Summary of Contents for Unical .it 7
- Page 1 7 - 8.5 - 10.5 INSTALLATION AND MAINTENANCE INSTRUCTIONS...
- Page 2 Read the precautions carefully and carry out the procedures correctly. ATTENTION! Do not try to install the stove on your own. Always rely on authorised and trained personnel. - In case of failures or malfunctions, always contact an Authorised Service Centre; any attempt to remove parts or to perform maintenance on the appliance can expose the user to the risk of electric shocks.
-
Page 3: Installation
Standards and declaration of conformity Legislation Liability • Our company declares that the stove The manufacturer declines any direct or indirect complies with the following standards for the civil or penal liability due to: European Directive CE marking. • Lack of maintenance. •... - Page 4 Installation • Each appliance must have its own flue with of combustion products and, in any case, a cross-section equal to or larger than the outside of the reflux area. The different diameter of the flue gas exhaust pipe of the dimensions and shapes of this area depend stove and no lower than declared.
- Page 5 Installation Fig.3: installation of indoor flue to be made according to insulated. standards If the smoke duct is inserted in a flue, this must be authorised for solid fuels and if the diameter is larger than 150 mm, it must be re-established by piping and sealing the exhaust respect to the part in masonry.
-
Page 6: Technical Data
Dimensioning .it 7 pellet stove dimensions .it 8.5 - 10.5 pellet stove dimensions Technical data .it 7 .it 8.5 .it 10.5 8.24 - 2.84 10.10 - 2.84 Overall output 6.97 - 2.84 Nominal output (max-min) 6.42 - 2.64 7.48 - 2.64 9.05 - 2.64 Pellet hourly consumption (max-min) kg/h... - Page 7 Positioning The stove is supplied with an electric cable to be Safety distances for fire protection connected to a 230V 50Hz socket, preferably The stove must be installed while meeting the with a circuit breaker switch. Voltage variations following safety conditions: beyond 10% can endanger operation of the •...
- Page 8 Positioning combustion air Minimum aeration for combustion air inlet Fig. 9: distances from walls intake (> 120 cm Certain measures and prescriptions must be respected to correctly and safely position the air inlet (Fig. 9.) They are distances to be respected to keep combustion air from being subtracted by another source: for example, opening a window can suck in outdoor air...
- Page 9 Quality features of the pellets Parameter M.U. EN plus-A1 EN plus-A1 Diameter (D) 6 (± 1) Length (L) 31,5 ≤ L ≤ 40 Water content (M) ≤ 10 ≤ 10 Ashes (A) 3 ≤ 0.7 ≤ 1.5 Mechanical durability (DU) ≥...
- Page 10 Ignition Operation of the appliance must be verified • Press the key for 2 seconds. After a few with an ignition test in compliance with the seconds, the flue gas extractor fan and the manufacturer installation instructions. ignition resistance switch on and the text “FAN ACC”...
- Page 11 Maintenance by BTA (Biomass Technical Assistance) • pellet loading gearmotor at minimum speed; ATTENTION! • tangential heat exchange fan at maximum When commissioning the stove, the room speed. must be well ventilated as unpleasant This procedure lowers the temperature of the smells could develop during the first flue gas. When it returns below the threshold hours of operation due to fumes coming...
- Page 12 46033 casteldario - mantova - Italy - tel. +39 0376 57001 - telefax +39 0376 660556 S.p.A. info@unical-ag.com - export@unical-ag.com - www.unical.eu Unical will not be held responsible for possible inaccuracies due to transcription or printing errors. It reserves the right to modify its products as deemed necessary or useful, without jeopardising their essential features.
