- Page 1 .it AQ INSTALLATION AND MAINTENANCE INSTRUCTIONS...
- Page 2 Read the precautions carefully and carry out the procedures correctly. ATTENTION! Do not try to install the stove on your own. always rely on authorised and trained personnel -In the event of fault or malfunctioning always contact the Authorised Service Centre; any attempt to remove parts, or appliance maintenance may expose the user to the electrocution hazard.
-
Page 3: Installation
Standards and declaration of conformity Legislation Liability • Our company declares that the stove complies The manufacturer declines any direct or indirect with the following standards for the European civil or penal liability due to: Directive CE marking. • Poor maintenance. •... - Page 4 Installation • Each appliance must have its own flue with area. The different dimensions and shapes of a cross-section equal to or larger than the this area depend on the inclination angle of the diameter of the flue gas exhaust pipe of the roof making it necessary to use the minimum stove and no lower than declared.
- Page 5 Installation Flue gas exhaust Fig.3: installation of indoor flue to be made according to Combustion products must be exhausted standards through the roof. There must be one exhaust system for the stove (there cannot be exhausts in a flue shared with other devices).
- Page 6 Dimensioning Outdoor air inlet • A vacuum must not be created in the room The stove must have the air necessary to adjacent to the installation room respect to the guarantee regular combustion and proper outdoor environment by effect of a back draft environmental well-being.
-
Page 7: Technical Data
Technical data .it AQ 15 Overall output 5.23 14.79 Nominal output 5.04 13.84 Efficiency 96.29 93.54 Water side power 3.81 10.53 Hourly pellet consumption kg/h 1.067 3.017 Autonomy Pellet tank capacity Litres - kg 26 - 17 Fuel gas exhaust pipe Ø... - Page 8 Positioning Minimum aeration for combustion air inlet Fig. 9: distances from walls combustion air entrata aria Certain measures and prescriptions must be intake (> 120 cm comburente (> 120 cm) respected to correctly and safely position the air inlet (Fig. 9.) They are distances to be respected 20cm.
- Page 9 Quality features of the pellets For best operation of the .it, it is recommended The use of poor quality pellets can cause .it to use pellets the quality of which is certified by malfunctioning and shall terminate the warranty. an authorised body. If the .it remains off for long periods of time, the For best operation of the .it, it is recommended tank must be emptied from any residual fuel.
- Page 10 Ignition Room thermostat (optional) The electronic board provides an input for an external thermostat on connector CN7, specifically on terminals marked with the screen printing “TERM”. Follow the procedure below to control room temperature with a thermostat: • Switch off the heat stove using the main switch at the rear of the heat stove, •...
- Page 11 Maintenance by BTA (Biomass Technical Assistance) • pellet loading gearmotor at minimum speed; ATTENTION! • tangential heat exchange fan at maximum When commissioning the stove, the room speed. must be well ventilated as unpleasant This procedure lowers the temperature of the smells could develop during the first flue gas.
- Page 12 S.p.A. info@unical-ag.com - export@unical-ag.com - www.unical.eu Unical shall not be held liable for any inaccuracies due to transcription or printing errors. Furthermore, it reserves the right to modify its products as deemed necessary or useful, without affecting their essential features.
