Section 6: Product Specifications
6.1 Electrical Specifications
NOTICE
USE bUSSMANN TPA TYPE FUSES ONLY.
FUSES MUST CARRY A 10kA INTERRUPT RATING.
TAbLE 5. TPA 250 SERIES FUSE PANEL SPECIFICATIONS
Type of Input
Circuits
Input Voltage (+/- 0%)
Input Current
Short Circuit Withstand
Maximum Fuse Size
Maximum Per Circuit Current
Max Operating Altitude
Max Ambient Temperature
Width
Height
Depth (Not Including Lacing Bar Kits)
Weight
UL File Number
UL Standard
MODELS:
016-2121-10
016-2123-10
016-2125-10
016-2127-10
Single Input
12
-42 to -60V DC
250A Max
10kA
50A TPA
40A
2000 m
50º C
17 in.
1.75 in.
18 in.
8.5 lbs.
E473904
ANSI/UL 60950-1
MODELS:
016-2122-10
016-2124-10
016-2126-10
016-2128-10
Dual Input (A/B)
12 (6A/6B)
-42 to -60V DC
250A Max
10kA
50A TPA
40A
2000 m
50º C
17 in.
1.75 in.
18 in.
8.5 lbs.
E473904
ANSI/UL 60950-1
