Contents
User Information .............................................. 1
Important Safety Instructions ........................... 2
Package Contents ........................................... 3
Rail Details ...................................................... 3
Assembly & Installation ................................... 4-6
Control Panel .................................................. 7
Programming Instructions................................ 8-9
Safety Reverse Test ........................................ 9

User Information

Important Safety Notes:
A garage door is the largest automated moving object in most homes.
Care needs to be taken when using this system.
Like any other electrical appliance or machine, it is important to familiarise yourself with the safety
guidelines which are applicable to automated garage doors. These are contained at the beginning and
throughout this booklet.
The following summary highlights some of these safety guidelines:
✓ Only operate the garage door when in full view to ensure people, objects and pets remain away from
the door whilst it is moving.
✓ Keep all controls away from children and do not allow them to play with the door.
✓ Regularly check the door and have it maintained and serviced as per the manufacturers' instructions.
✓ Safety beams or an equivalent safety device are recommended for any automated door for additional
safety.
Standard Operation of the Door:
If the door is OPENING: When the programmed remote control (transmitter) button is pressed, it will stop
the door. The next press will start the door moving in the opposite direction.
If the door is CLOSING: When the programmed remote control (transmitter) button is pressed, it will stop
the door. The next press will start the door moving in the opposite direction.
Installation Details:
Installation Date:
Installed by:
Telephone Number:
PLEASE RETAIN YOUR RECEIPT FOR WARRANTY PURPOSES.
Safety Reversal Force Adjustment .................. 10
Coding Wireless Transmitters .......................... 11
Safety Beam Installation .................................. 12
Auto-Close Timer ............................................ 13
Service Counter ............................................... 14
Technical Specifications .................................. 15
Troubleshooting ............................................... 16
Warranty .......................................................... 17
See page 17 for full Warranty Terms & Conditions.
Page 1
Installation & Operating Instructions
SD1200 - Sectional Garage Door Opener
V2.09/19
