Package Contents

Garage Door Opener:
(1) SD1200 opener/powerhead
(2) Hand transmitter (2)
(3) Wall transmitter
(4) Door bracket
(5) Lintel/Ceiling bracket
(6) Curved door arm
(7) Straight arm
(8) Fixing bracket
1
2
6
11

Rail Details

One Piece Belt Rail
RAIL OPTION DOOR HEIGHT
Rail A Up to 2500mm
Rail B Up to 3500mm
(9) Hanging bracket (2)
(10) Rail bracket (2)
(11) Hardware bag
(12) Door safety label
(13) Manual release instruction card
(14) Installation & operating instructions
(15) Trolley assembly
3
7
13
12
RAIL LENGTH
3300mm
4300mm
Page 3
Installation & Operating Instructions
SD1200 - Sectional Garage Door Opener
4
9
8
14
CEILING FIXING POINT
3000mm
4000mm
5
10
15
OVERALL LENGTH
3330mm
4330mm
