Appendix b: Supported Lugs For Termination

TAbLE 6. CHASSIS GROUND CONNECTIONS
WIRE GAUGE LUG BARREL TYPE
#4 AWG Long
TAbLE 7. INPUT CONNECTIONS
WIRE GAUGE LUG BARREL TYPE
#2 AWG Short; narrow tongue
#2 AWG Standard
#2 AWG Long
1/0 Short
1/0 Standard
1/0 Long
1/0 Long; narrow tongue
2/0 Short
2/0 Standard
2/0 Long
4/0 Short
4/0 Standard
4/0 Long
COMM/NET PART MANUFACTURER
NUMBER
538-085-10 Burndy
COMM/NET PART MANUFACTURER
NUMBER
538-173-10 Burndy
538-158-10 Burndy
538-089-10 Burndy
538-350-10 Burndy
538-125-10 Burndy
538-091-10 Burndy
538-260-10 Burndy
538-357-10 Burndy
538-313-10 Burndy
538-114-10 Burndy
538-410-10 Burndy
538-124-10 Burndy
538-122-10 Burndy
MANUFACTURER PART CRIMP DIE REQUIRED (HYDRAULIC)
NUMBER
YAZV4C2TC14FX Burndy U4CRT, W4CRT, W4CVT, X4CRT
MANUFACTURER PART CRIMP DIE REQUIRED (HYDRAULIC)
NUMBER
YAV2CL2NT14FX Burndy U2CRT, W2CVT, W2CRT, X2CRT
YAV2CL2TC14FX Burndy U2CRT, W2CRT, W2CVT, X2CRT
YAZV2C2TC14FX Burndy U2CRT, W2CVT, W2CRT, X2CRT
YAV25L2TC14FX Burndy U25RT, W25VT, W25RT, X25RT
YAV25L2NT14FX Burndy U25RT, W25VT, W25RT, X25RT
YAZV252TC14FX Burndy U25RT, W25VT, W25RT, X25RT
YAZV252NT14FX Burndy U25RT, W25RT, X25RT, W25VT
YAV26L2TC14FX Burndy U26RT, W26VT, W26RT, X26RT
YAV26L2NT14FX Burndy U26RT, W26VT, W26RT, X26RT
YAZV262TC14FX Burndy U26RT, W26VT, W26RT, X26RT
YAV28L2TC14FX Burndy U28RT, W28VT, W28RT, X28RT
YAV28L2ENT14FX Burndy U28RT, W28VT, W28RT, X28RT
YAZV282TC14FX Burndy U28RT, W28VT, W28RT, X28RT
