- Page 1 ZERO EDGE PRO Owner’s Manual INSTALLERS: PLEASE BE SURE TO LEAVE THIS MANUAL WITH THE OWNER. THANK YOU!
- Page 2 Innovations’ option) the defective part of the merchandise. Returns for service should be made to your Screen Innovations' dealer. If it is necessary for the dealer to return the screen or part to Screen Innovations, transportation expenses to and from Screen Innovations are payable by the purchaser and Screen Innovations is not responsible for damage in shipment.
-
Page 3: Table Of Contents
ZERO EDGE PRO Table of Contents SUGGESTED PROJECTOR PLACEMENT ............. 5 STANDARD FRAME PARTS LIST . - Page 4 SUGGESTED PROJECTOR PLACEMENT ZERO EDGE PRO Please visit our Screen Material Wizard (screeninnovations.com/tools/ screen-material-wizard/ ) for minimum throw distance requirements based on screen material. Better 11° Best 11° Good 36”-42” (91cm - 106cm)
- Page 5 ZERO EDGE PRO PRE ASSEMBLED STANDARD SPLIT...
-
Page 6: Standard Frame Parts List
STANDARD FRAME PARTS LIST (LED Lights Only) STANDARD 1 1/2’’ or 2’’ 1/2’’ Small trim trim option option Hardware Kit Wall Brackets Mounting Thumb 4X Thick Corner 4X Thin Corner 1/4-20 x 1/4’’ Screws Screws Brackets Brackets Screws (Small trim only) Bungees Acrylic Logo Channel Nut... - Page 7 STANDARD If IP controlled LED lights are ordered, Phillips Hue hub must be purchased and set up separately. See page 41 for IP lighting Instructions. Flying Mount Only LED IR Controlled Only LED Remote LED Foam 2X Flown Screen 2X Flown 2X Flown Ceiling Mount Cable...
-
Page 8: Standard Frame Assembly
STANDARD FRAME ASSEMBLY NOTE: If using AT or Maestro material then check to make STANDARD sure the channel nuts are installed in the inner channel before proceeding. Thick Bracket Thin Bracket Insert the thin corner brackets into the outside channels and the thick corner brackets into the inside channels of the vertical frames. - Page 9 STANDARD Make sure the points on the frame pieces line up. Then finger tighten 2 of the set screws to lock in the corners.
- Page 10 STANDARD A = B Measure the diagonals to check if frame is square. If one diagonal is longer then push on the corners at that diagonal. Tighten all set screws once the diagonals are equal to within 1/8’’.
-
Page 11: Split Frame Parts List
SPLIT FRAME PARTS LIST (LED Lights Only) SPLIT 1 1/2’’ or 2’’ 1/2’’ Small trim Trim option option Hardware Kit Wall Brackets Mounting Thumb 4X Thick Corner 4X Thin Corner 1/4-20 x 1/4’’ Screws Screws Brackets Brackets Screws (Small trim only) Bungees Acrylic Logo Channel Nut... - Page 12 SPLIT If IP controlled LED lights are ordered, Phillips Hue hub must be purchased and set up separately, see page 46 for IP lighting Instructions. Flying Mount Only LED IR Controlled Only LED Remote LED Foam 2X Flown Screen 2X Flown 2X Flown Ceiling Mount Cable...
-
Page 13: Split Frame Assembly
SPLIT FRAME ASSEMBLY NOTE: If using AT or Maestro material then check to make SPLIT sure the channel nuts are installed in the inner channel before proceeding. Thick Bracket Thin Bracket Insert the thin corner brackets into the outside channels and the thick corner brackets into the inside channels of the vertical frames. - Page 14 SPLIT Slide the horizontal frame pieces together and secure with the splice bars. Then attach the vertical support to the frame as shown.
- Page 15 SPLIT Make sure the points on the frame pieces line up. Then finger tighten 2 of the set screws to lock in the corners.
- Page 16 SPLIT A = B Measure the diagonals to check if frame is square. If one diagonal is longer then push on the corners at that diagonal. Tighten all set screws once the diagonals are equal to within 1/8’’.
-
Page 17: Led Lights Attachment
LED LIGHTS ATTACHMENT ZERO EDGE PRO If IP controlled LED lights are ordered, Phillips Hue hub must be purchased and set up separately, see page 50 for IP lighting Instructions. NOTE: Steps 1 and 2 will have already been completed if possible to be shipped that way. - Page 18 ZERO EDGE PRO Press in the lights to the channel on the frame. LED foam must be used when rounding the corners. Failure to do so will damage the LED strips Cut the light strips at the copper pad as indicated to...
-
Page 19: Black Diamond Or Short Throw Attachment
ZERO EDGE PRO Material? BLACK DIAMOND or SHORT THROW SLATE or PURE MAESTRO... -
Page 20: Slate Or Pure Attachment
SLATE OR PURE ATTACHMENT SLATE or PURE Non AT Material AT Material and Black Backer Wear gloves when handling material. Carefully unroll the screen material out onto a clean floor. Take care to not bend or crease the screen material. Carefully lie the frame onto the screen material. - Page 21 SLATE or PURE Remove and discard the black retaining bumpers then spread out the posts so that they aligning with the snaps on the screen material. Attach the snap attachments at the middle and then work your way towards the ends on all 4 sides of the screen material.
- Page 22 SLATE or PURE SLATE OR PURE Then check to make sure the screen material is flat and adjust the snap positions if necessary to flatten the screen material. Once all snaps are attached flip screen over and make sure that the screen material is flat and tight everywhere.
- Page 23 For Black DIamond and Short Throw Material Only BD or ST Black diamond and short throw material are highly sensitive. Take care to not bend or crease the material as you unroll it. BLACK DIAMOND OR SHORT THROW Then check to make sure the screen material is flat and adjust the snap positions if necessary to flatten the screen material.
-
Page 24: Black Backer Attachment
SLATE or PURE BLACK BACKER ATTACHMENT For AT Material Only Acoustically Transparent (AT) materials come with a black backer that must be installed to eliminate shine through. Spread out the nuts in the top frame piece and attach the black backer to the nuts with the thumb screws. -
Page 25: Maestro Attachment
MAESTRO MAESTRO ATTACHMENT Wear gloves when handling material. Carefully unroll the screen material and black backer out onto a clean floor. Take care to not bend or crease the screen material. Insert the rods into the pocket in the screen material. Make sure the screen material is lying flat. - Page 26 MAESTRO Carefully lay the frame onto the screen material and black backer. Center the frame about the screen material.
- Page 27 MAESTRO Remove and discard the black retaining bumpers then spread out the posts so that they aligning with the holes in the screen material and black backer. Put one end of the bungee through the hole in the material and black backer and place over the post while holding the other end.
- Page 28 MAESTRO Attach the bungees at the middle and then work your way towards the ends on all 4 sides of the screen material. Check to make sure the screen material is flat and adjust the bungee positions if necessary to flatten the screen material.
-
Page 29: Small Trim Attachment
ZERO EDGE PRO 1/2’’ SMALL TRIM 1 1/2’’ OR 2’’ MEDIUM OR LARGE TRIM... - Page 30 SMALL TRIM SMALL TRIM ATTACHMENT Velvet on trim is delicate, handle with care. Install trim with screen flat on floor, viewing side up, NOT when screen is vertical. Attach the vertical trim first onto the screen as shown above.
- Page 31 SMALL TRIM Split Frame Only Attach the horizontal trim pieces. Align and secure the corners with the 1/4-20 x 1/4’’ screws as shown. Hold the trim corners together while tightening the screw to ensure a well aligned corner. Split Frame Only: Connect the horizontals at the middle by installing quantity 4 1/4-20 x 1/4’’...
-
Page 32: Medium Or Large Trim Attachment
MEDIUM OR LARGE TRIM ATTACHMENT MEDIUM or LARGE TRIM Velvet on trim is delicate, handle with care. Install trim with screen flat on the floor with the viewing side up, not when screen is vertical. Attach the trim onto the screen as seen above. - Page 33 MEDIUM or LARGE TRIM Split Frame Only Loosen the screw on the corner plate, slide over to the corner, and hold the corners together while tightening the screw to secure the well aligned corners. Split Frame Only: Loosen the screw on the center cover plate, slide over to the middle, and hold together trim pieces while tightening the screw to secure the well aligned center trim seam.
-
Page 34: Logo Attachment
ZERO EDGE PRO LOGO ATTACHMENT Attach the logo to the trim by holding it at the middle of the horizontal trim and letting the magnet pull it to and attach to the back of the trim. NOTE: You can also attach the logo to the screen after it is installed on the wall or flown. - Page 35 ZERO EDGE PRO WALL MOUNT FLYING MOUNT...
-
Page 36: Wall Installation
WALL INSTALLATION WALL MOUNT TOP OF VIEWING LEVEL " (9.5 cm) TOP OF VIEWING " (12.1 cm) - Page 37 WALL MOUNT...
-
Page 38: Flown Installation
FLOWN INSTALLATION FLYING MOUNT 100 lbs 100 lbs (45.3 kg) (45.3 kg) - Page 39 FLYING MOUNT NOTE: If you pull too far the screen can be lowered by pushing down the button on the top of the flying mount. We recommend you don’t cut the extra cables for future adjustability. Simply tape the extra cable to the back of the screen frame.
-
Page 40: Ir Lighting Hex Codes
IR LIGHTING HEX CODES ZERO EDGE PRO IR Controlled Option Only 20 13 20 13 20 13 20 13 5C A3 5D A2 41 BE 40 BF 20 13 20 13 20 13 20 13 58 A7 59 A6 45 BA... -
Page 41: Ip Controlled Lighting Setup
IP CONTROLLED LIGHTING SETUP ZERO EDGE PRO Screen Innovations LED IP Setup Instructions Backlight IP Option Only Before attempting to connect your LED IP to Phillips Hue, ensure that the Hue Bridge is powered on and connected to the local WIFI network. - Page 42 ZERO EDGE PRO TRIM REMOVAL Disconnect the trim at the corners by either removing the screw or loosening the corner plate and sliding over. Then push in on trim pieces while rotating trim off of frame. The magnet will hold the trim in place at first.
- Page 43 NOTES...
- Page 44 Screen Innovations 9715-B Burnet Rd, Suite 400 Austin, TX 78758 512.832.6939 www.screeninnovations.com...
