Summit SUM-71000262 Installation Instructions

High endurance tube steps with step pads for ford f150

Advertisement

1997-03 Ford F150 Ext Cab and 4 Dr Cab

Parts List:

2-Front Mount Brackets (two mounting holes)
Driver Side Front Bracket
2-Rear Mount Brackets (four staggered mounting holes)
Driver Side Rear Bracket
1-Driver Side Bar
1-Passenger Side Bar
2-Front Support Straps
2-Rear Support Straps
4-12mm x 2" Hex Bolts
8-12mm Flat Washers
8-12mm Lock Washers
4-12mm x 1.25" Hex Bolts
4-12mm Hex Nuts
8-10mm Hex Nuts
8-10mm Flat Washers
8-10mm Lock Washers
4-Large Bolt Plates
1-Small Bolt Plate (For use on 97-98 Ext Cab Rear Mounting location only)
Installation Instructions
High Endurance Tube Steps with Step Pads
Part Number: SUM-71000262
/ 01-03 Ford Super Crew Pick Up 4 Dr
Passenger side Front Mounting Bracket
Passenger side Rear Mounting Bracket

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SUM-71000262 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Summit SUM-71000262

  • Page 1 Installation Instructions High Endurance Tube Steps with Step Pads Part Number: SUM-71000262 / 01-03 Ford Super Crew Pick Up 4 Dr 1997-03 Ford F150 Ext Cab and 4 Dr Cab Parts List: 2-Front Mount Brackets (two mounting holes) Driver Side Front Bracket...
  • Page 2 Installation: 1. Locate factory pre-drilled and horizontal slotted mounting locations on the underside of the body above pinch weld and along pinch weld. In some cases, the holes and slots may be covered with tape or have rubber plugs that will need to be removed. These are the foremost and rearmost mounting locations.
