- Page 1 MODELS RB-3011E-CB RB-3011E-ZB RB-3012E-CB RB-3012E-ZB RB-5022E-ZB RB-5022E-CB RB-6013E-CB RB-6013E-ZB RB-6014E-ZB RB-6014E-CB RB-6024E-ZB RB-6024E-CB RB-7012E-CB RB-7012E-ZB RB-7013E-ZB RB-7013E-CB Vitroceramic Hob Operation / Installation Manual...
- Page 2 TABLE OF CONTENTS English Page 01 - 12...
-
Page 3: Table Of Contents
Electrical Connection --------------------------------------------------------------------------------------------------------------------- 11 IMPORTANT Please paste the serial number labels enclosed with the packaging on your warranty card to register your product warranty. Please contact your local Rinnai Customer Care Centre should you require further assistance. Version: 2019 06 2.1... -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS Please read this user manual thoroughly before attempting to use this appliance for the first time. This manual contains important information on safe installation, use and care of the appliance. Keep these instructions for reference and pass them on to future user. Unpacking spillovers may ignite. -
Page 5: Technical Data
Middle:1.2kW Rear left: 1.2kW Right:1.8kW Rear right: 1.8kW Total Power 6400W 4100W Appliance Dimension 590*520*50mm 710*410*50mm Cut-out Dimension 560*490mm 680 * 380mm RB-3011E-CB RB-5022E-CB Model RB-3011E-ZB RB-5022E-ZB Voltage 220-240V 220-240V Frequency 50/60Hz 50/60Hz No. of Cooking Zones Left:1.8kW Power of Cooking Zones 2.0kW... - Page 6 Model No. A(mm) B(mm) W(mm) D(mm) H(mm) X(mm) Y(mm) RB-3012E-CB RB-3012E-ZB RB-6014E-CB RB-6014E-ZB RB-6024E-CB RB-6024E-ZB RB-7013E-CB RB-7013E-ZB Measurements in mm. Min. 50mm from hob cut-out to back wall. Min. 60mm from hob cut-out to side wall. Min. 70mm from the bench top with a fitted drawer underneath. Min.
-
Page 7: Guide To The Appliance
GUIDE TO THE APPLIANCE RB-3012E-CB / RB-3012E-ZB RB-7013E-CB / RB-7013E-ZB 1. Dual Zone 1100W/2200W (Φ140mm/Φ230mm) 1. 1800W(Φ200mm) 2. 1200W(Φ165mm) 2. 1200W(Φ165mm) 3. 1800W(Φ200mm) 3. Control panel 4. Control panel RB-6014E-CB / RB-6014E-ZB RB-6024E-CB / RB-6024E-ZB 1.1800W(Φ200mm) 1. Dual Zone 1100W/2200W (Φ140mm/Φ230mm) 2.1200W(Φ165mm) 2. - Page 8 RB-3011E-CB / RB-3011E-ZB RB-5022E-CB / RB-5022E-ZB 1. 2000W(Φ200mm) 1. 1800W(Φ200mm) 3. Control panel 2. 1200W(Φ165mm) 3. Control panel RB-6013E-CB / RB-6013E-ZB RB-7012E-CB / RB-7012E-ZB 1. 1800W(Φ200mm) 1. 1100W/2200W(Φ140mm/Φ230mm) 2. 1200W(Φ165mm) 2. 1100W/2200W(Φ140mm/Φ230mm) 3. 1100W/2200W(Φ140mm/Φ230mm) 3. Control panel 4. Control panel...
- Page 9 CONTROL PANEL RB-3012E-CB / RB-3012E-ZB RB-3011E-CB / RB-3011E-ZB RB-7013E-CB / RB-7013E-ZB RB-5022E-CB / RB-5022E-ZB RB-6014E-CB / RB-6014E-ZB RB-6013E-CB / RB-6013E-ZB RB-6024E-CB / RB-6024E-ZB RB-7012E-CB / RB-7012E-ZB 1. ON/OFF key 2. Child lock 3. Power level indicator / Timer indicator 4. Power level selector ("+" to increase level) 5.
-
Page 10: Helpful Hints And Tips
HELPFUL HINTS AND TIPS Practical Cooking Advice This appliance is programmed with 9 power levels. The following power levels should be taken as a guide only. A higher power level setting is required when using deep pans, cooking large food quantities, or cooking without a lid. Select a lower power setting for smaller food quantities. -
Page 11: Operating Instructions
OPERATING INSTRUCTIONS Switching ON/OFF the hob power management will not allow all both zones to The hob must be switched on before any of the cooking operate at full power but will alternate power between zones can be used. the dual zone or middle cooking zone. The change will be visible on both displays. -
Page 12: Maintenance And Care
• To see the remaining time press on the "H" is turned off when the cooking zone temperature corresponding zone selector key, the display will drops below a present temperature. show the remaining time • When the time is set, the countdown will begin and Automatic switch off the display will show the remaining time. -
Page 13: Troubleshoot
TROUBLESHOOT The hob does not work • Check that the main switch is turned on and any plug or power cable is properly inserted in the electrical outlet. The hob gives off a smell when used for the first time •... -
Page 14: Installation Instructions
INSTALLATION INSTRUCTIONS CAUTION • This appliance shall only be serviced by authorized personnel. This appliance is to be installed only by an authorized person according to the current local regulations and in observation of the manufacturer’s instructions. • Incorrect installation, for which the manufacturer accepts no responsibility, may cause personal injury of damage. - Page 15 FASTENING THE COOKTOP Each cooktop is supplied with a set of tabs and screws to fasten it on units with a working surface from 3 to 4 cm deep. The kit includes 4 tabs A and 4 self-threading screws B (fig.
-
Page 16: Electrical Connection
ELECTRICAL CONNECTION IMPORTANT: Installation must be carried out according to the manufacturer’s instructions. Incorrect installation may cause harm and damage to people, animals or property, for which the manufacturer accepts no responsibility. Before carrying out any work on the electrical section of the appliance, it must be disconnected from the mains. Connection to a good earth wiring system is absolutely essential. - Page 17 WIRING DIAGRAM Foe Below Model Only RB-6013E-CB / RB-6013E-ZB RB-6014E-CB / RB-6014E-ZB RB-6024E-CB / RB-6024E-ZB RB-7012E-CB / RB-7012E-ZB RB-7013E-CB / RB-7013E-ZB...
- Page 20 Rinnai Customer Care Centres Philippines China |中国 Mitsui Industia Corporation Guangzhou Rinnai Gas & Electric 10 Buenaventura St., Cor MacArthur Room 2805, No.31 Jianghe Building, Highway, Dalandan Valenzuela City, Tianshou Road, Guangzhou, China Philippines 广州林内燃具电器有限公司 Tel : (63) 2 292 9177 / 292 9179 中国广州天河区天寿路...
