Owner's Manual
TCC-9510
Cassette Player / Receiver with 4-Channel High Power
Output Flip Down Detachable Face Panel & ISO DIN
Mounting Chassis
BZ03

Advertisement

loading

  Related Manuals for LG TCC-9510

  Summary of Contents for LG TCC-9510

  • Page 1 Owner's Manual TCC-9510 Cassette Player / Receiver with 4-Channel High Power Output Flip Down Detachable Face Panel & ISO DIN Mounting Chassis BZ03...
  • Page 2 HOW TO INSTALL & REMOVE THE APPARATUS CAUTION-INVISIBLE LASER RADIATION WHEN OPEN AND WARNING INTERLOCKS DFEATED, AVOID EXPOSURE TO BEAM. RISK OF ELECTRIC SHOCK DO NOT OPEN The lightning flash with arrowhead within an equilateral triangle is intended to alert the user to the presence CAUTION of uninsulated “dangerous voltage”...
  • Page 3: Wiring Connections

    WIRING CONNECTIONS Precaution on making connections Before connecting, make sure that ignition switch is set to OFF, and remove the terminal of the battery to avoid short circuits. Note Make correct connections as illustrated in the connection diagram. Never use the cord of each speaker in common.
  • Page 4 WIRING CONNECTIONS From antenna From power amplifier’s input jack( 2 channel or 4 channel : optional ) To the wiring of vehicle colors of leads BLACK(Ground lead to be connected to vehicle(metal) body) PINK(Dimmer lead to be connected to Dimmer switch of vehicle) RED(ACC lead to be connected to the terminal from which the power is supplied when the ignition swich is set to ACC) YELLOW(Battery lead to be connected to the back up terminal from which power is always supplied) BLUE(To relay box for full automatic power antenna or power amplifier control lead.
  • Page 5 HOW TO INSTALL & REMOVE THE APPARATUS NOTE ! Use only the supplied mounting hardware for safe and secure installation. Please consult your nearest dealer if you get any problems with installation. HOLDER Press the open knob to open up the front panel and detach it by pulling it towards you.
  • Page 6: Attaching The Front Panel

    FRONT PANEL Attaching the front panel 1. Holding the panel at its top and bottom edges. 2. Attach one side of the panel lightly first, then push the other side of the panel into the unit. 3. Do not press the panel hard against the unit.
  • Page 7 FUNCTION DESCRIPTION, CONTROLS 1. POWER 7. DIR/MUTE 13. AUT(AUTO TRAVEL PRESET) ON/ OFF(PWR) 8. LCD 14. TUNE(AUTO / MANUAL) 2. VOLUME UP / DOWN 9. INTRO SCAN(INT) 15. TUNING & TRACK UP / DOWN (TUN 3. BAND 10. REPEAT(RPT) 16. SCAN 4.
  • Page 8 RADIO 1. POWER ON/OFF (PWR 4. TUNING UP / DOWN CONTROL ( ) To switch the audio system on/off, press power During the radio mode : button lightly. Rotate the Tune button Simultaneously, the system memorizes all clockwise / counterclockwise to choose the radio information about its current setting, and restores station which you want to listen to step by the information when you turn the system on by...
  • Page 9: Display Control

    RADIO / SOUND / DISPLAY 7. AUTO TRAVEL PRESET (AUT, 10. EQ ( ) Press the AUT button within 1.5 seconds, you can Press the EQ button and than, rotate volume to change the radio mode to the AUT function that select from the different sound effects of Pop, operates all over the radio band.
  • Page 10: Cassette Player

    CASSETTE PLAYER Listening to a tape Open the front panel by pressing the open ( ) button. Insert a cassette tape. Close the front panel. Play will start automatically. If a tape is already inserted, press the DIR button. Fast winding the tape ( During playback, rotate the Tune button clockwise / counterclockwise to rewind/ fast forward.
  • Page 11: Intro Scan

    CASSETTE PLAYER To go to the beginning of a desired track 14. INTRO SCAN (INT, Press the “INT” button, it displays “INTRO” and 17. Automatic Music Search (AMS) then it starts to play the first 10 seconds for songs. During playback, press the TUN button once, then 15.
  • Page 12 OPTION : CD - CHANGER DIR(CDC) INTRO SCAN REPEAT RANDOM DISC SELECTOR(D-/D+) MODE 1. CDC MODE SELECTOR (MODE, DIR, 4. RANDOM FUNCTION (RDM, Press the MODE button to change to CD changer mode. If you want to enjoy the songs in a random order, press this button. If you press DIR button, CD sound will be muted (PAUSE mode).
  • Page 13: Specification

    SPECIFICATION Power supply 12 - 15V DC Wow and Flutter 0.35% Speaker impedance 4 or 8 ohm Signal to Noise ratio 50dB Output Power Maximum 50W x 4CH Channel Separation 35dB Current Drain Max. 10A Frequency Response 63Hz-10kHz( 3dB) Tape Speed 4.75cm/sec Dimension (W H D)
  • Page 14 P/N:3828R-F016Y...
