Installation Manual
Attached Separately
Caution labels are attached on the product.
Smart Use Save Energy
Thank you for purchasing Panasonic product this time.
Please read the operating instructions carefully before using this product, and
●
save this manual for future use.
Before using the product, please make sure to read "Caution for Safety" (Pages 2 to 4).
●
Please carefully read this manual and, keep this documentation in a safe place for
●
future reference.
Refrigerator, Freezer
Model No.
Operating Instructions
SRR-K1281-ME
SRR-K1581-ME
SRF-K1281-ME
SRF-K1581-ME
Table of Contents
Before Using the Product
Caution for Safety ・・・・・・・ 2 - 4
Name of Each Part ・・・・・・・ 5 - 6
How to Install
Accessories ・・・・・・・・・・・・ 9
How to Operate
Other
In Such a Case ・・・・・・・・・・ 19
- Refrigerator ・・・・・・・・・・・ 22
- Freezer ・・・・・・・・・・・・・ 22
Separately Available Items ・・・・・ 23
(For Commercial Use)
・・・・・・・ 7 - 8
Advertisement
Table of Contents
Related Manuals for Panasonic SRR-K1281-ME
Summary of Contents for Panasonic SRR-K1281-ME
-
Page 1: Table Of Contents
Caution labels are attached on the product. - Freezer ・・・・・・・・・・・・・ 22 Separately Available Items ・・・・・ 23 Smart Use Save Energy Thank you for purchasing Panasonic product this time. Please read the operating instructions carefully before using this product, and ● save this manual for future use. -
Page 2: Caution For Safety
Caution for safety Be sure to comply To avoid human injury and property damage, absolute requirements are described here. ■ The degree of injury or damage caused by incorrect use is grouped for understanding. Danger that may cause Danger that may cause minor WARNING CAUTION death or serious injury. - Page 3 WARNING ■When using a product..■During installation..Avoid doing the followings. Avoid doing the followings. < Danger of fire or electrical shock > < Danger of fire or electrical shock > Prohibited Prohibited Do not store volatile or flammable ● Do not install the product where ●...
- Page 4 Caution for safety Be sure to comply CAUTION During installation, transfer ■ When using a product..■ or storage..Avoid doing the followings. Comply with the followings. Do not throw items into the ● Prohibited compartment. Before a transfer or storage, ●...
-
Page 5: Name Of Each Part
Name of Each Part ＜ Refrigerator, Freezer ＞ The illustration is based on model No. SRR-K1281-ME. (Center-pillar type) Specification may be slightly different by model. Grill Grill can be held open. Condenser filter (Please see Page 11) (Please see Page 15) Condenser Compartment... - Page 6 Name of Each Part Control Panel < Refrigerator > Temperature setting button Button for setting the compartment temperature. ECONAVI Temperature Lamp adjustment button Lights up during Econavi operation. Buttons for adjusting the (Please see Page 12) compartment temperature. (Please see Page 12) Compartment Temperature Indicator Indicates compartment temperature.
-
Page 7: About Installation
About Installation Caution for indemnity against accident or damage (failure) ■ Our company is not liable for any accident or damage caused by the method not described in the installation manual or without using the specified components. Any product failure caused by such installation is out of the product warranty. Please request a specialty operator for installation work. - Page 8 About Installation Installation location (continued) ■ Install the product horizontally or slightly tilted toward the back on a sturdy flat floor. In addition, secure the product with a bracket for avoiding fall down by an earthquake etc. Incorrect installation may cause water leak or injury by falling. To avoid vibration or noise from the product, install it in a stable condition.
-
Page 9: Accessories
Accessories Name Shape Name Shape Quantity Quantity Operating Shelf bracket Instructions Drain hose Wire shelf (refrigerator only) Fall prevention Wire shelf bracket (for bottom level) (4 sets inside) Available separately Lock installation parts ● Wire shelf set ● Door stopper (For changing the door opening angle) ●... -
Page 10: How To Use ・・・・・・・・・・10
How to Use Before operation ■ Use a dedicated power outlet. Do not connect the power cord in the middle, or avoid using an extension cord or branching connection. It may cause electrical shock, heat generation or fire. Single-phase 240 V power ■... - Page 11 How to Use How to open the grill ■ How to open and close the grill Open the grill by lifting it as shown by the arrow. ● ■ When opening the grill and securing the position Both sides may be hooked for keeping it open. ●...
- Page 12 How to Use About ECONAVI operation ■ ECONAVI operation automatically performs cooling operation by judging the installed and used condition of the refrigerator or freezer and saving energy according to the environment. ■ During ECONAVI operation, ECONAVI lamp is turned on. ■...
- Page 13 How to Use How to install a shelf bracket and wire shelf ■ Height of wire shelf can be adjusted in 12.5 mm CAUTION steps. Adjust the attachment position of the shelf bracket according to the size of storage items. Correctly attach the shelf brackets and wire shelves.
- Page 14 Place items for achieving uniform load. Do not throw items into the compartment. Shelf bracket may come off and lead to injury. < Center pillar type > SRR-K1281-ME SRR-K1581-ME SRF-K1281-ME SRF-K1581-ME ■ Always check the storage period of food and apply first-in first-out rule.
-
Page 15: How To Inspect And Care ・・・15
How to Inspect and Care WARNING Do not apply water Do not connect or Be sure to unplug or water-wash the disconnect power during caring or exterior or compart- plug by a wet hand. repair. ment interior. Denger of electri- Denger of Danger of fire or cal shock and fire... - Page 16 How to Inspect and Care CAUTION Do not touch the condenser Clean the condenser after fin directly by hand. stopping operation and it is cool. It may lead to injury. The condenser during cooling operation is hot and leads to Wear gloves when cleaning.
- Page 17 How to Inspect and Care Drain path Request cleaning periodically in one or two-year interval. ＊ Exclude Page 16 "Drain Outlet" CAUTION ■ Accumulation in the drain path disturbs normal flow of defrosted water or condensed water. Do not clean the path Accumulated water from defrosting and by the user.
- Page 18 How to Inspect and Care About error code display When a problem occurs while using the product, an error code is ■ displayed in blinking in the compartment temperature display. Check the following and if the error code still remains, contact the product distributor.
- Page 19 In the Following Cases Power failure ■ Reduce door opening as much as possible. ■ Avoid adding food inside for preventing increased compartment temperature. When the product is not used for a long time ■ Remove all food items from the compartment, CAUTION clean the interior, and wipe off any moisture.
-
Page 20: Before Requesting A Repair ・・20
Before requesting a repair WARNING Do not connect or disconnect Be sure to unplug during repair. power plug by a wet hand. Danger of electrical shock. Avoid fire or electrical shock. Prohibited Check out the following items and still the problem exists or abnormal sound, smell or smoke is detected, immediately unplug and move the stored food to other refrigerator, etc. - Page 21 Before Requesting a Repair Items to be informed (1) Condition of failure (Please tell us specific condition such as error code) (2) Model number (Described in the model number badge) (3) Manufacturing code (4) Your name, address, phone number, and how to get to the location (Tell us an easy-to-find land mark, building and room number) (5) Date of purchase (6) Requesting date of visit...
-
Page 22: Srr-K1281-Me
Please refer to this value when using for your purpose. ＊ Dimensions W×D×H indicate the width × depth × height. Commercial Refrigerator Product name Model No. SRR-K1281-ME SRR-K1581-ME Exterior （ W×D×H） （ mm） 1 200×800×1 950 1 460×800×1 950 1 100×700×1 450 1 360×700×1 450... -
Page 23: Separately Available Items
Wire shelf stopper installation Item name (1, 4 shelf supports) parts (85°) Separately-sold SRR-J04S SRR-J07S SRR-JHS SRR-JKY4 Part No. Product 530×622 mm 660×622 mm number ○ ○ SRR-K1281-ME ○ K1581-ME ○ ○ ○ ○ ○ SRF-K1281-ME ○ K1581-ME ○ ○ ○... - Page 24 Please fill the spaces at the time of purchase. It is convenient when requesting a repair. Product number Date of purchase Month Year Product distributor name Phone: ( ) - Panasonic Corporation Cold Chain Business Division Part No. 1-1 Sakata 1-chome, Oizumi-machi, Oura-gun, Gumma Prefecture, Japan 〒 370-0596 5FM6P11044400 Ｃ0817-0 2017...
