. It is highly advisable to adjust the device before every use of a standing frame. This adjustment has to be done only by a trained person or therapist.
-
Page 18: Safety Rules
NOOK SAFETY RULES CAUTION! NOOK™ chair has to be used in compliance with guidelines in this user manual. It is highly important to consult either doctor or physiotherapist in order to make right decision concerning the choice of chair and its size. It is also essential to familiarize with the guidelines described in user manual before using the device. - Page 19 NOOK 2. It is forbidden to use chair for different purposes that it is intended to. 3. It is forbidden to use chair when it is damaged or any part is missing. 4. It is forbidden to leave the patient unattended.
- Page 20 CAUTION! This device can be only used inside the buildings. 1) AKCES-MED Sp. z. o. o sells products free from manufacturing defects or faults. 2) Manufacturer gives the purchaser 24-month guarantee from the date of purchase. All defects revealed during warranty period will be repaired free of charge.
-
Page 21: Maintenance And Cleaning
4. It is forbidden to clean upholstery with strong chemical agents such as solvent or caustic chemicals. CAUTION! Akces-MED Sp z o. o takes no responsibility for damages caused by use of wrong clearing agent. 5. It is forbidden to soak upholstery during cleaning. Remember that upholstery has to be always dry before using. - Page 22 NOOK CAUTION! Remember that upholstery has to be always dry before using! Before using it is necessary to: clean wheels; § check if base as well as wheels are correctly mounted; check if brake § stops turning wheel make sure that all wooden parts e.g. tray don't have splinters §...
-
Page 23: Labelling
NOOK LABELLING Symbols 10.1. Declaration that the product Protect from sunlight meets the essential requirements Catalog number Storage temperature limitation Serial number Relative humidity storage Please read the manual Dry vertically instructions before use Attention! Do not chlorinate Producer Do not iron... - Page 24 ORTHOPAEDIC DEVICES MANUFACTURER Akces-MED Sp. z o.o. Jasionka 955B 36-002 Jasionka tel. (17) 864 04 77 www.akces-med.com e-mail: export@akces-med.com Authorised Dealer Date of issue: 14.05.2012 The last update: 04.02.2019...
