Summary of Contents for technoac Success AT-107N
-
Page 2: Table Of Contents
Table Page of Contents Introduction ......................3 1. The general description ..................3 Specification АP-014 ....................4 Receiver AP-014 ....................5 2.1 General view and buttons mapping ..............5 2.2 Receiver control and indication modes ............6 ........3. Portable acoustic sensor with magnet ADM-227... -
Page 3: Introduction
Introduction Acoustic water leak detector «Success AT-107» is used for acoustic detection of water leakages in underground pipelines and valve inspection. The application field - Housing and public utilities - Heating systems - Water utilities Operating conditions Ambient air temperature, °С ........from -30 до +50 Relative humidity, % ..........up to 85 at t=35 °С... -
Page 4: Specification Аp-014
Specification АP-014 AP-014 receiver Frequencies of the receiver’s 310 - 2000 Hz filter Gain factor 100 dB Visual indication LED scale – 7 values Audio output Headphones - natural Power supply Voltage 1.8 to 4V. - alkaline batteries АА type 1.5 V (2 pcs.) Time of continuous operation 10 hours Operation temperature... -
Page 5: Receiver Ap-014
2. Receiver AP-014 Reciever «АP-014» is made in the dimensions of the cell phone, has a built-in micro processor 2.1 General view and buttons mapping Sensor connector Headphone connector Led scale Pause Sensitivity Frequency and sound modes (>3c) Volume On/Off Batteries Battery cover compartment... -
Page 6: Receiver Control And Indication Modes
2.2 Receiver control and indication modes The receiver can work with acoustics or electromagnetism sensors. The type of the sensor is determined automatically. For an electromagnet sensor there are several reception frequencies. The light emitting diode scale executes indication of several functions: а) this is an indication of a power battery condition, b) a frequency of the received signal is switched in a circle, c) a sensitivity is more-less,... - Page 7 - Increase and reduction of headphones volume level. The volume in headphones level is changing with the corresponding «Change of volume” on headphones buttons. The volume level is displayed on the light emitting diode indicator with help of the blinking light emitting diode.
-
Page 8: Portable Acoustic Sensor With Magnet Adm-227
3 Portable acoustic sensor with magnet ADM-227 ADM-227 sensor is a portable acoustic sensor with magnet base and extension rod. Sensor Sensor with attached extension rod is used for valve inspection as handheld probe. Extension rod allows to use the sensor for inspection of valves in hard reachable places. Valve inspection Magnet base allows to attach the sensor to metal pipeline of any diameter and exclude unwanted noise (for example from hands).
