Assembly of the car jack

ASSEMBLY OF THE CAR JACK

Mounting the lever bar

1. Connect the two parts of the lever bars
other, and insert them into the

OPERATION OF THE CAR JACK

WARNING!
Do not work on or under the vehicle without knowing the exact
function and mode of operation of the device!
Before each use of the car jack, check that it is functioning
properly, in particular that there is no leakage of hydraulic oil, that
all screws and valves are tight and that there is sufficient oil in the
oil reservoir.

Take precautions on the vehicle

1. Before attaching the car jack, make sure that the vehicle's
parking brake is tightened.
2. For a vehicle with automatic transmission, set the selector lever
to "Parking".
3. If you have a manual transmission, engage first gear.
4. Block the non-lifted wheels with wheel chocks (wheel chocks
are not included).

Attaching the car jack

1. Lower the car jack completely. To do this, open the release valve
by placing the bar (at the end of the lower lever bar) on the
6
valve and turning it counterclockwise.
2. Close the release valve
12
handle holder.
4
by turning it clockwise firmly again .
6
with each
and
7 8
