- Page 1 INSTRUCTION MANUAL...
- Page 2 (Most supermarkets have) They are not allowed to be put into local household garbage. AMEWI Trade e.K. is involved in the dual system for boxing over the company Landbell AG. All used boxes are collected from partner companies (waste disposal contractor) at private customers (local household), sorted and properly utilized.
-
Page 3: Specifications
INSTRUCTION MANUAL PITBULL X EVOLUTION Please read this manual carefully and keep it for further questions. SPECIFICATIONS Length 825mm Width 480mm Height 270mm Wheelbase 610mm Gear Ratio 1:9,6 Ground clearance 55mm Weight 12,5kg Wheel diameter front Wheel diameter rear Wheel width front... - Page 4 INSTRUCTION MANUAL PITBULL X EVOLUTION CHASSIS...
- Page 5 INSTRUCTION MANUAL PITBULL X EVOLUTION TRANSMITTER Front view Rear view Top view 1. Cover for adjustment elements 9. Power LED 2. Antenna 10. Steering trim 3. Steering wheel 11. On-/Off switch 4. Throttle trigger 12. Throttle/Breake reverse switch 5. Battery box 13.
-
Page 6: Insert The Batteries
INSTRUCTION MANUAL PITBULL X EVOLUTION INSERT THE BATTERIES Insert 8x AA batteries in the batterie compartment. Please note the polarity. IMPORTANT NOTES • Never mix batteries and rechargeable batteries! • Never mix full and half empty batteries! • Do not mix batteries / rechargeable batteries of different manufacturers! •... -
Page 7: Connection Graph
INSTRUCTION MANUAL PITBULL X EVOLUTION CONNECTION GRAPH On/Off switch Battery 6V Throttle servo Receiver Steering servo Terminal assignment of receiver: CH1 – Steering servo, CH2 – Throttle servo, CH4 – Battery... -
Page 8: Fail Safe / Fail Safe
INSTRUCTION MANUAL PITBULL X EVOLUTION BIND TRANSMITTER Transmitter and receiver are already factory- matched and can be used immediately. A renewal of the binding is only necessary after a receiver or transmitter change or to remedy a mistake. Proceed as follows: 1. - Page 9 INSTRUCTION MANUAL PITBULL X EVOLUTION CONSTRUCTION OF THE ENGINE ignition cable pull starter Exhaust Off switch Pump Spark plug Air filter centrifugal clutch Fuel supply line Choke Fuel return line CARBURETTOR Fuel chamber Full load mix screw H-Needle Idle mix screw L-Needle...
-
Page 10: Engine Running In
INSTRUCTION MANUAL PITBULL X EVOLUTION Full load mix screw H-Needle Regulates the air-fuel mixture at full throttle. Turning = "lean" setting (more air) Turning off = "Faster" setting (more fuel) In the default setting, the screw is turned out 1.5 turns. - Page 11 INSTRUCTION MANUAL PITBULL X EVOLUTION PROBLEM: ENGINE DOES’N START 1. Turn all adjusting screws to factory settings. Check if the engine starts. 2. Turn the L needle slightly leaner (millimetre range). Check if the engine starts. 3. Repeat several times in the direction of leaner.
-
Page 12: Maintenance
INSTRUCTION MANUAL PITBULL X EVOLUTION MAINTENANCE To ensure optimal operation and a long service life of the model, it is necessary to perform maintenance and functional checks. Engine vibrations and shocks during driving can cause parts and screw connections to come loose. -
Page 13: Troubleshooting
INSTRUCTION MANUAL PITBULL X EVOLUTION TROUBLESHOOTING Error Cause Solution Transmitter not working Transmitter batteries are empty. Replace batteries or charge if rechargeable batteries. Batteries are inserted incorrectly Insert the batteries correct Range too low Transmitter batteries are empty. Replace batteries or charge if rechargeable batteries. - Page 14 INSTRUCTION MANUAL PITBULL X EVOLUTION Brake is ineffective Wrong adjusted brake linkage Correct the adjustment of the brake linkage. Throttle / brake servo not properly Check the trim of the throttle servo. trimmed Worn brake disk or brake shoes Replace the brake discs or brake shoes.
-
Page 15: Front Differential Installation
INSTRUCTION MANUAL PITBULL X EVOLUTION FRONT DIFFERENTIAL INSTALLATION... - Page 16 INSTRUCTION MANUAL PITBULL X EVOLUTION REAR DIFFERENTIAL INSTALLATION...
-
Page 17: Gear Installation
INSTRUCTION MANUAL PITBULL X EVOLUTION GEAR INSTALLATION... -
Page 18: Rear Axle Installation
INSTRUCTION MANUAL PITBULL X EVOLUTION REAR AXLE INSTALLATION... - Page 19 INSTRUCTION MANUAL PITBULL X EVOLUTION...
-
Page 20: Engine Installation
INSTRUCTION MANUAL PITBULL X EVOLUTION ENGINE INSTALLATION TANK INSTALLATION... -
Page 21: Servo Installation
INSTRUCTION MANUAL PITBULL X EVOLUTION RECEIVERBOX INSTALLATION SERVO INSTALLATION... - Page 22 INSTRUCTION MANUAL PITBULL X EVOLUTION SERVOSAVER INSTALLATION...
-
Page 23: Front Axle Installation
INSTRUCTION MANUAL PITBULL X EVOLUTION FRONT AXLE INSTALLATION... - Page 24 INSTRUCTION MANUAL PITBULL X EVOLUTION ROLLCAGE INSTALLATION...
-
Page 25: Spare Parts
INSTRUCTION MANUAL PITBULL X EVOLUTION SPARE PARTS Spare Parts you will find at https://amewi.com...
