To replace the Discharge Manifold (23549) in
an ADH NETCOM AC NEMA, perform the
steps below.
Shut
off
1.
unplugging the unit.
Open the two front door latches,
2.
loosen the two captive screws in the
corners of the housing opposite the
hinges, then open the NEMA box.
Place an object underneath the door
once open to help support it during
this procedure.
Remove the orange ethernet cable on
3.
the left by disconnecting both ends,
then removing it. Set aside for re-use.
Remove the power cable connector on
the right by loosening the captive
screw on each end of the green
connector,
then
connector.
Disconnect the ground
wire by loosening the ground wire
retaining
screw,
removing the ground wire. Refer to
Figure 1.
Disconnect
both ends,
then remove
orange
ethernet cable.
Loosen both captive screws,
then disconnect connector.
Figure 1. DISCONNECTING THE
ETHERNET CABLE,
THE POWER CABLE CONNECTOR, AND
THE GROUND WIRE.
South Bend, Indiana USA
|
networketi.com
machine
power
by
unplugging
the
then
carefully
Loosen
screw,
then
remove
ground
wire.
4.
Remove and retain the four
mounting screws from the four
corners of the protective front cover,
then slowly lift the front cover,
carefully flip it over, then set it down,
upside down, to rest on the inside of
the enclosure door. Be careful as
there are still many wires connected
between the enclosure and the front
cover and there isn't a lot of slack.
Note that the two upper front cover
mounting screws are located in plain
sight in the top corners of the front
cover, while the two lower front
cover corner mounting screws are
located down in the front "well" of
the unit. Use a long screwdriver to
remove them.
5.
Note how the three air hoses are
connected to the existing discharge
manifold, then carefully disconnect
the hoses from the existing manifold.
Refer to Figure 2. The hose in the
middle of the back or top side of the
manifold runs from the humidity
sensor. The hose on the left side of
the manifold runs to the pressure
transducer. The hose on the front or
bottom of the manifold runs to the air
out fitting. These three hoses will be
connected to the new discharge
manifold in this same arrangement.
6
ADH INSTRUCTION MANUAL | PART NO.
24101
REV
B
