6. Place the lower door on a
smooth surface with its
p a n e l u p w a r d s . L o o s e
② ，
screws detach part
Then install
corresponding position on
left side together with
②.
screws
① Stop block
② -
Self tapping screws
7. Change screw hole
covers on middle cover
plate from left to right (as
shown in figure below).
8.Place refrigerator flatwise,
③
remove part
④ .
loose screws
②
part and part
① .
①
part to
①
②
and then
Remove
①.
Hisense Refrigerator
① Lower hinge part right （ ）
② Front foot fixed board
③ Adjustable bottom feet part
④ Self tapping screws -
9. Screw out lower hinge,
change it to the near hole
site, and then screw up and
mount washer.
10. Just remount to the step
①
8,change part
②
part to right and then fix
them with
Finally install part
Lower hinge part (left)
11. Move the lower door
and adjust its position to
align lower hole site and
upper hinge axis. Turn the
m i d d l e h i n g e b y 1 8 0 ,
change the washer on the
axis to the upper side,
adjust the middle hinge to
the appropriate position and
then install it.
10
washer
Note: washer may
stick to lower door.
to left and
④ .
screws
③.
