USING SAFETY HARNESS
EN
20 Insert side strap buckle into harness
buckle on both sides.
21 Insert connected harness and side
strap buckles into the sides of the
crotch buckle.
22 Press button on crotch buckle to
release.
RECLINE THE SEAT
23 Pinch the clamp behind the seat, and
slide it down to desired recline.
24 Pull seat down on both sides to match
the clamp position. Reverse steps to
return to the upright position.
WARNING: When making adjustments
to the stroller seat, make sure child' s
head, arms, and legs are clear of
moving seat parts and stroller frame.
25 For extra ventilation, roll up the seat
back flap and secure with elastic and
button.

LEG SUPPORT

26 To use the leg support, lift the front of
the seat pad.
27 Rotate the support arm out and lower
the seat pad. Lock the support arm.
28 To lower leg support, reverse the steps.
FOLDING
• Remove your child from the seat.
• Disengage front wheel swivel locks.
• Remove all attachments and all items
from basket.
WARNING: To prevent injury, remove
Child Tray or Belly Bar accessory when
folding or unfolding the stroller.
29 Pull up on the straps on both seats and
let the frame collapse.
30 Make sure the auto-lock lever clicks
into place.

BASKET REMOVAL

31 From the front of the stroller, unsnap
the 2 snaps and pull the straps out of
foot well.
32 Lift basket off the hook.
33 From the back, lift the top of basket off
the tab on both sides of frame.
NWL0000951375A City Mini 2 Double USA R08 FINAL.indd 12
34 Remove the strap from the C clamp
on both sides of frame.

REMOVING THE SEAT PAD

35 Flip the stroller over to expose the seat
bottom.
A Unfasten the 4 fastening strips and
pull them out of the stroller frame.
B Unfasten the fastening strips and
pull them out of the sides of the
stroller frame.
C Unscrew 4 carabiner hooks and
remove them from the stroller
frame.
Unsnap 4 snaps from stroller frame.
36
37 Starting from the bottom, slide the seat
pad out from stroller frame on both
sides.
38 From the top, slide the seat pad out of
the frame on both sides.
39 Remove seat pad.
Reverse the steps to reattach the seat pad
to the frame.
