KULLANIM KILAVUZU
USER GUIDE
P-3
DÜŞÜŞ DURDURMA VE
KONUMLANDIRMA
KEMERİ
FALL ARREST AND
WORK POSITIONING
HARNESS
A
Ürün Kullanım Raporu
Product Usage Report
A.1-
Ürün Seri No
Serial Number
: .............................................................................
A.2-
Üretim Tarihi
Date of Production
: .............................................................................
Sevk Tarih
A.3-
Date of Delivery
: .............................................................................
Kaşe İmza
A.4-
Stamp & Signature
: .............................................................................
...............................................................................
..............................................................................
...............................................................................
...............................................................................
..............................................................................
...............................................................................
A.5-
Ürün İlk Kul. Tar.
Date of first use
: .............................................................................
Kullanıcı Ad/Soyad
A.6-
Name&Surname of user : .............................................................................
B
Ürün Yıllık Kontrolleri
Annual Product Inspections
No
Yıllık Kontrol Tarihi
Gelecek Yıl Kontrol Tarihi
Nu
Inspection Date
Next Inspection Date
1
2
3
4
5
6
7
ROC_P3_KLK_01_161117_B
Kontrol Eden Ad/Soyad
Inspected by
C
P-3
(TR)
Düşüş Durdurma ve Konumlandırma Kemeri
(EN)
Fall Arrest and Work Positioning Harness
EN 361:2002, EN 358:1999
Test eden Onaylı Kuruluş / Tested by Notified Body
TÜV SÜD Product Service GmbH (No 0123) Daimlerstraße 11
85748 Garching - Germany
T: + 49/89/361965-483 W: www.tuev-sued.de
D
(TR)
Kemer Ankraj Noktaları (Minimum Kopma Mukavemetleri - Şekil-1)
(EN)
Harness Anchorage Points (Minimum Breaking Strength - Figure-1)
EN361:2002
15 kN
A
A/2+A/2=
15 kN
EN358:1999
15 kN
Şekil-1 / Figure-1
E
(TR)
Beden Seçimi
(EN)
Size Selection
Boy
Height
Bel
Bacak
P-3
Waist
Leg
E-1
E-2
S/M
65-95 cm
45-65 cm
L/XL
75-115 cm
60-70 cm
XX
85-135 cm
65-80 cm
L
STB-45
EN 358
STB-45
15 kN
A
A
Bel
Waist
Bacak
Leg
Boy
Ürün Gramajı
Height
Product Weight
E-4
E-3
155-175 cm
1,390 kg
175-190 cm
1,480 kg
180-200 cm
1,550 kg

Advertisement

loading
Need help?

Need help?

Do you have a question about the rock P-3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Kaya Safety rock P-3

  • Page 1 KULLANIM KILAVUZU USER GUIDE (TR) Düşüş Durdurma ve Konumlandırma Kemeri (EN) Fall Arrest and Work Positioning Harness EN 361:2002, EN 358:1999 STB-45 EN 358 STB-45 DÜŞÜŞ DURDURMA VE KONUMLANDIRMA Test eden Onaylı Kuruluş / Tested by Notified Body KEMERİ TÜV SÜD Product Service GmbH (No 0123) Daimlerstraße 11 FALL ARREST AND 85748 Garching - Germany WORK POSITIONING...
  • Page 2 (TR) Ürün Etiketi (EN) Product Label Ürün Kullanım Raporu A-1- Ürün Seri No A-2- Üretim Tarihi A-3- Sevk Tarih A-4- Kaşe İmza A-5- Ürün İlk Kullanım Tarihi A-6- Kullanıcı Ad/Soyad DÜŞÜŞ DURDURMA VE KONUMLANDIRMA KEMERİ FALL ARREST AND WORK POSITIONING HARNESS Ürün Yıllık Kontrolleri Malzeme / Material : %100 Polyester Ü.
  • Page 3 * Sırt ve Göğüs Ankraj Noktası; (Şekil - 1) - Ürün bir kontrol sırasında kullanıma uygun bulunmadı ise ve sizin bun- Bir düşüş durdurma sistemi ile sadece sırt ve göğüs ankraj noktalarını dan bir şüpheniz var ise. kullanınız (şok emici, lanyard, düşüş durdurma sistemi ve diğer EN 363 - Eğer ürünün kullanım geçmişini bilmiyorsanız.
  • Page 4 * Back and Chest Anchorage Points; (Figure- 1) Use only back and front anchorage points of safety harness with other equipment described in EN 363 (Shock absorber, lanyard, fall arrest systems). These points were Product Usage Report marked with “A” in order to be recognized easily). A-1- Serial Number In order to have an anchor point on the chest, both A/2 connection points must be...
  • Page 5 Notified Body after tests according to EN 361:2002, EN 358:1999 2- Materias Primas * KAYA SAFETY has CE0082 (APAVE SUDEUROPE SAS) notified body num- Este arnés de seguridad está hecho de; ber 89/686/EEC 11 B Quality System certificate and commit to Materiales Textiles: % 100 Poliéster...
  • Page 6 - Los usuarios tienen que estar adecuado a trabajar en alto medicalmente. 4. Uso Del Producto Se tienen que tener atención sobre que puede originar a los accidentes 4.1- EN 361:2002 Arnés De Detención De Caídas fatales la cinturón de seguridad. * Arnés de cuerpo entero para protección contra caídas Cuando el arnés de cuerpo entero se utiliza como dispositivo de protección 7.
  • Page 7 SÜD Product Service GmbH de producto (No 0123) después de las pruebas según EN 361:2002, EN 358:1999 * KAYA SAFETY tiene el servicio de producto APAVE SUDEUROPE SAS (n°0082) cuerpo notificado 89/686 / EEC 11 B Certificado del sistema de calidad y se compromete a producir cada producto igual que la muestra probada.
