MODEL: FLX-WH-01
02/2019
28
User
Manual
HYDRAULIC
TROLLEY JACK
1
Contents
Overview .................................................................................................................. 4
Use ............................................................................................................................ 5
Total content /parts ................................................................................................. 6
General information ................................................................................................8
Please read and store the instructions ..............................................................................8
Explanation of symbols........................................................................................................8
Safety ....................................................................................................................... 9
Correct use .............................................................................................................................9
Safety instructions ................................................................................................................9
First use ...................................................................................................................14
Check the car jack and the total content ......................................................................... 14
General overview ............................................................................................................... 14
Saddle assembling/dismantling ...................................................................................... 15
Assembling the car jack .........................................................................................15
Fitting the carry handle ..................................................................................................... 15
Assembling the jack handle .............................................................................................. 15
Attaching the jack handle ................................................................................................. 15
Car jack use .............................................................................................................17
Vehicle preparation .............................................................................................................17
Car jack placement ..............................................................................................................17
Vehicle lifting. ...................................................................................................................... 18
Vehicle lowering ................................................................................................................. 19
Troubleshooting .................................................................................................... 20
Maintenance, repair and inspection ..................................................................... 22
Adding oil ............................................................................................................................. 23
Changing oil ........................................................................................................................ 24
Cleaning and storing ............................................................................................. 25
Technical details .................................................................................................... 26
Waste disposal ....................................................................................................... 26
Disposal of the packaging .................................................................................................26
Disposal of the car jack .......................................................................................................26
Declaration of conformity. ..................................................................................... 27
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ALDI AutoXS FLX-WH-01
Summary of Contents for ALDI AutoXS FLX-WH-01
-
Page 1: Table Of Contents
Attaching the jack handle ....................15 Car jack use ......................17 Vehicle preparation ......................17 Car jack placement ......................17 PRODUCED IN CHINA FOR: ALDI STORES LTD. PO BOX 26, ATHERSTONE Vehicle lifting........................18 WARWICKSHIRE, CV92SH. Vehicle lowering ......................... 19 Troubleshooting ....................20 ALDI STORES (IRELAND) LTD. -
Page 2: Use
Total content /parts S addle holder S addle bolt S addle sleeve S addle Lifting arm Cover plate Handle sleeve Jack handle Carry handle Release valve Carry handle nut Jack handle clip, 4 Drilled hole - User Manual / Warranty Card... -
Page 3: General Information
General information Safety GENERAL INFORMATION Declaration of conformity (see the “Declaration of conformity” section): Products marked with this symbol Please read and store the instructions fulfil all of the rules, which they must adhere to, of the European These instructions for use are valid for this hydraulic Economic Area. - Page 4 Safety Safety − The car jack should only be used for lifting and lowering vehicles. − Before each use examine the car jack. If you notice loose parts or damage, do not use the car jack. In this case, do not use the DANGER! Danger of personal injury! car jack;...
- Page 5 Safety Safety car jack on a soft surface (for example on grass). Such a surface − Do not use the car jack in a potentially explosive area, near could cause the vehicle to incline or fall from the car jack, which explosives and mines.
-
Page 6: First Use
First use Saddle assembling/dismanteling FIRST USE Saddle assembling/dismantling Check the car jack and the total content Damage and injury risks! WARNING! NOTICE! Risk of injury! If the saddle is removed from the saddle holder, the load will not lift equally and stably, which can lead to personal injury and Be very careful when opening the packaging. -
Page 7: Assembling The Car Jack
Assembling the car jack Car jack use ASSEMBLING THE CAR JACK CAR JACK USE Fitting the carry handle Danger of personal injury! DANGER! On each side of the jack handle sleeve is a nut, where the carry If the car jack is not properly placed (under a vehicle), it will not be handle is attached possible to lift vehicles steadily and they could also fall suddenly. -
Page 8: Vehicle Lifting
Car jack use Car jack use Vehicle lifting Vehicle lowering Danger of personal injury! Danger of personal injury! DANGER! DANGER! Never conduct work on, under or around a vehicle which is solely If there are people, animals or other objects in or under the vehicle, supported by a car jack. -
Page 9: Troubleshooting
Troubbleshooting Troubleshooting Problem Possible reasons Solution Problem Possible reasons Solution The car jack − Low on oil. − Add oil (see “Maintenance, The car jack − Movable parts − The reservoir is damaged. will not lift repair and inspection” is making of the car jack the vehicle. -
Page 10: Maintenance, Repair And Inspection
Maintenance, repair and inspection Maintenance, repair and inspection MAINTENANCE, REPAIR AND INSPECTION Adding oil Damage and injury risks! Damage and injury risks! CAUTION! WARNING! When the car jack is being used in a working area where oil is If too much oil is added to the reservoir, the car jack will become spilled, it can slip and cause material damage and/or personal overloaded and can cause injury. -
Page 11: Changing Oil
Maintenance, repair and inspection Cleaning and storing CLEANING AND STORING Changing oil • Check the oil at least once a year; if dirt or foreign objects NOTICE! Danger due to incorrect use! are noticed, change the oil. With inappropriate handling, the car jack can be damaged. •... -
Page 12: Technical Details
Technical details / Waste disposal Declaration of conformity TECHNICAL DETAILS DECLARATION OF CONFORMITY Model: FLX-WH-01 Lowest saddle height - with the sleeve: 150 mm - without the sleeve: 135 mm Highest saddle height with the sleeve with a load: 350 mm without a load: 357 mm Highest saddle height without the sleeve...
